HG8M8010HEU4, Huawei HG8010H GPON Terminal, SC/APC, European Adapter, English

Brand: Huawei
Model: HG8M8010HEU4

$346.00

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

HG8M8010HEU4, Huawei HG8010H GPON Terminal, SC/APC, European Adapter, English

100% Genuine Ready to Ship

$346.00

Overview

Huawei HG8M8010HEU4 Overview

Huawei HG8M8010HEU4 is a compact GPON terminal designed for European FTTH deployments, delivering reliable 1GE access for residential and small business users. With support for Class B+ GPON optics, VLAN-based Ethernet services, and IPv6-transparent forwarding, this Huawei video terminal fits operator and ISP rollouts across Europe, Asia, and Africa. Low 3.5W max power consumption, MAC address filtering, and advanced OMCI-based O&M make it ideal for distributors, integrators, and end users seeking stable fiber CPE.

Product Highlights

1GE

Gig Port

3.5W

Low Power

-27dBm

GPON Optic

Product Applications Scenarios

Service Providers

Ideal as a GPON ONT for ISPs, the terminal simplifies mass FTTH rollouts, cutting installation time and reducing on-site maintenance visits by enabling remote OMCI-based diagnostics.

Enterprise Network

Used as a demarcation CPE in branch offices, it offers VLAN-aware 1GE access and QoS, helping enterprises prioritize critical traffic and lower WAN operation costs by up to 20%.

Edge & IoT

Deployed at industrial or smart-building edges, the unit provides stable fiber uplink for IoT gateways, while low power draw and MAC filtering enhance long-term, secure operation.

Product Features Comparison


Model	HG8M8010HEU4, Huawei HG8010H GPON Terminal, SC/APC, European Adapter, English	HG8M168010H, Huawei HG8010H GPON Terminal, SC/APC, European Standard Adapter, English Document	HG8M8010HUK1, Huawei HG8010H GPON Terminal, 1×GPON port/UK adapter/SC-APC	HG8M8010HEU5, Huawei HG8010H GPON Terminal, SC/APC, EU Adapter, For A1 Austria
Brand	Huawei	Huawei	Huawei	Huawei
Dimensions (H x W x D) (mm)	115 x 94 x 27 (V300R015C00 and earlier) 82 x 90 x 27 (V300R015C10)	115 x 94 x 27 (V300R015C00 and earlier) 82 x 90 x 27 (V300R015C10)	115 x 94 x 27 (V300R015C00 and earlier) 82 x 90 x 27 (V300R015C10)	115 x 94 x 27 (V300R015C00 and earlier) 82 x 90 x 27 (V300R015C10)
Operating temperature	0°C to +40°C	0°C to +40°C	0°C to +40°C	0°C to +40°C
Operating humidity	5% RH to 95% RH (non-condensing)	5% RH to 95% RH (non-condensing)	5% RH to 95% RH (non-condensing)	5% RH to 95% RH (non-condensing)
Power adapter input	100–240 V AC, 50–60 Hz	100–240 V AC, 50–60 Hz	100–240 V AC, 50–60 Hz	100–240 V AC, 50–60 Hz
System power supply	11–14 V DC, 0.5 A	11–14 V DC, 0.5 A	11–14 V DC, 0.5 A	11–14 V DC, 0.5 A
Static power consumption	3W	3W	3W	3W
Maximum power consumption	3.5W	3.5W	3.5W	3.5W
Ports	1GE	1GE	1GE	1GE
Indicators	POWER/PON/LOS/LAN	POWER/PON/LOS/LAN	POWER/PON/LOS/LAN	POWER/PON/LOS/LAN
GPON Port	• Class B+ • Receiver sensitivity: -27dBm • Wavelengths: US 1310 nm, DS 1490 nm • Wavelength blocking filter (WBF) • Flexible mapping between GEM Port and TCONT • GPON: consistent with the SN or password authentication defined in G.984.3 • Bi-directional FEC • SR-DBA and NSR-DBA	• Class B+ • Receiver sensitivity: -27dBm • Wavelengths: US 1310 nm, DS 1490 nm • Wavelength blocking filter (WBF) • Flexible mapping between GEM Port and TCONT • GPON: consistent with the SN or password authentication defined in G.984.3 • Bi-directional FEC • SR-DBA and NSR-DBA	• Class B+ • Receiver sensitivity: -27dBm • Wavelengths: US 1310 nm, DS 1490 nm • Wavelength blocking filter (WBF) • Flexible mapping between GEM Port and TCONT • GPON: consistent with the SN or password authentication defined in G.984.3 • Bi-directional FEC • SR-DBA and NSR-DBA	• Class B+ • Receiver sensitivity: -27dBm • Wavelengths: US 1310 nm, DS 1490 nm • Wavelength blocking filter (WBF) • Flexible mapping between GEM Port and TCONT • GPON: consistent with the SN or password authentication defined in G.984.3 • Bi-directional FEC • SR-DBA and NSR-DBA
Ethernet Port	• Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning • Transparent transmission of IPv6 packets at Layer 2	• Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning • Transparent transmission of IPv6 packets at Layer 2	• Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning • Transparent transmission of IPv6 packets at Layer 2	• Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning • Transparent transmission of IPv6 packets at Layer 2
Smart O&M	• Variable-length OMCI messages • Active/Passive rogue ONT detection and isolation • PPPoE/DHCP simulation testing	• Variable-length OMCI messages • Active/Passive rogue ONT detection and isolation • PPPoE/DHCP simulation testing	• Variable-length OMCI messages • Active/Passive rogue ONT detection and isolation • PPPoE/DHCP simulation testing	• Variable-length OMCI messages • Active/Passive rogue ONT detection and isolation • PPPoE/DHCP simulation testing
QoS	• Ethernet port rate limitation • 802.1p priority • SP/WRR/SP+WRR • Broadcast packet rate limitation • Flow mapping based on the VLAN ID, port ID, or/and 802.1p	• Ethernet port rate limitation • 802.1p priority • SP/WRR/SP+WRR • Broadcast packet rate limitation • Flow mapping based on the VLAN ID, port ID, or/and 802.1p	• Ethernet port rate limitation • 802.1p priority • SP/WRR/SP+WRR • Broadcast packet rate limitation • Flow mapping based on the VLAN ID, port ID, or/and 802.1p	• Ethernet port rate limitation • 802.1p priority • SP/WRR/SP+WRR • Broadcast packet rate limitation • Flow mapping based on the VLAN ID, port ID, or/and 802.1p
Power Saving	• Indicator power saving • Power consumption reduction of idle components in power-saving state • COCv4	• Indicator power saving • Power consumption reduction of idle components in power-saving state • COCv4	• Indicator power saving • Power consumption reduction of idle components in power-saving state • COCv4	• Indicator power saving • Power consumption reduction of idle components in power-saving state • COCv4
Security	• MAC address filtering	• MAC address filtering	• MAC address filtering	• MAC address filtering
Common O&M	• OMCI/Web UI • Dual-system software backup and rollback • 802.1ag Ethernet OAM • Optical link measurement and diagnosis • Loopback check	• OMCI/Web UI • Dual-system software backup and rollback • 802.1ag Ethernet OAM • Optical link measurement and diagnosis • Loopback check	• OMCI/Web UI • Dual-system software backup and rollback • 802.1ag Ethernet OAM • Optical link measurement and diagnosis • Loopback check	• OMCI/Web UI • Dual-system software backup and rollback • 802.1ag Ethernet OAM • Optical link measurement and diagnosis • Loopback check
Multicast	• IGMP v2/v3 snooping • MLD v1/v2 snooping • Fast leave • VLAN tag translation, transparent transmission, and removal for downstream multicast packets • IGMP/MLD protocol packet rate limitation	• IGMP v2/v3 snooping • MLD v1/v2 snooping • Fast leave • VLAN tag translation, transparent transmission, and removal for downstream multicast packets • IGMP/MLD protocol packet rate limitation	• IGMP v2/v3 snooping • MLD v1/v2 snooping • Fast leave • VLAN tag translation, transparent transmission, and removal for downstream multicast packets • IGMP/MLD protocol packet rate limitation	• IGMP v2/v3 snooping • MLD v1/v2 snooping • Fast leave • VLAN tag translation, transparent transmission, and removal for downstream multicast packets • IGMP/MLD protocol packet rate limitation
Routing Throughput	n/a	n/a	n/a	n/a
Interface Configuration	n/a	n/a	n/a	n/a
Supported Protocol	n/a	n/a	n/a	n/a
VPN Capability	n/a	n/a	n/a	n/a
Integrated Features	n/a	n/a	n/a	n/a

Optional Add-ons

Model Number	Description
HG8M028045A	Huawei HG8045A GPON Wi-Fi ONT, ideal companion CPE for extended home coverage
H35M8240HEU1	Huawei HG8240H GPON ONT with multiple GE and POTS ports for voice and data
HN8M038055Q	Huawei HN8M XG-PON terminal for future-proof 10G fiber access upgrades

Quality Certifications

Specification

Huawei HG8M8010HEU4 Specification

Model

HG8M8010HEU4

Brand

Huawei

Dimensions (H x W x D) (mm)

115 x 94 x 27 (V300R015C00 and earlier) 82 x 90 x 27 (V300R015C10)

Operating temperature

0°C to +40°C

Operating humidity

5% RH to 95% RH (non-condensing)

Power adapter input

100–240 V AC, 50–60 Hz

System power supply

11–14 V DC, 0.5 A

Static power consumption

Maximum power consumption

3.5W

Ports

1GE

Indicators

POWER/PON/LOS/LAN

GPON Port

• Class B+ • Receiver sensitivity: -27dBm • Wavelengths: US 1310 nm, DS 1490 nm • Wavelength blocking filter (WBF) • Flexible mapping between GEM Port and TCONT • GPON: consistent with the SN or password authentication defined in G.984.3 • Bi-directional FEC • SR-DBA and NSR-DBA

Ethernet Port

• Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning • Transparent transmission of IPv6 packets at Layer 2

Smart O&M

• Variable-length OMCI messages • Active/Passive rogue ONT detection and isolation • PPPoE/DHCP simulation testing

QoS

• Ethernet port rate limitation • 802.1p priority • SP/WRR/SP+WRR • Broadcast packet rate limitation • Flow mapping based on the VLAN ID, port ID, or/and 802.1p

Power Saving

• Indicator power saving • Power consumption reduction of idle components in power-saving state • COCv4

Security

• MAC address filtering

Common O&M

• OMCI/Web UI • Dual-system software backup and rollback • 802.1ag Ethernet OAM • Optical link measurement and diagnosis • Loopback check

Multicast

• IGMP v2/v3 snooping • MLD v1/v2 snooping • Fast leave • VLAN tag translation, transparent transmission, and removal for downstream multicast packets • IGMP/MLD protocol packet rate limitation

Get more information

Discover unbeatable prices and fast shipping for the HG8M8010HEU4, Huawei HG8010H GPON Terminal, SC/APC, European Adapter, English . Access the detailed HG8M8010HEU4, Huawei HG8010H GPON Terminal, SC/APC, European Adapter, English datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

Quality Certifications

Need Help? Technical Experts Available Now.

+1-626-655-0998 (USA)
UTC 15:00-00:00
+852-2592-5389 (HK)
UTC 00:00-09:00
+852-2592-5411 (HK)
UTC 06:00-15:00

Get a Quote

Live Chat

Need Help? Technical Experts Available Now.

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

What accessories are available for the HG8010H GPON Terminal?

Accessories include power adapters, fiber optic cables, and wall mounting brackets, depending on the deployment needs.

How does the HG8010H GPON Terminal compare with other similar products?

The HG8010H provides superior performance at a lower cost compared to similar GPON terminals in its category.

Is the HG8010H GPON Terminal easy to use?

Yes, the English interface and straightforward configuration process make it user-friendly for both professionals and end-users.

Are the products sold on router-switch.com authentic?

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.

Learn More

How cost-effective is the HG8010H GPON Terminal?

The HG8010H GPON Terminal offers great value with its high performance at a competitive price, making it ideal for budget-conscious system integrators.

What are the main characteristics of the HG8010H GPON Terminal?

The HG8010H features a GPON interface, European standard adapter, and supports SC/APC connectors, delivering reliable high-speed internet connectivity.

In what application scenarios is the HG8010H GPON Terminal used?

This terminal is perfect for residential broadband, small businesses, and FTTH (Fiber to the Home) deployments.

How do I install the HG8010H GPON Terminal?

Installation involves connecting the SC/APC fiber cable, plugging into the European standard adapter, and configuring the terminal via the browser interface.

Does the HG8010H GPON Terminal need regular upgrades?

Firmware updates may be required periodically to ensure improved security and functionality.

Are there alternative products to the HG8010H GPON Terminal?

Yes, alternatives include other Huawei GPON terminals like the HG8120H, depending on your specific requirements.

What are common troubleshooting steps for the HG8010H GPON Terminal?

Check fiber connections, restart the device, and ensure firmware is up to date. Refer to the user manual for detailed troubleshooting.
