S5310-52C-EI, Huawei S5310 Switch, 48xGE RJ45/4x10GE SFP+/Dual Power Slots

Product Code

S5310-52C-EI

Maximum stack

bandwidth

(bidirectional)

160 Gbit/s

Stack ports

Four fixed 10GE SFP+ ports on the front panel or ports on the 2-port 10GE rear card

Mean time between

failures (MTBF)

45.57 years when a 8xGE optical interface card is configured; 44.85 years when a 8xGE electrical interface card is configured; 43.33 years when a 2x10GE interface card is configured

Memory

512 MB

Flash

200 MB

Available Version

V200R002C00 to V200R005C02

NOTE: These chassis models are not supported in V200R003C02 and V200R005C01.

Maximum system

power consumption

(100% throughput,

full speed of fans)

146.9 W

Dimensions (W x D x H)

442.0 mm x 420.0 mm x 43.6 mm When a 1150 W power module is installed, it extrudes out from the chassis. Therefore, the total depth of the switch changes to 507.3 mm

Weight

Fully loaded ≤ 10 kg

Empty ≤ 6 kg

①

Forty-eight 10/100/1000BASE-T Ethernet electrical ports

②

Four 10GE SFP+ Ethernet optical ports

Applicable modules and cables:

• ● GE optical module
• ● GE-CWDM optical module
• ● GE-DWDM optical module
• ● GE SFP copper module
• ● 10GE SFP+ optical module
• ● 10GE-CWDM optical module (applicable in V200R005C00 and later versions)
• ● 1 m, 3 m, 10 m SFP+ copper cables
• ● 3 m, 10 m AOC cables(applicable in V200R003C00 and later versions)

③

One ETH management port

④

One Mini USB port

⑤

One console port

⑥

One USB port

①

Ground screw

NOTE: It is used with a ground cable.

②

RCard slot 1

NOTE: For details about the mapping between cards and switches, see Cards.

③

Card slot 2

NOTE: For details about the mapping between cards and switches, see Cards.

④

Bar code label

NOTE: This label is drawable, and you can pull it outward to view the bar code and MAC address of the switch.

⑤

Power module slot 2

NOTE: Available power modules: l 150 W AC Power Module l 150 W DC Power Module

⑥

Power module slot 1

NOTE: Available power modules: l 150 W AC Power Module l 150 W DC Power Module

Model

Description

FE-SFP Optical Transceiver

SFP-FE-SX-MM1310

Optical Transceiver, SFP, 100M/155M, Multi-mode Module(1310nm, 2km, LC)

eSFP-FE-LX-SM1310

Optical Transceiver, eSFP, 100M/155M, Single-mode Module(1310nm, 15km, LC)

S-SFP-FE-LH40-SM1310

Optical Transceiver, eSFP, FE, Single-mode Module(1310nm, 40km, LC)

GE-SFP Optical Transceiver

eSFP-GE-SX-MM850

Optical Transceiver, eSFP, GE, Multi-mode Module(850nm, 0.55km, LC)

SFP-GE-LX-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module(1310nm, 10km, LC)

S-SFP-GE-LH40-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module(1310nm, 40km, LC)

S-SFP-GE-LH40-SM1550

Optical Transceiver, eSFP, GE, Single-mode Module(1550nm, 40km, LC)

10G-SFP+ Optical Transceiver

SFP-10G-USR

10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module(850nm, 0.1km, LC)

OMXD30000

Optical Transceiver, SFP+, 10G, Multi-mode Module(850nm, 0.3km, LC)

OSX010000

Optical Transceiver, SFP+, 10G, Single-mode Module(1310nm, 10km, LC)

GE Copper Transceiver

SFP-1000BaseT

Electrical Transceiver, SFP, GE, Electrical Interface Module(100m, RJ45)

Product Code

S5310-52C-EI

S5300-28X-LI-24S-AC

Mean time between

failures (MTBF)

45.57 years when a 8xGE optical interface card is configured; 44.85 years when a 8xGE electrical interface card is configured; 43.33 years when a 2x10GE interface card is configured

89.91 years

Memory

512 MB

256 MB

Flash

200 MB

200 MB

Power

consumption

146.9 W

<54W

Dimensions (W x D x H)

442.0 mm x 420.0 mm x 43.6 mm When a 1150 W power module is installed, it extrudes out from the chassis. Therefore, the total depth of the switch changes to 507.3 mm

442 mm x 220 mm x 43.6 mm

Weight

Fully loaded ≤ 10 kg

Empty ≤ 6 kg

≤ 5 kg
