H802SCUB01, Huawei MA5600T Board, 1xH802SCUB/with H801CKMC/1 slot

100% Genuine Ready to Ship

Overview

Huawei H802SCUB01 Overview

The Huawei H802SCUB01 is a carrier-grade service control and uplink board for MA5600T series multi-service access platforms. Designed for high-density broadband and voice aggregation, it delivers 3.2 Tbit/s backplane switching capacity and flexible 10 GE uplink options for operators and large enterprises. With extensive access capacity for ADSL2+, VDSL2, GPON, 10G GPON, POTS, and ISDN, this module enables scalable FTTx and xDSL deployments across MA5600T and MA5603T chassis. Its wide operating temperature and robust clock synchronization suit central office and outdoor cabinets.

Product Highlights

3.2 Tbit/s

Backplane Cap

1,024xADSL

High Density

128x10G

10G GPON

Product Applications Scenarios

Service Providers

Supports large-scale FTTx and xDSL aggregation on MA5600T, simplifying CO access, reducing per-line costs by up to 30% through high-density GPON, 10G GPON, and legacy voice integration.

Enterprise Network

Enables converged voice and broadband for campuses and business parks, combining POTS, ISDN, and high-speed internet to cut multi-box deployments and streamline maintenance by about 25%.

Public Infrastructure

Ideal for municipal and utility networks requiring mixed legacy telephony and IP access, using robust temperature tolerance to lower field cabinet visits and downtime by nearly 20%.

Product Features Comparison


Model	H802SCUB01, Huawei MA5600T Board, 1×H802SCUB/with H801CKMC/1 slot	TN51ROP01, Huawei TN51ROP Series Optical Transmission Board, C-Band/Extended C-Band support/Remote Optical Pump	E8KE-X-101-1X40GE-CFP, Huawei E8KE-X Switch Module, 1×40G CFP/Occupy 2 sub-slots/Flexible card	CR5D00L2XX60, Huawei Router Module, 2×10GBase LAN/WAN-XFP/1 sub-slot/CP100
Brand	Huawei	Huawei	Huawei	Huawei
Module Type	n/a	n/a	n/a	n/a
Port Configuration	n/a	n/a	Port	Number of Ports
Supported Speed	n/a	n/a	Data Rate	Data Rate
Compatible Platform	n/a	n/a	Compatibility	Compatible Series
Installation Type	n/a	n/a	Form Factor	Installation

Optional Add-ons

Model Number	Description
H801CKMC	Huawei control and clock motherboard used together with H802SCUB01 in MA5600T chassis.
GPFD	Huawei MA5600T GPON interface card for adding GPON service ports to the same platform.
ADLE	Huawei MA5600T ADSL2+ service board for high-density copper broadband access.

Quality Certifications

Specification

Huawei H802SCUB01 Specification

Model

H802SCUB01

Brand

Huawei

Specifications

MA5600T(ETSI)

MA5600T(IEC)

MA5603T

Dimensions (H x W x D)

490mm x 275.8mm x 447.2mm

442 mm x 275.8 mm x 441.7 mm

442mm x 283.2mm x 263.9mm

Operating Environment

–25°C to 55°C 5% RH to 95% RH

–40°C to 65°C 5% RH to 95% RH

Switching Capacity — Backplane Bus

3.2 Tbit/s

1.5 Tbit/s (H801MABO) 2 Tbit/s (H802MABO)

720 Gbit/s

Access Capacity

1,024 x ADSL2+ 1,024 x VDSL2 512 x EFM SHDSL 256 x TDM SHDSL 1,024 x POTS 512 x ISDN BRA 64 x ISDN PRA 128 x 10G GPON 256 x GPON 768 x P2P FE 768 x P2P GE

896 x ADSL2+ 896 x VDSL2 448 x EFM SHDSL 224 x TDM SHDSL 896 x POTS 448 x ISDN BRA 56 x ISDN PRA 112 x 10G GPON 224 x GPON 672 x P2P FE 672 x P2P GE

384 x ADSL2+ 384 x VDSL2 192 x EFM SHDSL 96 x TDM SHDSL 384 x POTS 192 x ISDN BRA 64 x ISDN PRA 96 x 10G GPON 48 x GPON 288 x P2P FE 288 x P2P GE

Port Types

Upstream ports: 10 GE optical and GE optical/electrical ports Service ports: 10G GPON optical port, GPON optical port, P2P FE optical port, P2P GE optical port, and Ethernet optical port, ADSL2+ port, VDSL2 port, SHDSL port, POTS port, and ISDN port

System Performance

Layer 2/Layer 3 line-rate forwarding Static route, RIP, OSPF, and MPLS Clock synchronization schemes: BITS, E1, STM-1, Ethernet clock synchronization, 1588v2, and 1PPS + ToD GPON maximum split ratio of 1:128 10G PON maximum split ratio of 1:256 GPON maximum logical distance between devices: 60 km XG PON maximum logical distance between devices: 100 km

Get more information

Discover unbeatable prices and fast shipping for the H802SCUB01, Huawei MA5600T Board, 1×H802SCUB/with H801CKMC/1 slot . Access the detailed H802SCUB01, Huawei MA5600T Board, 1×H802SCUB/with H801CKMC/1 slot datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

Quality Certifications

Need Help? Technical Experts Available Now.

+1-626-655-0998 (USA)
UTC 15:00-00:00
+852-2592-5389 (HK)
UTC 00:00-09:00
+852-2592-5411 (HK)
UTC 06:00-15:00

Get a Quote

Live Chat

Need Help? Technical Experts Available Now.

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

What accessories are available for the H802SCUB01?

Accessories may include compatible cables, additional sub-boards, and power supply units designed for the MA5600T series.

How does the H802SCUB01 compare to other boards in the MA5600T series?

The H802SCUB01 offers unique features with its 1*1 configuration and H801CKMC sub-board, setting it apart in functionality and efficiency.

Can the H802SCUB01 be used with other Huawei products?

Yes, the H802SCUB01 can be integrated within the broader Huawei ecosystem, especially with devices in the MA5600T series.

Are the products sold on router-switch.com authentic?

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.

Learn More

How cost-effective is the H802SCUB01?

The H802SCUB01 offers high performance at a competitive price, making it cost-effective for large-scale deployments.

What are the main features of the H802SCUB01?

The H802SCUB01 includes 1*1 configuration and integrates the H801CKMC sub-board, providing robust connectivity and management.

What applications is the H802SCUB01 suitable for?

The H802SCUB01 is ideal for use in Huawei MA5600T series setups, enhancing connectivity and network management capabilities.

How do I install the H802SCUB01?

Installation involves integrating the H802SCUB01 module into the Huawei MA5600T chassis and connecting the necessary cables.

Does the H802SCUB01 require upgrading?

Regular firmware updates may be needed for optimal performance, which can be downloaded from Huawei's support site.

Are there alternative products to the H802SCUB01?

Alternatives include other boards in the Huawei MA5600T series, yet H802SCUB01 remains a top choice for its specific configuration.

What common troubleshooting steps are there for the H802SCUB01?

Common steps include checking connections, verifying power supply, and ensuring the latest firmware is installed.
