H801MCUE, Huawei MA5600T Board, Main Control Unit, GE Uplink, Super Control

100% Genuine Ready to Ship

Overview

Huawei H801MCUE Overview

The Huawei H801MCUE is a carrier-grade main control unit board for MA5600T OLT platforms, delivering high-capacity GPON and P2P access aggregation with GE uplink connectivity. It offers 720 Gbit/s backplane switching capacity, rich upstream and service port types, and robust dual-power protection for reliable deployment across diverse environments from –40°C to 65°C. Supporting Layer 2/Layer 3 line-rate forwarding and multiple clock synchronization schemes, the H801MCUE is ideal for service providers and integrators building scalable fiber access networks.

Product Highlights

720 Gbit/s

Backplane Cap

16x10G

10G GPON

1:256

10G Split

Product Applications Scenarios

Service Providers

H801MCUE aggregates large-scale GPON and P2P access, enabling carriers to deliver triple-play and business VPN services while cutting central office footprint and easing multi-site rollout.

Enterprise Network

Deployed as the core of campus fiber access, the board supports Layer 2/Layer 3 line-rate forwarding to consolidate branch traffic, simplify management, and improve service reliability.

Public Infrastructure

In municipal or utility networks, H801MCUE delivers resilient broadband backbones across harsh climates, supporting long-distance GPON to reduce cabinet sites and maintenance visits.

Product Features Comparison


Model	H801MCUE, Huawei MA5600T Board, Main Control Unit, GE Uplink, Super Control	H805GPFD03, Huawei H805GPFD Series OLT Interface Board, 16-port GPON, ClassC+ SFP, Optical Module Included	LE0MSRUA, Huawei S9300 Switch, Main Control Unit A/High reliability/Hot swappable	SSJ1JCOM, Huawei SSJ1J Series System Communication Board, Communication module
Brand	Huawei	Huawei	Huawei	Huawei
Module Type	n/a	n/a	Main Control Unit	System Communication Board
Port Configuration	16 x 10G GPON 48 x GPON 96 x P2P FE 96 x P2P GE	1,024 x ADSL2+ 1,024 x VDSL2 512 x EFM SHDSL 256 x TDM SHDSL 1,024 x POTS 512 x ISDN BRA 64 x ISDN PRA 128 x 10G GPON 256 x GPON 768 x P2P FE 768 x P2P GE	Multiple GE/10GE Ports	4 x 10G SFP+
Supported Speed	n/a	n/a	High Performance	10Gbps
Compatible Platform	n/a	MA5600T(ETSI) MA5600T(IEC) MA5603T	S9306/S9312 Series	n/a
Installation Type	n/a	n/a	Plug-in Module	Rack-mountable

Optional Add-ons

Model Number	Description
H805GPFD03	Huawei MA5600T-series 16-port GPON OLT interface board with Class C+ SFP optics for high-density fiber access.
H80D00VDQM01	Huawei MA5800 VDSL2/ISDN service board providing 64 VDSL2 ports to extend copper-based broadband from the OLT.
H901GPHF03	Huawei MA5800-X7 16-port advanced GPON OLT interface board with integrated Class B+ SFP optical modules.

Quality Certifications

Specification

Huawei H801MCUE Specification

Model

H801MCUE

Brand

Huawei

Dimensions (H x W x D)

442mm x 244.5mm x 88.1mm

Operating Environment

–40°C to 65°C 5% RH to 95% RH

Power Supply

Dual-power supply protection DC power supply: -38.4V to -72V AC power supply: 100V to 240V

Switching Capacity — Backplane Bus

720 Gbit/s

Access Capacity

16 x 10G GPON 48 x GPON 96 x P2P FE 96 x P2P GE

Port Types

Upstream ports: 10 GE optical and GE optical/electrical ports Service ports: 10G GPON optical port, GPON optical port, P2P FE optical port, P2P GE optical port, and Ethernet optical port, ADSL2+ port, VDSL2 port, SHDSL port, POTS port, and ISDN port

System Performance

Layer 2/Layer 3 line-rate forwarding Static route, RIP, OSPF, and MPLS Clock synchronization schemes: BITS, E1, STM-1, Ethernet clock synchronization, 1588v2, and 1PPS + ToD GPON maximum split ratio of 1:128 10G PON maximum split ratio of 1:256 GPON maximum logical distance between devices: 60 km XG PON maximum logical distance between devices: 100 km

Get more information

Discover unbeatable prices and fast shipping for the H801MCUE, Huawei MA5600T Board, Main Control Unit, GE Uplink, Super Control . Access the detailed H801MCUE, Huawei MA5600T Board, Main Control Unit, GE Uplink, Super Control datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

Quality Certifications

Need Help? Technical Experts Available Now.

+1-626-655-0998 (USA)
UTC 15:00-00:00
+852-2592-5389 (HK)
UTC 00:00-09:00
+852-2592-5411 (HK)
UTC 06:00-15:00

Get a Quote

Live Chat

Need Help? Technical Experts Available Now.

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

How does the H801MCUE compare with similar products?

The H801MCUE offers superior GE uplink performance and integrates seamlessly with Huawei's extensive range of networking equipment.

What are common troubleshooting steps for the H801MCUE?

Common troubleshooting includes checking cable connections, ensuring firmware is up-to-date, and verifying network configurations.

Can the H801MCUE be used in large-scale network deployments?

Yes, the H801MCUE is designed to support large-scale networks, providing robust control and management capabilities.

Are the products sold on router-switch.com authentic?

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.

Learn More

How cost-effective is the H801MCUE Super Control Unit Board?

The H801MCUE is highly cost-effective due to its advanced features and reliable GE uplink, making it suitable for various network integration needs.

What are the main features of the H801MCUE?

The H801MCUE offers a GE uplink, efficient data processing, and seamless integration with other Huawei products, ensuring robust network performance.

What are the common application scenarios for H801MCUE?

The H801MCUE is ideal for enterprise network management, Internet Service Providers, and data center environments.

How do I install the H801MCUE Super Control Unit Board?

Installation involves securely mounting the H801MCUE into compatible Huawei chassis and configuring the software settings as per the user manual.

Does the H801MCUE require regular upgrades?

Periodic firmware updates are recommended to ensure optimal performance and security for the H801MCUE.

Are there any alternative products to the H801MCUE?

Alternatives to the H801MCUE include other Huawei control units such as the H801MAIA, depending on specific network requirements.

What are the available accessories for the H801MCUE?

Accessories for the H801MCUE include GE transceivers, compatible Huawei chassis, and mounting brackets.
