Are the products sold on router-switch.com authentic?

Name: H35M8247HUS1, Huawei EchoLife HG8247H GPON Terminal, SC/APC, CATV, US Standard Adapter
SKU: H35M8247HUS1
Rating: 5 (1 reviews)

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

H35M8247HUS1, Huawei EchoLife HG8247H GPON Terminal, SC/APC, CATV, US Standard Adapter

Brand: Huawei
Model: H35M8247HUS1

Rating:

100%

5/5.0

1 Review

1 Questions

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Talk to an Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

H35M8247HUS1, Huawei EchoLife HG8247H GPON Terminal, SC/APC, CATV, US Standard Adapter

100% Genuine Ready to Ship

Overview

Huawei H35M8247HUS1 Overview

Huawei EchoLife HG8247H is a GPON home gateway designed for high-speed fiber access and triple-play services. It integrates a Class B+ GPON uplink, 4GE LAN ports, CATV RF output, dual POTS ports, IEEE 802.11 b/g/n Wi-Fi, and a USB2.0 port for network storage. With advanced Layer 3 features, IPv6/IPv4 dual stack, multicast over Wi-Fi, and powerful Smart O&M via OMCI/Web UI/TR069, it helps Asian, European, African, and North American ISPs, distributors, and SMB integrators deliver reliable FTTH, voice, and video services.

Product Highlights

18W

Max Power

4GE

GE Ports

2POTS

Voice FXS

Product Applications Scenarios

Service Providers

The integrated GPON, CATV, VoIP, and Wi‑Fi functions simplify FTTH CPE deployment, cutting truck rolls and reducing overall rollout costs by up to 25% for regional and national broadband operators.

Enterprise Network

Small offices use the HG8247H as a converged gateway, leveraging Layer 3, QoS, and VLAN features to prioritize voice and video, improving application performance and lowering WAN OPEX.

Media & Entertainment

High-quality multicast, CATV RF output, and stable Wi‑Fi ensure smooth IPTV and OTT streaming, reducing buffering incidents and enhancing end-user viewing satisfaction in FTTH deployments.

Product Features Comparison


Model	H35M8247HUS1, Huawei EchoLife HG8247H GPON Terminal, SC/APC, CATV, US Standard Adapter	H35M8247HTT1, Huawei EchoLife HG8247H Broadband Network Terminal, GPON, SC/APC, CATV	H35M8247HEU2, Huawei EchoLife HG8247H GPON Terminal, SC/APC, CATV, European Plug Adapter	H35M8242HRD1, Huawei EchoLife HG8242H GPON Terminal, SC/APC, CATV, European Plug Adapter
Brand	Huawei	Huawei	Huawei	Huawei
Routing Throughput	n/a	n/a	n/a	n/a
Interface Configuration	2POTS+4GE+CATV+Wi-Fi+USB	2POTS+4GE+CATV+Wi-Fi+USB	2POTS+4GE+CATV+Wi-Fi+USB	4GE + 2POTS + CATV
Supported Protocol	• PPPoE/Static IP/DHCP • NAT/NAPT • Port forwarding • ALG, UPnP • DDNS/DNS server/DNS client • IPv6/IPv4 dual stack • Static/Default routes • Multiple services on one WAN port	• PPPoE/Static IP/DHCP • NAT/NAPT • Port forwarding • ALG, UPnP • DDNS/DNS server/DNS client • IPv6/IPv4 dual stack • Static/Default routes • Multiple services on one WAN port	• PPPoE/Static IP/DHCP • NAT/NAPT • Port forwarding • ALG, UPnP • DDNS/DNS server/DNS client • IPv6/IPv4 dual stack • Static/Default routes • Multiple services on one WAN port	n/a
VPN Capability	n/a	n/a	n/a	n/a
Integrated Features	GPON, 4GE, 2POTS, CATV, Wi-Fi, USB, Smart Wi-Fi, Smart O&M	GPON, 4GE, 2POTS, CATV, Wi-Fi, USB, Smart Wi-Fi, Smart O&M	GPON, 4GE, 2POTS, CATV, Wi-Fi, USB, Smart Wi-Fi, Smart O&M	GPON, 4GE, 2POTS, CATV, Smart O&M

Optional Add-ons

Model Number	Description
GPON-SFP-B+	Huawei Class B+ GPON SFP uplink module for OLT connectivity
HW-ONT-STAND	Huawei desktop mounting stand kit for HG8247H series ONTs
HW-CATV-SPLIT	Huawei RF CATV splitter for distributing HG8247H CATV output to multiple TVs

Quality Certifications

Specification

Huawei H35M8247HUS1 Specification

Model

H35M8247HUS1

Brand

Huawei

Dimensions (H x W x D)

220mm x 160mm x 32mm (without an external antenna)

Operating temperature

0°C to 40°C

Operating humidity

5% RH to 95% RH (non-condensing)

Power adapter input

100–240 V AC, 50–60 Hz

System power supply

11–13 V DC, 2 A

Static power consumption

7.5W

Maximum power consumption

18W

Ports

2POTS+4GE+CATV+Wi-Fi+USB

Indicators

POWER/PON/LOS/LAN/TEL/USB/WLAN/WPS/CATV

GPON Port

• Class B+ • Receiver sensitivity: -27 dBm • Wavelengths: US 1310 nm, DS 1490 nm • WBF • Flexible mapping between GEM Port and TCONT • GPON: consistent with the SN or password authentication defined in G.984.3 • Bi-directional FEC • SR-DBA

Ethernet Port

• Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning

CATV Port

• Bandwidth 54-870MHz • Output resistance 75 ohms

POTS Port

• Maximum REN: 4 • G.711A/μ, G.729a/b, and G.722 encoding/decoding • T.30/T.38/G.711 fax mode • DTMF • Emergency calls (with the SIP protocol)

USB Port

• USB2.0 • FTP-based network storage

WLAN

• IEEE 802.11 b/g/n • 2 x 2 MIMO • Antenna gain: 2 dBi • WMM • Multiple SSIDs • WPS

Smart interconnection

• Smart Wi-Fi coverage (V300R015C10) • SIP/H.248 auto-negotiation • Any port any service • Parental control (V300R015C10) • L2/L3(IPv4) forwarding: 1G uplink, 2G downlink

Smart service

• Smart Wi-Fi sharing: Portal/802.1x authentication (V300R015C10) SoftGRE-based sharing (V300R015C10) • Association of one account with two POTS ports

Smart O&M

• Variable-length OMCI messages • Active/Passive rogue ONT detection and isolation • Call emulation, and circuit test and loop-line test • PPPoE/DHCP simulation testing • WLAN emulation

Layer 3 Features

• PPPoE/Static IP/DHCP • NAT/NAPT • Port forwarding • ALG, UPnP • DDNS/DNS server/DNS client • IPv6/IPv4 dual stack • Static/Default routes • Multiple services on one WAN port

Multicast

• IGMP v2/v3 proxy(V300R015C00) /snooping • MLD v1/v2 snooping • Multicast services through Wi-Fi

QoS

• Ethernet port rate limitation • 802.1p priority • SP/WRR/SP+WRR • Broadcast packet rate limitation

Security

• SPI firewall • Filtering based on MAC/IP/URL addresses

Common O&M

• OMCI/Web UI/TR069 • Dual-system software backup and rollback

Power Saving

• Dynamic power saving • Indicator power saving • Scheduled Wi-Fi shutdown (V300R015C00)

Weight

1000 kg
