AIR-OEAP1810-F-K9, Cisco AIR-OEAP1810 Series Access Point, 802.11ac Wave 2/4x4 MIMO/OfficeExtend

100% Genuine Ready to Ship

$695.00

$732.00

Overview

Cisco AIR-OEAP1810-F-K9 Overview

The Cisco AIR-OEAP1810-F-K9 is an enterprise-class OfficeExtend access point designed to bring secure corporate Wi‑Fi into remote and home offices. Leveraging 802.11ac with 2x2 MU‑MIMO, it delivers high-performance wireless across 2.4GHz and 5GHz with integrated antennas optimized for dense client environments. Up to 400 simultaneous clients, rich WPA2/AES security with 802.1X and RADIUS AAA, plus flexible PoE uplink and local Ethernet ports make it ideal for distributed workers, SMB branches, and hospitality deployments requiring simple, centralized control via Cisco AireOS controllers.

Product Highlights

400

Client Cap

866.7Mbps

11ac Rate

13/4

Ch 2.4/5

Product Applications Scenarios

Enterprise Network

Enables secure OfficeExtend connectivity for branch and home workers, reducing WAN congestion and IT onsite visits while maintaining centralized policy control.

Cloud Services

Optimizes access to cloud applications over 802.11ac, improving user experience and helping cut support tickets by up to 30% in remote-heavy deployments.

Security & Privacy

Uses WPA2, 802.1X, and RADIUS AAA to extend corporate SSIDs securely into homes, reducing data leakage risk and simplifying regulatory compliance.

Product Features Comparison


Model	AIR-OEAP1810-F-K9, Cisco AIR-OEAP1810 Series Access Point, 802.11ac Wave 2/4x4 MIMO/OfficeExtend	AIR-AP3802P-GK910	AIR-CAP3602I-K-K9, Cisco AIR-CAP3602I Series Access Point, 802.11n, 4x4:3SS, Internal Antenna	AIR-AP1815W-A-K9C
Brand	Cisco	Cisco	Cisco	Cisco
Wi-Fi Standard	802.11ac (non HT80)	Wireless Standard: 802.11ac Wave 2	IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d	IEEE: 802.11a/b/g/n/h/d/ac
Maximum Data Rate	PHY data rates up to 866.7Mbps (80MHz on 5GHz)	Maximum Data Rate: 5.2 Gbps	Data Rates Supported: IEEE 802.11a: up to 54 Mbps; IEEE 802.11g: up to 54 Mbps	Supported Data Rates: 802.11a: 6-54 Mbps; 802.11b/g: 1-54 Mbps; 802.11n (2.4 GHz): up to 144.4 Mbps; 802.11ac (5 GHz): up to 866.7 Mbps
Supported Frequency Band	F regulatory domain: 2.412 to 2.472GHz; 13 channels 5.745 to 5.805GHz; 4 channels	Operating Frequency Bands: 2.4 GHz and 5 GHz	Integrated Antenna Details: 2.4 GHz, gain 2 dBi; 5 GHz, gain 4 dBi	Wi-Fi Bands: 2.4 GHz, 5 GHz
Client Capacity	Maximum number of associated wireless clients: 200 per Wi-Fi radio, in total 400 clients per access point	Number of Spatial Streams: 3	n/a	Maximum Clients: 200 clients per Wi-Fi radio, 400 per access point
Network Interface	Interfaces: One 10/100/1000BASE-T PoE uplink port; Management console port (RJ-45); Three 10/100/1000BASE-T ports (local Ethernet ports), including one PoE out port; One passive pass-through port RJ-45; DC power connector	Ports: 1x 100/1000/2500/5000 Multigigabit Ethernet (RJ-45)	Interfaces: 10/100/1000BASE-T autosensing (RJ-45)	Interfaces: 1 x 10/100/1000BASE-T RJ-45 (PoE); management console port (4-pin); 3 x local Gigabit Ethernet; 1 x passive RJ-45 pass-through

Optional Add-ons

Model Number	Description
AIR-AP-BRACKET-W2=	Cisco mounting bracket for AIR-OEAP1810 Series indoor access points, wall or junction-box installation.
AIR-AP1810W-KIT=	Cisco spacer kit with RJ-45 jumper cable for direct wall mounting of AIR-OEAP1810-F-K9 where junction boxes are unavailable.
AIR-OEAP1810-CRD=	Cisco desk cradle kit with back cover and RJ-45 jumper cable for desktop deployment of AIR-OEAP1810 Series access points.
AIR-SEC-50=	Cisco physical security kit with screws and RJ-45 caps to secure AIR-OEAP1810-F-K9 and block Ethernet port access.
AIR-PWR-D=	Cisco local power supply for AIR-OEAP1810 Series, enabling full 802.3af PoE out on the local Ethernet port.

Quality Certifications

Specification

Cisco AIR-OEAP1810-F-K9 Specification

Model

AIR-OEAP1810-F-K9

Brand

Cisco

Authentication and security

Advanced Encryption Standard (AES) for Wi-Fi Protected Access 2 (WPA2) 802.1X, RADIUS authentication, authorization and accounting (AAA) 802.11i

Software

Cisco Unified Wireless Network Software with AireOS Wireless Controllers Release 8.2.111.0 or later

Maximum clients

Maximum number of associated wireless clients: 200 per Wi-Fi radio, in total 400 clients per access point

802.11ac

2x2 single-user/multiuser MIMO with two spatial streams Maximal ratio combining (MRC) 20-, 40- and 80-MHz channels PHY data rates up to 866.7Mbps (80MHz on 5GHz) Packet aggregation: A-MPDU (Tx/Rx), A-MSDU (Rx) 802.11 Dynamic Frequency Selection (DFS) Cyclic shift diversity (CSD) support

Ethernet ports

Authentication with 802.1X or MAC filtered Dynamic VLAN or per port Traffic locally switched or tunneled back to wireless LAN controller

Bluetooth (future availability)

Integrated Bluetooth 4.1 (including BLE) radio Maximum transmit power: 5 dBm Antenna gain: 2 dBi

Maximum number of non-overlapping channels

F (F regulatory domain): 2.412 to 2.472GHz; 13 channels 5.745 to 5.805GHz; 4 channels

Receive sensitivity (combined sensitivity)

802.11ac (non HT80) -88 dBm @ 6Mbps -70 dBm @ 54Mbps

Integrated antennas

2.4GHz, gain 2 dBi 5GHz, gain 4 dBi

Interfaces

One 10/100/1000BASE-T PoE uplink port Management console port (RJ-45) Three 10/100/1000BASE-T ports (local Ethernet ports), including one PoE out port: 鈼?nbsp; PoE out provides 802.3af when access point is powered by Cisco local power supply (AIR-PWR-C=, AIR-PWR-D=), or ~6.5W when powered by 802.3at, or no output when powered by 802.3af One passive pass-through port RJ-45 (back to bottom) DC power connector

Indicators

Status LED indicates boot loader status, association status, operating status, boot loader warnings, boot loader errors Per-port status for local Ethernet ports For privacy, LEDs are automatically turned off when the access point joins a controller. LEDs may be enabled to be administratively - see configuration guide.

Dimensions (W x L x H)

Access point (without mounting bracket): 6.5 x 4.5 x 1.6in. (165 x 114 x 41mm)

Environmental

Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C) Nonoperating (storage) maximum altitude: 25°C, 15,000 ft (4,500m) Operating temperature: 32° to 104°F (0° to 40°C) Operating humidity: 10% to 90% percent (noncondensing) Operating maximum altitude: 40°C, 9843 ft (3,000m)

System

512MB DRAM 256MB flash 1.4GHz system dual-core CPU

Input power requirements

44 to 57V DC Optional power supply and power injector: 100 to 240V AC; 49 to 60 Hz

Powering options

802.3af/at Ethernet switch Optional Cisco power injectors (AIR-PWRINJ5=, AIR-PWRINJ6=) Optional Cisco local power supply (AIR-PWR-C= or AIR-PWR-D=)

Power draw

Maximum values: 12.95W (15.4W with 100m of cable) with no PoE out, 20.7W (22W with 100m of cable) with 6.49W PoE out and 27.65W with 12.95W PoE out (when powered using AIR-PWR-C or AIR-PWR-D) Note: When deployed using PoE, the power draw numbers listed above include the power loss in 100m of cabling on the uplink port and 100m of cabling on the PoE out port.

Physical security

Torx security screw, included with the access point Kensington security slot

Mounting

Included with the access point: mounting bracket AIR-AP-BRACKET-W2, compatible to install to single gang junction box or multiple international standards Optional: 鈼?nbsp; AIR-AP1810W-KIT=, spacer kit to mount the access point directly on a wall where standard junction boxes are not available 鈼?nbsp; AIR-OEAP1810-CRD=, cradle kit to mount the access point on a desk

Accessories

Mounting bracket: AIR-AP-BRACKET-W2= (available as spare) Spacer kit: AIR-AP1810W-KIT= (sold separately), includes spacer and RJ-45 jumper cable Cradle kit: AIR-OEAP1810-CRD= (sold separately), includes back cover and RJ-45 jumper cable Physical security kit: AIR-SEC-50= (sold separately), with 50 pcs. security screws used to secure the access point onto wall-mounting bracket, 50 pcs. RJ-45 caps and 2 pcs. unlock keys used to block physical access to Ethernet ports Cisco local power supply: AIR-PWR-D= (sold separately)

Weight

1.2 kg
