How cost-effective is the S5700-28C-EI-24S?

The S5700-28C-EI-24S offers high performance at a competitive price, making it cost-effective for medium to large networks.

What are the key features of the S5700-28C-EI-24S?

The S5700-28C-EI-24S includes 20 100/1000Base-X and 4 GE Combo ports, dual slots for power modules, and a flexible card slot.

What are the typical application scenarios for the S5700-28C-EI-24S?

The S5700-28C-Ei-24S is ideal for enterprise campus networks and data center access scenarios.

How do I install the S5700-28C-EI-24S?

Installation involves mounting the switch in a rack, connecting power modules, and configuring the network settings via the web interface.

Does the S5700-28C-EI-24S need software upgrades?

Yes, it is recommended to keep the firmware updated for optimal performance and security of the S5700-28C-EI-24S.

Are there alternative products to the S5700-28C-EI-24S?

Alternatives include the Cisco Catalyst 2960-X series, providing similar functionality but varying in brand support.

S5700-28C-EI-24S

Name: S5700-28C-EI-24S
SKU: S5700-28C-EI-24S
Rating: 4.5 (6 reviews)

Skip to the end of the images gallery

End of Life

Skip to the beginning of the images gallery

Name:	S5700-28C-EI-24S
Model:	S5700-28C-EI-24S 02352350 Huawei Quidway S5700 Switch
Brand:	Huawei
Detail:	20 100/1000Base-X and 4 GE Combo, Dual Slots of power, Single Slot of Flexible Card, Without Flexible Card and Power Module
	Rating: 90% 4.5/5.0 6 Reviews 10 Questions
Availability:	Item Backordered
Condition:	New Factory Sealed
Replacement:	S5720-36C-EI-28S-AC

Shipping:

Express Shipping to United States
2-6 Days, via DHL, FedEx, UPS, etc.

Ships to:

Payment:

Pay by wire transfer.
Pay with your paypal.
Pay with your webmoney.
Pay with your onafriq.
Pay with your Visa credit card.
Pay with your Mastercard credit card.
Pay with your Discover Card.
Pay by Western Union.

Support:

TZS, XAF, TZS payment.

Safe, Fast, 100% Genuine. Your Reliable IT Partner.
Best Price Assurance, Bulk Savings, Trusted Worldwide.

S5700-28C-EI-24S

20 100/1000Base-X and 4 GE Combo, Dual Slots of power, Single Slot of Flexible Card, Without Flexible Card and Power Module

Stable Global Supply Chain for Thriving Businesses.

$4,000,000 Inventory
500+ Reliable Vendors
Certified Partnerships
Collaborating with FedEx, UPS, DHL

100,000+ Diverse Products for All Your Needs

Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.

Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.

Projects and Technical Support
Easy Purchasing Supply
Product Lifecycle Protection
Exclusive F4 Team Support

Overview

S5700-28C-EI-24S Overview

Huawei S5700 Series Switches provide highly scalable gigabit access for terminals in enterprise campus networks; also ideal for resilient server support and aggregation in large-scale data centers. S5700-28C-EI-24S offers 24 Gig SFP, 4 of which are dual-purpose 10/100/1000 or SFP, and 1 interface slot.

Quick Specs

Figure 1 shows the appearance of Huawei S5700-28C-EI-24S-AC switch with installed sub-card. The sub-card must be purchased separately.

S5700-28C-EI-24S Appearance

Table 1 shows the Quick Specs.

Product Code	S5700-28C-EI-24S
Ports	24 Gig SFP, 4 of which are dual-purpose 10/100/1,000 or SFP ports
Subcard Supported	4 x 1,000 Base-X SFP subcard, 2 x 10 GE SFP+ subcard, 4 x 10 GE SFP+ subcard
Forwarding Performance	96 Mpps
Switching Capacity	256 Gbit/s
MAC Address Table	32K MAC
VLAN Features	4K VLANs
Dimensions (W x D x H)	44.2 cm x 42 cm x 4.36 cm
Weight	7.3 Kg

Product Details

Figure 2 shows the front panel of Huawei S5700-28C-EI-24S-AC switch. This one has installed the sub-card but the card must be purchased alone.

S5700-28C-EI-24S Front Panel

Note:

①

Twenty 100/1000BASE-X ports

④

ETH management port

②

Four combo ports (10/100/1000BASE-T

+ 100/1000BASE-X)

⑤

Front card slot with subcard

③

One console port

Figure 3 shows the back panel of Huawei S5700-28C-EI-24S switch. This one has installed the AC power module but the power module must be purchased alone.

S5700-28C-EI-24S Back Panel

Note:

①	ESD jack	④	Power module slot 2
②	Rear card slot	⑤	Power module slot 1
③	Fan slot

The Optical Transceiver and Card

Table 2 shows the recommended optical transceivers and card.

Model	Description
GE-SFP Optical Transceiver
SFP-1000BaseT	Electrical Transceiver, SFP, GE, Electrical Interface Module(100m,RJ45)
eSFP-GE-SX-MM850	Optical Transceiver, eSFP, GE, Multi-mode Module(850nm,0.55km,LC)
SFP-GE-LX-SM1310	Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,10km,LC)
S-SFP-GE-LH40-SM1310	Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,40km,LC)
S-SFP-GE-LH40-SM1550	Optical Transceiver, eSFP, GE, Single-mode Module(1550nm,40km,LC)
10G-SFP+ Optical Transceiver
SFP-10G-USR	10GBase-USR Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.1km,LC)
OMXD30000	Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.3km,LC)
OSX010000	Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)
10GE interface card
ES5D000X2S00	2 × 10 Gig SFP+ interface card(used in S5700SI and S5700EI series

Compare to Similar Items

Table 3 shows the comparison of Huawei S5700-28C-EI-24S and S5700-28C-PWR-EI switch.

Models	S5700-28C-EI-24S	S5700-28C-PWR-EI
Ports	24 Gig SFP, 4 of which are dual-purpose 10/100/1,000 or SFP ports	24 Ethernet 10/100/1,000 ports
Subcard Supported	4 x 1,000 Base-X SFP subcard, 2 x 10 GE SFP+ subcard, 4 x 10 GE SFP+ subcard	4 x 1,000 Base-X SFP subcard, 2 x 10 GE SFP+ subcard, 4 x 10 GE SFP+ subcard
Software Image	Enhanced software Image	Enhanced software Image
PoE	Not Supported	Supported

Get more information

Do you have any question about the Huawei S5700-28C-EI-24S switch?

Quality Certifications

Specification

S5700-28C-EI-24S Specification

S5700-28C-EI-24S Specifications
Manufacturer	Huawei
Manufacturer Part Number	S5700-28C-EI-24S
Form Factor	Fixed, Stackable
Switch Port	20 GE SFP ports, 4 GE Combo ports
Power Over Ethernet (PoE)	Non-POE
Extended slot	Provides two extended slots, one for an uplink subcard and the other for a stack card
Max Stack bandwidth	48Gbps
DRAM Memory	256 MB
Flash Memory	32 MB
Performance
Forwarding performance	96 Mpps
MAC address table	IEEE 802.1d compliance
	16 K MAC address entries
	MAC address learning and aging
	Static, dynamic, and blackhole MAC address entries
	Packet filtering based on source MAC addresses
VLAN	4 K VLANs
Reliability	RRPP ring topology and RRPP multi-instance
	Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level protection switchover
	SEP
	STP, RSTP, and MSTP
	BPDU protection, root protection, and loop protection
	E-Trunk
IP routing	Static routing, ECMP
IP routing	RIPv1, RIPv2 and RIPng
IPv6 features	Neighbor Discovery (ND)
	Path MTU (PMTU)
	IPv6 ping, IPv6 tracert, and IPv6 Telnet
	ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type
	MLD v1/v2 snooping
	6to4 tunnel, ISATAP tunnel, and manually configured tunnel
Multicast	IGMP v1/v2/v3 snooping and IGMP fast leave
	Multicast forwarding in a VLAN and multicast replication between VLANs
	Multicast load balancing among member ports of a trunk
	Controllable multicast
	Port-based multicast traffic statistics
QoS/ACL	Rate limiting on packets sent and received by an interface
	Packet redirection
	Port-based traffic policing and two-rate three-color CAR
	Eight queues on each port
	WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms
	Re-marking of the 802.1p priority and DSCP priority
	Packet filtering at Layers 2 through 4, filtering out invalid frames based on the source MAC address, destination
	MAC address, source IP address, destination IP address, port number, protocol type, and VLAN ID
	Rate limiting in each queue and traffic shaping on ports
Security	User privilege management and password protection
	DoS attack defense, ARP attack defense, and ICMP attack defense
	Binding of the IP address, MAC address, interface, and VLAN
	Port isolation, port security, and sticky MAC
	Blackhole MAC address entries
	Limit on the number of learned MAC addresses
	802.1x authentication and limit on the number of users on an interface
	AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC
	SSH v2.0
	Hypertext Transfer Protocol Secure (HTTPS)
	CPU defense
	Blacklist and whitelist
Management
Management and maintenance	Stacking MAC Forced Forwarding (MFF) Virtual cable test Port mirroring and RSPAN (remote port mirroring) Remote configuration and maintenance by using Telnet SNMP v1/v2/v3 RMON Web NMS HGMP System logs and alarms of different levels GVRP MUX VLAN
Power Supply Specifications
Power Device	Power supply - Non-PoE
Power Redundancy	No
Voltage Required	AC 120/230 V ( 50/60 Hz )
Dimensions / Weight / Miscellaneous
Width	44.2cm
Depth	43.6cm
Height	22.0cm
Weight	5.0kg
System Software
Software Version	Enhanced Version
Manufacturer Warranty
Service & Support	1 year warranty

Quality Certifications

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

What are common troubleshooting steps for the S5700-28C-EI-24S?

Common steps include checking power connections, verifying network configurations, and updating firmware.

What accessories are available for the S5700-28C-EI-24S?

Available accessories include optional flexible cards and power modules for enhanced functionality.

How does the S5700-28C-EI-24S compare to similar products?

The S5700-28C-EI-24S offers robust performance with flexible power and card options, competitive with similar switches within its range.

Is the S5700-28C-EI-24S a reliable choice for network scalability?

Yes, its modular design and flexible card options make it reliable and scalable for growing network demands.
