Huawei CH242 V3 Compute Node

Huawei FusionServer CH242 V3 Compute Node foe E9000, Intel Xeon E7-4800/8800 V2/V3 series CPU, RAID, 32 DDR4 DIMMs S-ERVER

Overview
Specification
Reviews
Q&A
Warranty
Download
Stable Global Supply Chain for Thriving Businesses.
  • $4,000,000 Inventory
  • 500+ Reliable Vendors
  • Certified Partnerships
  • Collaborating with FedEx, UPS, DHL
100,000+ Diverse Products for All Your Needs
Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.
Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.
  • Projects and Technical Support
  • Easy Purchasing Supply
  • Product Lifecycle Protection
  • Exclusive F4 Team Support
Overview

Huawei CH242 V3 Compute Node Overview

Huawei FusionServer CH242 V3 Compute Node does more than you thought possible — large data sets and transaction-intensive databases such as Enterprise Resource Planning (ERP), Business Intelligence (BI) platforms, cloud computing, and virtualization. It’s powered by Intel Xeon processors. It features dynamic energy-saving and power-capping technologies that manage and control power consumption with remarkably reduced low-load operating power. Carrier-class design, manufacturing, and components ensure high quality.

Quick Specs

Figure 1 shows the appearance of Huawei CH242 V3 Compute Node.

The CH242 V3 has two types of specifications:

·CH242 V3 8HDD

Supports SAS HDDs, SATA HDDs, and SSDs, and provides two customized PCIe cards.

·CH242 V3 4HDD

Supports SAS HDDs, SATA HDDs, and SSDs, and provides one standard PCIe card of full-height, half-length and two customized PCIe cards.

Figure 1-1 CH242 V3 8HDD appearance.

CH242 V3 8HDD appearance

Figure 1-2 CH242 V3 4HDD appearance.

CH242 V3 4HDD appearance

Table 1 shows the Quick Specs.

Product Code

Huawei CH242 V3 Compute Node

Form Factor

Full-width 4-socket compute node

Number of Processors

2 or 4

Processor Models

Intel® Xeon® E7 v3/v4 series, up to 24-core processor

Number of DIMMs

32 DDR4 DIMMs, providing a maximum memory capacity of 2 TB

Number of Hard Disks

8 x 2.5-inch SAS/SATA HDDs, or SSDs, among them 4 slots support NVMe SSDs

RAID Support

RAID 0, 1, 10, 5, 50, 6, and 60 with a 1 GB RAID cache

PCIe Expansion

4 PCIe x 16 Mezz modules

Supports two FHHL PCIe cards. When the two built-in PCIe slots are used, some DIMM slots cannot be used

Operating Systems Support

Microsoft Windows Server 2008/2012

Red Hat Enterprise Linux

SUSE Linux Enterprise Server

Huawei FusionSphere

Citrix XenServer

VMware ESX

Operating Temperature

5°C to 40°C

Dimensions

Height: 60.46 mm (2.38 in.)

Width: 423 mm (16.65 in.)

Depth: 525 mm (20.67 in.)

Product Details

Figure 2 shows the front panel of Huawei CH242 V3 Compute Node.

Figure 2-1 CH242 V3 8HDD front panel.

CH242 V3 8HDD front panel

Note:

①

Customization label (with an ESN label)

②

High-density port

③

Power button/indicator

④

UID button/indicator

⑤

HLY indicator

⑥

Ejector lever

⑦

Spring

⑧

Hard disk

⑨

Hard disk active indicator

⑩

Hard disk fault indicator

Product model

–

–

Figure 2-2 CH242 V3 4HDD front panel.

CH242 V3 4HDD front panel

Note:

①

Customization label (with an ESN label)

②

High-density port

③

Power button/indicator

④

UID button/indicator

⑤

HLY indicator

⑥

Ejector lever

⑦

Spring

⑧

Hard disk

⑨

Hard disk active indicator

⑩

Hard disk fault indicator

Product model

–

–

Compare to Similar Items

Table 3 shows the comparison of Huawei CH242 V3 Compute Node, Huawei CH220 V3 I/O Expansion Compute Node, Huawei CH222 V3 Storage Compute Node and Huawei CH226 V3 Storage Expansion Compute Node.

Product Code

Huawei CH242 V3 Compute Node

Huawei CH220 V3 I/O Expansion Compute Node

Huawei CH222 V3 Storage Compute Node

Huawei CH226 V3 Storage Expansion Compute Node

Form Factor

Full-width 4-socket compute node

Full-width 2-socket compute node

Full-width 2-socket compute node

Full-width, 2-socket compute node

Number of Processors

2 or 4

1 or 2

1 or 2

1 or 2

Processor Model

Intel® Xeon® E7 v3/v4 series, up to 24-core processor

Intel® Xeon® E5-2600 v3/v4 series

Intel® Xeon® E5-2600 v3/v4 series

Intel® Xeon® E5-2600 v3/v4 series

Number of DIMMs

32 DDR4 DIMMs, providing a maximum memory capacity of 2 TB

16 DDR4 DIMMs, providing a maximum memory capacity of 1 TB

24 DDR4 DIMMs, providing a maximum memory capacity of 1.5 TB

24 DDR4 DIMMs, providing a maximum memory capacity of 1.5 TB

Number of Hard Disks

8 x 2.5-inch SAS/SATA HDDs, or SSDs, among them 4 slots support NVMe SSDs

2 x 2.5-inch SSDs, SAS HDDs, or SATA HDDs

15 x 2.5 in. SAS/SATA HDDs or SSDs

6 x 3.5 in. SAS/SATA HDDs, and 2 x 2.5 in. SAS/SATA HDDs or SSDs

Get more information

Do you have any question about the Huawei CH242 V3 Compute Node

Contact us now via Live Chat or [email protected].

Quality Certifications

  • ISO 14001
  • ISO 9001
  • RoHS
  • REACH
  • CE
  • FCC
Specification

Huawei CH242 V3 Compute Node Specification

Huawei CH242 V3 Compute Node Specifications

Form Factor

Full-width 4-socket compute node

Number of Processors

2 or 4

Processor Models

Intel® Xeon® E7 v3/v4 series, up to 24-core processor

Number of DIMMs

32 DDR4 DIMMs, providing a maximum memory capacity of 2 TB

Number of Hard Disks

8 x 2.5-inch SAS/SATA HDDs, or SSDs, among them 4 slots support NVMe SSDs

RAID Support

RAID 0, 1, 10, 5, 50, 6, and 60 with a 1 GB RAID cache

PCIe Expansion

4 PCIe x 16 Mezz modules

Supports two FHHL PCIe cards. When the two built-in PCIe slots are used, some DIMM slots cannot be used

Operating Systems Support

Microsoft Windows Server 2008/2012

Red Hat Enterprise Linux

SUSE Linux Enterprise Server

Huawei FusionSphere

Citrix XenServer

VMware ESX

Operating Temperature

5°C to 40°C

Dimensions

Height: 60.46 mm (2.38 in.)

Width: 423 mm (16.65 in.)

Depth: 525 mm (20.67 in.)

Quality Certifications

Q&A

Questions & Answers

What accessories are available for the Huawei CH242 V3 Compute Node?

Accessories include additional DDR4 DIMMs, RAID controllers, and compatible network adapters for expanded functionality.

How does the Huawei CH242 V3 Compute Node compare with similar products?

The CH242 V3 stands out with its support for Intel Xeon E7-4800/8800 V2/V3 CPUs and up to 32 DDR4 DIMMs, offering excellent performance at competitive pricing.

What RAID options are available for the Huawei CH242 V3 Compute Node?

The CH242 V3 supports various RAID configurations including RAID 0, 1, 5, and 10 to enhance data protection and performance.
