    Juniper EX2300-48T Overview

    The EX2300-48T is a compact 1RU non-PoE access switch with 48 10/100/1000BASE-T ports and four 1/10GbE SFP/SFP+ uplinks. It delivers 176 Gbps bidirectional packet switching and 130 Mpps throughput for branch offices, retail, workgroups, and enterprise access-layer networks.

    Key Specifications

    Access Ports

    48 × 10/100/1000BASE-T, non-PoE

    SFP/SFP+ Uplinks

    4 × 1/10GbE

    Packet Switching Capacity

    88 Gbps unidirectional / 176 Gbps bidirectional

    L2/L3 Throughput

    130 Mpps

    Form Factor and Airflow

    1RU; front-to-back airflow

    Virtual Chassis

    Up to 4 switches


    Figure 1 shows the official front-panel layout of the Juniper EX2300-48T Ethernet switch.

    Juniper EX2300-48T front panel with 48 Gigabit Ethernet ports, four 1/10GbE SFP/SFP+ uplinks, console port, status LEDs, and reset button

    The official EX2300 front-panel diagram shows the 48 RJ-45 Gigabit Ethernet ports, four 1/10GbE SFP/SFP+ uplinks, Mini-USB console port, status indicators, and Factory Reset/Mode button. The EX2300-48T is a non-PoE model.

    ① RJ-45 network ports
    ② Chassis status LEDs
    ③ Port status mode LEDs; the PoE LED is present only on PoE-capable models
    ④ Factory Reset/Mode button
    ⑤ Mini-USB console port
    ⑥ 10-Gigabit Ethernet uplink ports


    Figure 2 shows the official rear-panel layout of the Juniper EX2300-48T Ethernet switch.

    Juniper EX2300-48T rear panel with USB port, management port, RJ-45 console port, grounding point, ESD point, labels, ventilation, and AC power inlet

    The official EX2300 rear-panel diagram shows the USB port, management Ethernet port, RJ-45 console port, protective earthing terminal, ESD point, air exhaust opening, identification labels, and AC power cord inlet.

    ① USB Type-A port
    ② RJ-45 management Ethernet port
    ③ RJ-45 console port
    ④ Protective earthing terminal
    ⑤ ESD point
    ⑥ Air exhaust opening
    ⑦ Serial number identification label
    ⑧ CLEI code label
    ⑨ AC power cord inlet

    Best Fit Applications

    Branch and Remote Office Access

    Branch and Remote Office Access

    The 1RU EX2300-48T provides 48 non-PoE Gigabit Ethernet ports and four 1/10GbE uplinks for compact branch and remote-office access networks.

    Retail and Workgroup Networks

    Retail and Workgroup Networks

    The EX2300-48T is designed for retail locations, workgroups, and other small network environments where compact installation and low power consumption are important.

    Enterprise Access-Layer Networks

    Enterprise Access-Layer Networks

    With 48 Gigabit Ethernet access ports, four 1/10GbE SFP/SFP+ uplinks, Junos OS, and Layer 2/Layer 3 switching, the EX2300-48T supports enterprise campus access-layer deployments.

    Virtual Chassis Deployments

    Virtual Chassis Deployments

    Up to four EX2300 switches can be connected in a Virtual Chassis configuration to simplify management and provide a scalable access-layer deployment.

    Compare Related Models


    EX2300-48T EX2300-48T
    Access Ports 48 × 1G RJ45 24 × 1G RJ45 24 × 1G RJ45 48 × 1G RJ45
    PoE Not supported Not supported PoE+ PoE+
    PoE Power per Port Not applicable Not applicable Up to 30W Up to 30W
    SFP/SFP+ Uplinks 4 × 1/10GbE 4 × 1/10GbE 4 × 1/10GbE 4 × 1/10GbE
    Packet Switching Capacity 88/176 Gbps 64/128 Gbps 64/128 Gbps 88/176 Gbps
    L2/L3 Throughput 130 Mpps 95 Mpps 95 Mpps 130 Mpps
    Virtual Chassis Up to 4 switches Up to 4 switches Up to 4 switches Up to 4 switches
    Recommended Use High-density non-PoE access Lower-density non-PoE access Access with PoE devices High-density PoE access

    System Compatible Components

    Type Part Number Description
    Rack Mounting Kits EX-RMK EX Series rack mount kit for EX2300 switches
    EX-4PST-RMK Four-post adjustable rack mount kit for EX2300 switches
    EX-WMK Wall mount kit for EX2300 switches
    Type Part Number Description
    Power Cables CBL-EX-PWR-C13-CH EX Series AC power cable with China plug and C13 connector
    CBL-EX-PWR-C13-EU EX Series AC power cable with European plug and C13 connector
    CBL-EX-PWR-C13-C14 C13-to-C14 AC power cable, 10A/250V, 2.5m

    Quality Certifications

    • ISO 14001
    • ISO 9001
    • RoHS
    • REACH
    • CE
    • FCC
    Specification

    Juniper EX2300-48T Specification

    Product Information
    Product Code EX2300-48T
    Product Description Juniper EX2300 Ethernet Switch, 48-Port Non-PoE
    Product Type Fixed 1RU Ethernet access switch
    Product Positioning Branch, retail, workgroup, and enterprise access-layer switching
    Operating System Junos OS
    First Supported Junos Release Junos OS 15.1X53-D55
    Ports and Interfaces
    Access Ports 48 × 10/100/1000BASE-T RJ-45
    PoE Not supported
    Uplink Ports 4 × 1/10GbE SFP/SFP+
    Supported Optical Interfaces 1000BASE-T, 1000BASE-SX, 1000BASE-LX, 1000BASE-LH
    Management Port 1 × RJ-45 management Ethernet port
    Console Ports 1 × RJ-45 console port and 1 × Mini-USB Type-B console port
    USB Port 1 × USB Type-A port
    Optics Requirement SFP/SFP+ transceivers sold separately
    Performance and Switching
    Packet Switching Capacity 88 Gbps unidirectional / 176 Gbps bidirectional
    L2/L3 Throughput 130 Mpps
    MAC Address Table 16,000
    VLAN IDs 4,093
    Active VLANs Up to 2,044 according to the reviewed datasheet
    Jumbo Frames 9,216 bytes
    QoS Queues 8 unicast queues per port
    Virtual Chassis Interconnect 80 Gbps
    Virtual Chassis Scale Up to 4 switches
    LAGs 128
    Ports per LAG 8
    MSTP Instances 64
    VSTP Instances 253
    Port Mirroring Sessions 4
    Destination VLANs 1
    Destination Ports 4
    Routing and Address Tables
    IPv4 Unicast Host Routes 4.096K
    IPv4 RIB Routes 0.512K
    IPv4 Multicast Routes 2.048K
    IPv6 Unicast Host Routes 2.048K
    IPv6 RIB Routes 0.512K
    IPv6 Multicast Routes 1.024K
    IPv6 Neighbor Discovery Entries 1.5K
    ARP Entries 1.5K
    Access Control Lists
    Ingress VLAN ACL 256
    Ingress Port ACL 256
    Ingress Routed ACL 256
    Egress VLAN ACL 256
    Egress Port ACL 256
    Egress Routed ACL 512
    Power and Cooling
    Power Supply 1 fixed AC power supply
    Maximum AC Power Consumption 70W
    Airflow Direction Front-to-back
    Fans 2 fixed fans
    Acoustic Noise Maximum 34.6 dB
    Mechanical Specifications
    Form Factor 1RU
    Height 1.75 in. / 4.445 cm
    Width 17.4 in. / 44.196 cm
    Depth 10.2 in. / 25.908 cm
    Chassis Weight 8.28 lb. / 3.76 kg
    Rack Installation Supported with optional rack mounting kits
    Wall Installation Supported with optional wall mount kit
    Environmental Specifications
    Operating Temperature 32° to 113°F / 0° to 45°C
    Storage Temperature –40° to 158°F / –40° to 70°C
    Operating Humidity 10% to 85% noncondensing
    Nonoperating Humidity 0% to 95% noncondensing
    Operating Altitude Up to 13,000 ft. / 3,962 m
    Nonoperating Altitude Up to 15,000 ft. / 4,572 m
    Seismic Rating Zone 4
    Maintenance Clearance 30 in. / 76.2 cm
    Standards and Certifications
    Safety Certifications UL-UL60950-1, C-UL CAN/CSA 22.2 No. 60950-1, TUV/GS EN60950-1, CB IEC60950-1, EN60825-1
    EMC FCC 47 CFR Part 15 Class A, EN55022 Class A, ICES-003, VCCI Class A, AS/NZS CISPR22 Class A, CISPR22 Class A, EN55024, EN300386, CE
    Environmental Compliance RoHS6
    Product Identification CLEI
    Quality Standard TL9000
