Overview

S1728GWR-4P-AC Overview

Huawei S1728GWR-4P-AC is an Web-managed Switch which is easy to install and maintain, and is ideal for small and medium size enterprises, Internet cafes, hotels, and schools. It’s one of the S1700 Series Enterprise Switches and it offers 24 Ethernet 10/100/1000 ports and AC power supply.

Quick Specs

Figure 1 shows the appearance of Huawei S1728GWR-4P-AC switch.

S1728GWR-4P-AC

Table 1 shows the Quick Specs.

Product Code

S1728GWR-4P-AC

Type

Web-managed Switch

Downlink Ports

24 Ethernet 10/100/1000 ports

Uplink Ports

4 Gig SFP

MAC Address

8K MAC

Forwarding Performance

42 Mpps

Switching Capacity

56 Gbit/s

Input Voltage

100 V to 240 V AC, 50/60 Hz

Heat Dissipation

Fan-free natural heat dissipation

Dimensions (W x D x H)

44.2 × 22 × 4.36 cm

Weight (Kg)

3.5 Kg

Product Details

Figure 2 shows the front panel of Huawei S1728GWR-4P-AC switch.

S1728GWR-4P-AC Front Panel

Note：

①

Ethernet electrical port indicators

⑤

Reset Button

②

1000BASE-X port indicator

⑥

Power Status Indicator

③

24 Ethernet 10/100/1000 ports

⑦

System Status Indicator

④

1000BASE-X ports

Table 2 shows the LED Indicators description.

LED Indicator

Condition

Description

Ethernet Electrical Port Indicator

On Green

The port has a valid 1000 Mbps.

Blinking Green

Blinking indicates activity for 1000 Mbps.

On Yellow

The port has a valid 10/100 Mbps link.

Blinking Yellow

Blinking indicates activity for 10/100 Mbps.

Off

The port is not connected or has been shut down.

Power Status Indicator

On Green

Internal power is operating normally.

Off

Power off.

System Status Indicator

Steady Green

The switch is starting or working abnormally.

Blinking Green

The switch is working properly.

Off

The switch is not started.

Figure 3 shows the back panel of Huawei S1728GWR-4P-AC switch.

S1728GWR-4P-AC Back Panel

Note：

①

Ground Screw

②

AC Power Jack

· There is no On/Off power switch on S1728GWR-4P-AC for that it can work directly by connecting the power supply.

· Ground screw is used with a ground cable.

· An S1728GWR-4P has a built-in AC power supply, which provides power for the entire switch.

The Optical Transceiver

Table 3 shows the recommended optical transceivers for 1720-28GFR-4TP.

Models

Description

eSFP-GE-SX-MM850

Optical Transceiver, eSFP, GE, Multi-mode Module(850nm,0.55km,LC)

SFP-GE-LX-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,10km,LC)

S-SFP-GE-LH40-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,40km,LC)

S-SFP-GE-LH40-SM1550

Optical Transceiver, eSFP, GE, Single-mode Module(1550nm,40km,LC)

Compare to Similar Item

Table 4 shows the comparison between S1728GWR-4P-AC and S1700-28FR-2T2P-AC.

Model

S1728GWR-4P-AC

S1700-28FR-2T2P-AC

Downlink Ports

24 Ethernet 10/100/1000 ports

24 Ethernet 10/100 ports

Uplink Ports

4 Gig SFP

2 Ethernet 10/100/1000 ports and 2 Gig SFP

MAC Address Table

8K MAC

8K MAC

Dimensions (W x D x H)

442 × 220 × 43.6 mm

442 × 220 × 43.6 mm

Get more information

Do you have any question about the Huawei S1728GWR-4P-AC switch?

Contact us now via Live Chat or sales@router-switch.com.

Quality Certifications

  • ISO 14001
  • ISO 9001
  • RoHS
  • REACH
  • CE
  • FCC
Specification

S1728GWR-4P-AC Specification

S1728GWR-4P-AC Specifications

Type

Huawei S1700 Web-managed Switch

Downlink Ports

24 Ethernet 10/100/1,000 ports

Uplink Ports

4 Gig SFP

MAC Address Table

8K MAC

Dimensions in mm (W x D x H)

442 mm x 220 mm x 43.6 mm

Input Voltage

100V to 240V AC, 50 Hz/60 Hz

EEE

Supported

Power Consumption

< 15W

Operating Temperature

0°C to 45°C

Humidity (non-condensing)

5% to 90%

Heat Dissipation

Fan-free natural heat dissipation

Security features

Packet filtering based on MAC addresses
MAC address authentication (S1720 Series)
Port-based 802.1x authentication
RADIUS authentication
Portal authentication (S1720 Series)
Port isolation
Storm suppression (S1720 Series)
DHCP snooping (S1720 Series)

VLANs

256 VLANs (S1720 Series: 4K)
Access port
Trunk port
Hybrid port
Management VLAN
Voice VLAN

QoS

PQ and WRR
Four queues on each port (S1720 series: Eight)
Queue scheduling based on 802.1p or DSCP priorities

STP

STP (IEEE 802.1d)
RSTP (IEEE 802.1w)
MSTP (IEEE 802.1s) (S1720 series)

Multicast

IGMP snooping

Routing Features

IPv4 and IPv6 static routing (S1720 series)

Link Aggregation

12 Link Aggregation Groups (LAGs) with a maximum of eight ports in each LAG
64 Link Aggregation Groups (S1720 series)
Static LACP

Port Mirroring

Port-based bi-directional flow mirroring

Broadcast Storm Suppression

Broadcast storm suppression based on the interface rate
Alarm sending when the traffic rate reaches the upper limit

Device Management

Web system network management
DHCP client
One-key restoration

Device Maintenance

System log
Ping
Virtual Cable Test (VCT)
Link Layer Discovery Protocol (LLDP)

Quality Certifications

Q&A

Questions & Answers

Are there alternative products to the S1728GWR-4P-AC?

Alternative products include other Huawei switches such as the S1700 series, offering similar features at different price points.

What common troubleshooting is needed for the S1728GWR-4P-AC?

Common troubleshooting for the S1728GWR-4P-AC involves checking network cable connections, power supply status, and ensuring firmware is up to date.

What accessories are available for the S1728GWR-4P-AC?

Accessories for the S1728GWR-4P-AC include additional SFP modules, power cables, and rack-mounting kits.

How does the S1728GWR-4P-AC compare to similar products?

The S1728GWR-4P-AC offers a competitive edge with its balance of 24 Gigabit Ethernet ports and 4 Gig SFP ports, combined with reliable performance and cost-efficiency.
