S5720-32X-EI-DC, Huawei S5720 Switch, 24xGE RJ45/4xGE SFP/4x10GE SFP+/DC -48V

100% Genuine Ready to Ship

Overview

Huawei S5720-32X-EI-DC Overview

The Huawei S5720-32X-EI-DC is an enterprise-class Gigabit Ethernet switch designed for high-performance campus and metro aggregation. It delivers 598 Gbit/s switching capacity and 102Mpps forwarding performance across 24×10/100/1,000 Base-T, 4×GE SFP, and 4×10GE SFP+ ports, ideal for dense server and access uplinks. Advanced IP routing, MPLS L2/L3 VPN, comprehensive QoS/ACL, and rich security features such as MACSec and 802.1X make this Huawei switch suitable for Asian, European, African, and North American business networks.

Product Highlights

598 Gbit/s

Switch Fabric

102Mpps

L2 L3 Rate

24GE+4

Port Mix

Product Applications Scenarios

Enterprise Network

Delivers high-density GE access and 10GE uplinks, simplifying Layer 3 aggregation while improving reliability and cutting branch networking costs by up to 30%.

Data Center

Acts as a Top-of-Rack switch with 10GE SFP+ uplinks, supporting large MAC tables and jumbo frames to optimize east-west server traffic.

Service Providers

MPLS L2/L3 VPN and advanced QoS enable efficient metro aggregation, simplifying multi-tenant services and reducing backbone utilization overhead.

Product Features Comparison


Model	S5720-32X-EI-DC, Huawei S5720 Switch, 24×GE RJ45/4×GE SFP/4×10GE SFP+/DC -48V	S5720-28X-SI-DC, Huawei S5720 Switch, 24×GE/4×10GE SFP+/150W DC PSU	LS-S3352P-EI-24S-AC, Huawei S3352P-EI Switch, 24×10/100BASE-T/24×100BASE-X/2×GE SFP	CE5855-24T4S2Q-EI-F, Huawei CE5855-24T4S2Q-EI Switch, 24×GE RJ45/4×10G SFP+/2×40G QSFP+
Brand	Huawei	Huawei	Huawei	Huawei
Port Configuration	n/a	Fixed Ports: 24 Ethernet 10/100/1,000 ports, 4 of which are dual-purpose 10/100/1,000 or SFP P series: 4 Gig SFP X series: 4 x 10 Gig SFP+	10/100BASE-T Ports: 24; 100BASE-X Ports: 24; 100/1000BASE-X Ports: 2; SFP GE Ports: 2 (1000BASE-X, SFP required)	Base-T Ports: 24; SFP+ Ports: 4; QSFP+ Ports: 2
Switching Capacity	598 Gbit/s	336 Gbit/s	n/a	288 Gbit/s
Forwarding Rate	102Mpps	Forwarding Performance: 42Mpps/57Mpps/78Mpps/96Mpps/132Mpps	n/a	Forwarding Rates: 215Mpps
PoE Budget	n/a	n/a	n/a	n/a
Stacking Capability	iStack	iStack	n/a	iStack

Optional Add-ons

Model Number	Description
GE-SFP-LX-SM1310	Huawei 1G SFP LX single-mode module for long-distance uplinks on S5720 SFP ports
SFP-10G-SR	Huawei 10G SFP+ SR multimode transceiver for short-range 10GE connections
Cabinet-42U-Standard	Standard 42U rack cabinet suitable for mounting Huawei S5720 series switches

Quality Certifications

Specification

Huawei S5720-32X-EI-DC Specification

Model

S5720-32X-EI-DC

Brand

Huawei

Switching Capacity

598 Gbit/s

Forwarding Performance

102Mpps

DRAM and Flash Memory

SDRAM: 2GB Flash: 340MB

MAC Address Table

64k

Fixed Ports

24 x 10/100/1,000 Base-T, 4 x 100/1,000 Base-X SFP, 4 x 10 Gig SFP+

Extended Slot

DRAM and Flash

SDRAM: 2GB Flash: 340MB

MAC Address Table

IEEE 802.1d 64K MAC address entries MAC address learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses

VLANs

4K VLANs Guest VLAN and voice VLAN GVRP MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports 1:1 and N:1 VLAN mapping VLAN-based transparent transmission of protocol packets

Jumbo Frame

12K

Ring Protection

RRPP ring topology and RRPP multi-instance Smart Link tree topology and Smart Link multi-instance, providing millisecond-level protection switchover Smart Ethernet Protection (SEP), G.8032 Ethernet Ring Protection Switching (ERPS) STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s) BPDU protection, root protection, and loop protection BPDU tunnel

MPLS

MPLS L3VPN MPLS L2VPN (VPWS/VPLS) MPLS-TE MPLS QoS

IP Routing

Static routing, RIPv1/v2, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, ECMP, and policy-based routing

IPv6 Features

Neighbor Discovery (ND) Path Maximum Transmission Unit (PMTU) IPv6 Ping, IPv6 Tracert, and IPv6 Telnet 6to4 tunnel, ISATAP tunnel, and manually configured tunnel ACLs based on source IPv6 addresses, destination IPv6 addresses, Layer 4 ports, or protocol types Multicast Listener Discovery (MLD) v1/v2 snooping

Multicast Forwarding

IGMP v1/v2/v3 snooping and IGMP fast leave Multicast forwarding in a VLAN and multicast replication between VLANs Multicast load splitting among trunk member ports Controllable multicast Layer 2 multicast control Port-based multicast traffic statistics collection IGMPv1/v2/v3, Protocol Independent Multicast Sparse Mode (PIM-SM), and Protocol Independent Multicast Dense Mode (PIM-DM), and Protocol Independent Multicast Source-Specific Multicast (PIM-SSM) Multicast Source Discovery Protocol (MSDP)

QoS/ACL

Inbound and outbound traffic rate limiting on a port Packet redirection Broadcast storm control Port-based traffic policing and two-rate and three-color CAR Eight queues per port, Weighted Round Robin (WRR), Deficit Round Robin (DRR) Strict Priority (SP), WRR + SP, and DRR + SP queue scheduling algorithms Weighted Random Early Detection (WRED) Re-marking of the 802.1p priority and DSCP value of packets Packet filtering based on Layer 2 to Layer 4 information, including source MAC addresses, destination MAC addresses, source IP addresses, destination IP addresses, TCP/UCD source/destination ports, protocol types, and VLAN IDs Per queue rate limiting and interface traffic shaping 1:1, N:1, N:4 port mirroring VLAN mirroring

Security Features

Hierarchical user management and password protection DoS attack defense, ARP attack defense, and ICMP attack defense Binding of the IP address, MAC address, interface number, and VLAN ID of a user Port isolation, port security, and sticky MAC MAC Forced Forwarding (MFF) Blackhole MAC address entries Limit on the number of learned MAC addresses IEEE 802.1x authentication and the limit on the number of users on an interface AAA authentication, RADIUS authentication, HWTACACS+ authentication, and NAC SSH v2.0 Hypertext Transfer Protocol Secure (HTTPS) CPU defense Blacklist and whitelist MACSec

Access Security

DHCP Relay DHCP Server DHCP Snooping DHCP Client DHCP Security

Port Aggregation

LACP Up to 128 trunk groups Up to 8 member interfaces in each trunk group

Reliability

Ethernet OAM (IEEE 802.3ah and 802.1ag) ITU-Y.1731 BFD for BGP/IS-IS/OSPF/static route

Management and Maintenance

iStack Virtual cable test SNMPv1/v2c/v3 RMON/RMON2 Web-based network management system System logs and multi-level alarms sFlow LLDP/LLDP-MED Secure Copy Protocol (SCP), TFTP, FTP Store dual software images and configuration files 802.3az Energy Efficient Ethernet (EEE)

Interoperability

VLAN-based Spanning Tree (working with PVST/PVST+/RPVST) Link-type Negotiation Protocol (LNP), similar to the Dynamic Trunking Protocol (DTP) VLAN Central Management Protocol (VCMP), similar to the VLAN Trunk Protocol (VTP)

Surge Protection

Surge protection capability of service ports: 6 kV

Operating Environment

Operating temperature: Zero to 1,800m altitude: 0°C to 45°C 1,800m to 5,000m altitude: Operating temperature reduces by 1°C for every altitude increase of 220m. Relative humidity: 5% to 95% (non-condensing)

Input Voltage

DC: Rated voltage range: –48V to –60V Maximum voltage range: –36V to –72V

Dimensions (W x D x H)

442mm x 220mm x 43.6mm

Front Power Input

Yes

Typical Power Consumption

40.9W
