main product photo
Name:

AR1220EVW

Model:Huawei AR1220EVW,2GE COMBO,8GE LAN,802.11b/g/n AP,2 USB,2 SIC,build-in 32-channel DSP,PoE Power Adapter
Brand: Huawei
Detail:
Huawei AR1220EVW,2GE COMBO,8GE LAN,802.11b/g/n AP,2 USB,2 SIC,build-in 32-channel DSP,PoE Power Adapter
Rating:
91%
4.6/5.0
7 Reviews
Price:US$736.00
Coupon
Up to $80 Coupons
Get Now
$10.00
Order Over $100
RS10
$20.00
Order Over $2000
RSTW
$50.00
Order Over $5000
RSFI
$80.00
Order Over $8000
RSEI
Availability: Item Backordered
Condition:New Factory Sealed
Warranty:3 years warranty
Shipping:
Express Shipping to United States
2-6 Days, via DHL, FedEx, UPS, etc.
Ships to:
United States
Payment:
  • Pay by wire transfer.
  • Pay with your paypal.
  • Pay with your webmoney.
  • Pay with your onafriq.
  • Pay with your Visa credit card.
  • Pay with your Mastercard credit card.
  • Pay with your Discover Card.
  • Pay by Western Union.
More
Support:
TZS, XAF, TZS payment.
  • Safe, Fast, 100% Genuine. Your Reliable IT Partner.
    Safe, Fast, 100% Genuine. Your Reliable IT Partner.
  • Best Price Assurance, Bulk Savings, Trusted Worldwide.
    Best Price Assurance, Bulk Savings, Trusted Worldwide.
Expertise Builds Trust

Expertise Builds Trust

  • 22 Years, 200+ Countries
  • 18000+ Customers/Projects
  • CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts
Ask an Expert Now
24/7 Online Service
  • +1-626-655-0998(USA)
  • +852-25925389(HK)
  • +852-25925411(HK)
Live Chat

Join Partner Network

  • Exclusive Discounts/Service
  • Credit Terms/Priority Supply
In  United States
Partner Today

You may also be interested in the following product(s)

AR0MNTEH10100

AR0MNTEH10100

Rating:
100%
5/5.0
2 Reviews
US$1,020.00
AR0MNTEH10201

AR0MNTEH10201

Rating:
100%
5/5.0
1 Review
US$1,394.00
AR0MNTEH10301

AR0MNTEH10301

Rating:
100%
5/5.0
1 Review
US$2,584.00
AR0M1200CC

AR0M1200CC

Rating:
90%
4.5/5.0
2 Reviews
US$1,039.00
AR1220E

AR1220E

Rating:
99%
5/5.0
16 Reviews
US$1,241.00
AR1220EV

AR1220EV

Rating:
100%
5/5.0
2 Reviews
AR1220F

AR1220F

Rating:
97%
4.9/5.0
6 Reviews
AR0M012VBA00

AR0M012VBA00

Rating:
93%
4.7/5.0
3 Reviews
US$1,025.00
AR1220F-S

AR1220F-S

Rating:
95%
4.8/5.0
8 Reviews
AR0M012SBA00

AR0M012SBA00

Rating:
90%
4.5/5.0
8 Reviews
US$428.00
AR0M12VWBA00

AR0M12VWBA00

Rating:
87%
4.4/5.0
6 Reviews
US$1,144.00
AR1220C

AR1220C

Rating:
94%
4.7/5.0
14 Reviews
US$380.00

AR1220EVW

Huawei AR1220EVW,2GE COMBO,8GE LAN,802.11b/g/n AP,2 USB,2 SIC,build-in 32-channel DSP,PoE Power Adapter

Price: US$736.00
Overview
Specification
Reviews
Q&A
Warranty
Download
Stable Global Supply Chain for Thriving Businesses.
  • $4,000,000 Inventory
  • 500+ Reliable Vendors
  • Certified Partnerships
  • Collaborating with FedEx, UPS, DHL
100,000+ Diverse Products for All Your Needs
Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.
Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.
  • Projects and Technical Support
  • Easy Purchasing Supply
  • Product Lifecycle Protection
  • Exclusive F4 Team Support
Overview

AR1220EVW Overview

Huawei AR1220EVW is the next generation enterprise-class wireless, voice and security router, the router based on the Huawei proprietary Versatile Routing Platform which is built on Huawei.

Quick Specs

Figure 1 shows the appearance of AR1220EVW.

  AR1220EVW-appearance

Table 1 shows the Quick Specs.

Product Code

Huawei Router - AR1220EVW

Memory

1 GB

Flash

512 MB

Service interfaces (standard configuration)

WAN interfaces: 2 GE combo interfaces

LAN interfaces: 8 10/100/1000M auto-sensing Ethernet electrical interfaces

Extended slots

2 SIC slots

Interface number

LAN interfaces: GE0-GE7

Power module type

Built-in AC power module

Weight

2.9 kg (6.39 lb)

Dimensions (W x D x H)

390.0 mm x 232.5 mm x 44.5 mm

Product Details

Figure 2 shows the front panel of AR1220EVW.

  AR1220EVW-front

Note:

①

Two USB interfaces (host)

②

RST button

Figure 3 shows the back panel of AR1220EVW.

  AR1220EVW-back

Note:There are 2 SIC slots, 8 GE electrical interfaces and 2 GE combo interfaces on the back panel. These cards must purchase separately.

The Optical transceiver, Cards

Table 2 shows the recommended elements for the Huawei Router - AR1220EVW.

Model

Description

FE-SFP Optical Transceiver

SFP-FE-SX-MM1310

SFP,100M/155M,Multi-mode Module(1310nm,2km,LC)

eSFP-FE-LX-SM1310

eSFP,100M/155M,Single-mode Module(1310nm,15km,LC)

S-SFP-FE-LH40-SM1310

eSFP,FE,Single-mode Module(1310nm,40km,LC)

GE-SFP Optical Transceiver

SFP-1000BaseT

SFP,GE,Electrical Interface Module(100m,RJ45)

eSFP-GE-SX-MM850

eSFP,GE,Multi-mode Module(850nm,0.55km,LC)

SFP-GE-LX-SM1310

eSFP,GE,Single-mode Module(1310nm,10km,LC)

S-SFP-GE-LH40-SM1310

eSFP,GE,Single-mode Module(1310nm,40km,LC)

S-SFP-GE-LH40-SM1550

eSFP,GE,Single-mode Module(1550nm,40km,LC)

WAN interface card

AR-1E3T3M-W

1-Port Channelized/Unchannelized E3/T3 WAN Interface Card

xDSL interface card

AR01SLV1XA

1-Port VDSL2 over POTS WAN Interface Module

Compare to Similar Items

Table 3 shows the comparison between AR1220EVW and AR0M012VBA00 .

Model

AR1220EVW

AR0M012VBA00

WAN Speed with Services

400 Mbit/s

200 Mbit/s

Fixed WAN Ports

2 x GE Combo

2 x GE

Fixed LAN Ports

8 x GE (can be configured as WAN interfaces)

8 x FE (can be configured as WAN interfaces)

Slots

SIC slots: 2

WSIC slots (default/max): 0/1

Memory

1 GB

512 MB

Get more information

Do you have any question about the AR1220EVW

Contact us now via Live Chat or sales@router-switch.com.

Quality Certifications

  • ISO 14001
  • ISO 9001
  • RoHS
  • REACH
  • CE
  • FCC
Specification

AR1220EVW Specification

AR1220EVW Specification

WAN speed with services***

400 Mbit/s

Firewall Performance (large packet)

1,800 Mbit/s

Device Switching Capacity

8 Gbit/s

Slot Switching Bandwidth

SIC & WSIC slots 2 Gbit/s

Number of Recommended Users

100

Fixed WAN Ports

2 x GE Combo

Fixed LAN Ports

8 x GE (can be configured as WAN interfaces)

SIC Slots

2

WSIC Slots (default/max)

0/1

DSP Slots

32 channels supported by default

Wi-Fi

802.11b/g/n

USB 2.0 Ports

2

Mini-USB Ports

1

Serial Auxiliary/Console Port

1

Memory

1 GB

Flash

512 MB

Max. Power

60W

PoE Power

External 100W

AC Power

100V to 240V

Frequency

50 Hz/60 Hz

DC Power

-

Dimensions (H x W x D)

44.5 mm x 390 mm x 220 mm

Weight

2.9kg (without interface cards)

Ambient Temperature

0°C to 45°C

Relative Humidity

5% to 95% (non-condensing)

Basic Features

DHCP server/client, PPPoE server/client, PPPoA server/client, PPPoEoA server/client, NAT, and Sub interface management

Voice

RTP, SIP, SIP AG, IP PBX/TDM PBX, FXO/FXS, VoIP/conference call, BEST, DISA, and SBC (only voice models support voice features)

WLAN (AP)

AP management, WLAN QoS (WMM), WLAN security (WEP/WPA/WPA2/key management), WLAN radio management (802.11b/g/n), and WLAN user management (only WLAN models support WLAN AP features)

WLAN (AC)

AP management (AC discovery/AP access/AP management), CAPWAP, WLAN user management, WLAN radio management (802.11a/b/g/n, WLAN QoS (WMM), and WLAN security (WEP/WPA/WPA2/Key management）

3G

3G Interface card (WCDMA)

LTE

LTE Interface card (FDD LTE: Uplink: 50 Mbit/s; Downlink: 100 Mbit/s)

LAN

IEEE 802.1P, IEEE 802.1Q, IEEE 802.3, VLAN management, MAC address management, and MSTP

IPv4 Unicast Routing

Routing policy, static route, RIP, OSPF, IS-IS, and BGP

IPv6 Unicast Routing

Routing policy, static route, RIPng, OSPFv3, IS-ISv6, and BGP4+

Multicast

IGMPv1/v2/v3, PIM SM, PIM DM, and MSDP

MPLS

LDP, MPLS L3 VPN, VLL, PWE3, static LSP, dynamic LSP, MPLS TE, IP FRR, LDP FRR, TE FRR

VPN

IPSec VPN, GRE VPN, DSVPN, A2A VPN, L2TP VPN, Smart VPN

QoS

DiffServ mode, MPLS QoS, priority mapping, traffic policing (CAR), traffic shaping, congestion avoidance (based on IP precedence/DSCP WRED), congestion management (LAN interface: SP/WRR/SP + WRR; WAN interface: PQ/CBWFQ), MQC (traffic classifier, traffic behavior, and traffic policy), Hierarchical QoS, WLAN QoS, FR QoS, and Smart Application Control (SAC)

Security

ACL, firewall, 802.1x authentication, AAA authentication, RADIUS authentication, HWTACACS authentication, broadcast storm suppression, ARP security, ICMP attack defense, URPF, CPCAR, blacklist, and IP source tracing

Management and Maintenance

Upgrade management, device management, web-based GUI, GTL, SNMPv1/v2c/v3, NTP, CWMP, Auto-Config, deployment using USB disk, and CLI

Quality Certifications

Q&A

Questions & Answers

What accessories come with the Huawei AR1220EVW?

Accessories include the PoE power adapter, mounting brackets, and necessary cables for setup.

How does the Huawei AR1220EVW compare to similar products?

The Huawei AR1220EVW stands out with its built-in 32-channel DSP and PoE power adapter, offering a competitive edge over similar products.

How can I troubleshoot common issues with the Huawei AR1220EVW?

Common troubleshooting involves checking the power supply, ensuring firmware is up to date, and verifying proper network configurations.

Does the Huawei AR1220EVW support PoE and what are its benefits?

Yes, the Huawei AR1220EVW supports PoE, which simplifies installation by allowing power and data over a single cable.
