H83D00VDTH01, Huawei H83D00 Series VDSL2 Service Board, 24 VDSL2/ISDN/Service Board

Name: H83D00VDTH01, Huawei H83D00 Series VDSL2 Service Board, 24 VDSL2/ISDN/Service Board
SKU: H83D00VDTH01
Rating: 4 (1 reviews)

Brand: Huawei
Model: H83D00VDTH01

Rating:

80%

4/5.0

1 Review

11 Questions

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Talk to an Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

H83D00VDTH01, Huawei H83D00 Series VDSL2 Service Board, 24 VDSL2/ISDN/Service Board

100% Genuine Ready to Ship

Overview

Huawei H83D00VDTH01 Overview

The Huawei H83D00VDTH01 is a carrier-grade VDSL2/ISDN service board for the MA5616 multi-service access platform, ideal for FTTx and cable deployments in Asia, Europe, Africa, and North America. Providing 24 VDSL2 over ISDN ports and flexible network-side options including GPON and GE uplinks, it helps distributors, SMB integrators, and operators deliver high-speed broadband over existing copper. With –40°C to 65°C operating range, robust surge protection, and AC/DC power support, this module ensures reliable triple-play and business access services.

Product Highlights

24 ports

VDSL2 Lines

-40~65℃

Wide Temp

6kV/4kV

Surge Safe

Product Applications Scenarios

Service Providers

Enables carriers to deliver high-speed VDSL2 and legacy ISDN over copper, reducing last-mile upgrade costs by up to 40% versus full fiber rebuilds.

Enterprise Network

Supports multi-service access to branch offices, combining VDSL2, E1, and ISDN to simplify WAN aggregation and cut infrastructure complexity by 30%.

Public Infrastructure

Ideal for municipal and campus networks using existing copper, providing robust broadband with 6 kV surge protection to improve uptime significantly.

Product Features Comparison


Model	H83D00VDTH01	H83D00UP2AA1	H83D0008E101	SU2DFF18S200
Brand	Huawei	Huawei	Huawei	Huawei
Module Type	24-port VDSL2 over ISDN Service Board	EPON/GPON/GE TypeC Uplink Interface Card	8-Port E1 Interface Unit Board	Switch Module
Port Configuration	24 VDSL2/ISDN	2×EPON/GPON/GE TypeC	8×E1	18×FE RJ45, 2×GE SFP
Supported Speed	ADSL2+, VDSL2, FE, GE	GPON/GE uplink	2.048Mbps	FE/GE
Compatible Platform	MA5616	MA5616	Huawei Network Systems	Huawei switches/routers
Installation Type	Service board	Uplink interface card	Standard slot in Huawei chassis	Rack-mountable

Optional Add-ons

Model Number	Description
H83D00UP2AA1	Huawei MA5616 EPON/GPON/GE TypeC uplink interface card for fiber or GE aggregation with H83D00VDTH01.
H83D0008E101	Huawei 8-port E1 interface board to extend TDM E1 services alongside VDSL2 access on MA5616.
SU2DFF18S200	Huawei 18×FE RJ45/2×GE SFP switch module for downstream aggregation of VDSL2 CPE or customer routers.

Quality Certifications

Specification

Huawei H83D00VDTH01 Specification

Model

H83D00VDTH01

Brand

Huawei

Part Number

03020QGG

Product Description

24-port VDSL2 over ISDN Service Board

Product Series

MA5616

Dimensions (H x W x D)

88.1mm x 442mm x 245mm

Operating Environment

–40°C to 65°C 5% RH to 95% RH

Power

AC: 110V/220V DC: –48V

Network-side Ports

Available configuration modes: CCUE: GPON/GE, 1 x GE (electrical or optical) CCUD: 1 x GPON, 1 x GE (electrical)

User-side Ports

ADSL2+, VDSL2, POTS, G.SHDSL, E1, ISDN, FE, and GE

Surge Protection

Power: 6 kV GE/FE: 4 kV POTS: 4 kV

Sub Product Family

FTTx and Cable

UOM

PCS

Get more information

Discover unbeatable prices and fast shipping for the H83D00VDTH01, Huawei H83D00 Series VDSL2 Service Board, 24 VDSL2/ISDN/Service Board . Access the detailed H83D00VDTH01, Huawei H83D00 Series VDSL2 Service Board, 24 VDSL2/ISDN/Service Board datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

Quality Certifications

Need Help? Technical Experts Available Now.

+1-626-655-0998 (USA)
UTC 15:00-00:00
+852-2592-5389 (HK)
UTC 00:00-09:00
+852-2592-5411 (HK)
UTC 06:00-15:00

Get a Quote

Live Chat

Need Help? Technical Experts Available Now.

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

What accessories are available for the H83D00VDTH01?

Accessories include compatible power supplies, mounting brackets, and network cables specifically designed for Huawei VDSL2 boards.

How does the H83D00VDTH01 compare to similar products?

The H83D00VDTH01 stands out with its superior ISDN VDSL2 support and cost-efficiency compared to other similar service boards.

How to use the H83D00VDTH01 effectively?

Maximize usage by configuring the board through Huawei's interface, monitoring its performance, and regularly updating its firmware for peak efficiency.

Are the products sold on router-switch.com authentic?

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.

Learn More

How cost-effective is the H83D00VDTH01?

The H83D00VDTH01 offers advanced VDSL2 over ISDN capabilities at a competitive price, enhancing your network's efficiency without breaking the budget.

What are the main characteristics of the H83D00VDTH01?

The H83D00VDTH01 features 24 VDSL2 ports over ISDN, delivering high-speed data transfer rates and robust network performance.

What is the application scenario for the H83D00VDTH01?

The H83D00VDTH01 is ideal for service providers requiring high-speed internet services over existing ISDN lines, especially in regions with minimal fiber infrastructure.

How do I install the H83D00VDTH01?

Installation involves integrating the H83D00VDTH01 into your existing network infrastructure and configuring it via Huawei's network management software.

Does the H83D00VDTH01 require any upgrades?

The H83D00VDTH01 may need firmware updates to ensure optimal performance and security. Regularly check for updates from Huawei.

Are there alternative products to the H83D00VDTH01?

Alternatives include other VDSL2 service boards in the Huawei product lineup, like the H83D00VDFH02, with varying port configurations and features.

What common troubleshooting steps are there for the H83D00VDTH01?

Common steps include verifying cable connections, resetting the board, and updating the firmware for resolution of most issues.
