Are the products sold on router-switch.com authentic?

Name: H35M8247HTT1, Huawei EchoLife HG8247H Broadband Network Terminal, GPON, SC/APC, CATV
SKU: H35M8247HTT1
Rating: 5 (2 reviews)

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

H35M8247HTT1, Huawei EchoLife HG8247H Broadband Network Terminal, GPON, SC/APC, CATV

Brand: Huawei
Model: H35M8247HTT1

Rating:

100%

5/5.0

2 Reviews

1 Questions

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Talk to an Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

H35M8247HTT1, Huawei EchoLife HG8247H Broadband Network Terminal, GPON, SC/APC, CATV

100% Genuine Ready to Ship

Overview

Huawei H35M8247HTT1 Overview

The Huawei EchoLife HG8247H is a carrier-grade broadband network terminal designed for FTTH triple-play services. This GPON video terminal integrates 4GE data ports, 2POTS voice ports, 2.4 GHz Wi-Fi, USB, and CATV, enabling operators and integrators across Asia, Europe, Africa, and North America to deliver high-speed internet, HD IPTV, and VoIP over a single optical fiber. With advanced Layer 3 features, multicast support, and smart O&M, it simplifies deployment for distributors while ensuring stable, secure access for end users.

Product Highlights

4GE

Gigabit Lan

2POTS

Voice Ports

18W

Max Power

Product Applications Scenarios

Service Providers

Integrated GPON, CATV, VoIP, and Wi-Fi let service providers deliver triple-play FTTH, cutting CPE counts and onsite visits.

Enterprise Network

Small offices use its 4GE, Wi-Fi, and voice ports to consolidate access, reducing wiring effort and WAN edge costs.

Media & Entertainment

Reliable multicast and CATV output enable smooth HD and IP video delivery, minimizing buffering and user churn.

Product Features Comparison


Model	H35M8247HTT1, Huawei EchoLife HG8247H Broadband Network Terminal, GPON, SC/APC, CATV	H35M8247HEU2, Huawei EchoLife HG8247H GPON Terminal, SC/APC, CATV, European Plug Adapter	H35M8247HVT1, Huawei EchoLife HG8247H Broadband Network Terminal, GPON/SC-APC/5dBi antenna	H35M8012HPT1, Huawei EchoLife HG8012H GPON Terminal, 1×GPON, SC/APC, European Plug Adapter
Brand	Huawei	Huawei	Huawei	Huawei
Routing Throughput	n/a	n/a	n/a	n/a
Interface Configuration	2POTS+4GE+CATV+Wi-Fi+USB	2POTS+4GE+CATV+Wi-Fi+USB	2POTS+4GE+CATV+Wi-Fi+USB	1GE + 1CATV
Supported Protocol	• PPPoE/Static IP/DHCP • NAT/NAPT • Port forwarding • ALG, UPnP • DDNS/DNS server/DNS client • IPv6/IPv4 dual stack • Static/Default routes • Multiple services on one WAN port	• PPPoE/Static IP/DHCP • NAT/NAPT • Port forwarding • ALG, UPnP • DDNS/DNS server/DNS client • IPv6/IPv4 dual stack • Static/Default routes • Multiple services on one WAN port	• PPPoE/Static IP/DHCP • NAT/NAPT • Port forwarding • ALG, UPnP • DDNS/DNS server/DNS client • IPv6/IPv4 dual stack • Static/Default routes • Multiple services on one WAN port	·PPPoE/Static IP/DHCP ·NAT/NAPT ·Port forwarding ·ALG, UPnP ·DDNS/DNS server/DNS client ·IPv6/IPv4 dual stack, and DS-Lite ·Static/Default routes ·Multiple services on one WAN port
VPN Capability	n/a	n/a	n/a	n/a
Integrated Features	2POTS, Wi-Fi, USB, CATV, SPI firewall, Smart Wi-Fi, TR069	2POTS, Wi-Fi, USB, CATV, SPI firewall, Smart Wi-Fi, TR069	2POTS, Wi-Fi, USB, CATV, SPI firewall, Smart Wi-Fi, TR069	CATV, USB2.0, FTP storage, multicast, QoS, MAC filtering

Optional Add-ons

Model Number	Description
HUAWEI-SC-APC-PATCH	Huawei SC/APC single-mode patch cord for connecting HG8247H GPON terminals to ODF.
HUAWEI-GPON-SFP-C+	Huawei GPON C+ SFP uplink module for OLTs serving HG8247H ONTs.
HUAWEI-WALL-MOUNT-KIT	Wall-mount bracket kit for Huawei EchoLife GPON home terminals.

Quality Certifications

Specification

Huawei H35M8247HTT1 Specification

Model

H35M8247HTT1

Brand

Huawei

Dimensions (H x W x D)

220mm x 160mm x 32mm (without an external antenna)

Operating temperature

0°C to 40°C

Operating humidity

5% RH to 95% RH (non-condensing)

Power adapter input

100–240 V AC, 50–60 Hz

System power supply

11–13 V DC, 2 A

Static power consumption

7.5W

Maximum power consumption

18W

Ports

2POTS+4GE+CATV+Wi-Fi+USB

Indicators

POWER/PON/LOS/LAN/TEL/USB/WLAN/WPS/CATV

GPON Port

• Class B+ • Receiver sensitivity: -27 dBm • Wavelengths: US 1310 nm, DS 1490 nm • WBF • Flexible mapping between GEM Port and TCONT • GPON: consistent with the SN or password authentication defined in G.984.3 • Bi-directional FEC • SR-DBA

Ethernet Port

• Ethernet port-based VLAN tags and tag removal • 1:1 VLAN, N:1 VLAN, or VLAN transparent transmission • QinQ VLAN • Limit on the number of learned MAC addresses • MAC address learning

CATV Port

• Bandwidth 54-870MHz • Output resistance 75 ohms

POTS Port

• Maximum REN: 4 • G.711A/μ, G.729a/b, and G.722 encoding/decoding • T.30/T.38/G.711 fax mode • DTMF • Emergency calls (with the SIP protocol)

USB Port

• USB2.0 • FTP-based network storage

WLAN

• IEEE 802.11 b/g/n • 2 x 2 MIMO • Antenna gain: 2 dBi • WMM • Multiple SSIDs • WPS

Smart interconnection

• Smart Wi-Fi coverage (V300R015C10) • SIP/H.248 auto-negotiation • Any port any service • Parental control (V300R015C10) • L2/L3(IPv4) forwarding: 1G uplink, 2G downlink

Smart service

• Smart Wi-Fi sharing: Portal/802.1x authentication (V300R015C10) SoftGRE-based sharing (V300R015C10) • Association of one account with two POTS ports

Smart O&M

• Variable-length OMCI messages • Active/Passive rogue ONT detection and isolation • Call emulation, and circuit test and loop-line test • PPPoE/DHCP simulation testing • WLAN emulation

Layer 3 Features

• PPPoE/Static IP/DHCP • NAT/NAPT • Port forwarding • ALG, UPnP • DDNS/DNS server/DNS client • IPv6/IPv4 dual stack • Static/Default routes • Multiple services on one WAN port

Multicast

• IGMP v2/v3 proxy(V300R015C00) /snooping • MLD v1/v2 snooping • Multicast services through Wi-Fi

QoS

• Ethernet port rate limitation • 802.1p priority • SP/WRR/SP+WRR • Broadcast packet rate limitation

Security

• SPI firewall • Filtering based on MAC/IP/URL addresses

Common O&M

• OMCI/Web UI/TR069 • Dual-system software backup and rollback

Power Saving

• Dynamic power saving • Indicator power saving • Scheduled Wi-Fi shutdown (V300R015C00)

Weight

1000 kg
