    Overview

    Huawei USG9560-BASE-DC-V3 Overview

    Huawei USG9560-BASE-DC-V3 USG9500 Data Center Firewall Basic Configuration includes 8 slots Chassis with DC power supply, 2*SRU,1*SFU. Huawei USG9500 data center firewall is the world’s fastest firewall for data center environment to ensure secure services in the cloud and for large data centers and enterprise campus networks. Integrated switching, routing, and security enable smooth upgrade, carrier-class reliability, comprehensive virtualization, and terabit-level processing capability. The Huawei USG9500 uses a hardware platform that often exists in a core router to provide modularized components. Each interface module has two network processors (NPs) to provide line rate forwarding. The SPU uses multi-core CPUs and a multi-thread architecture, and each CPU has an application acceleration engine. These hardware advantages, combined with Huawei optimized concurrent processing technology, increases CPU capacity to ensure the high speed parallel processing of multiple services, such as NAT and VPN. LPUs and SPUs function separately. The overall performance increases linearly with the addition of SPUs so that customers can easily scale up the performance at a low cost.

    With revolutionized system architecture, the Huawei USG9500 security gateway series has the industry's highest firewall throughput and the most concurrent connections. With dedicated traffic splitting technology, the overall performance of the USG9500 increases linearly with the addition of SPUs. The USG9500 delivers a maximum of 960 Gbps large-packet throughput, 960 million concurrent connections, and 4096 virtual firewalls. The industry leading performance can meet the performance demand of high-end customers, such as television and broadcast systems, government agencies, energy companies, and education organizations.

    Quick Specs

    Figure 1 shows the appearance of USG9560-BASE-DC-V3.

    USG9560-BASE-DC-V3 Appearance

    Table 1 shows the Quick Specs.

    Model

    USG9560-BASE-DC-V3

    Part Number

    0235G7F7

    Description

    USG9560 DC Basic Configuration(include X8 DC Chassis,2*SRU,1*SFU)

    Firewall Throughput (maximum)*

    720 Gbit/s

    Firewall Throughput (IMIX Traffic)

    720 Gbit/s

    Maximum Number of Concurrent Sessions

    720 million

    IPSec VPN Performance (1,420 Bytes)

    336 Gbit/s

    Maximum Number of Concurrent IPSec Tunnels

    768,000

    IPS Performance

    209 Gbit/s

    Antivirus Performance

    187 Gbit/s

    Expansion Slots

    8 slots

    Number of MPU Slots

    2

    Pack Weight(kg)

    100

    Pack Volume(m^3)

    0.459

    Pack Dimension(D*W*H mm)

    885*640*810

    Net Dimension(D*W*H mm)

    442*650*620

    Typic Power(W)

    439

    Power consumption

    1,270W

    The Modules, Cards, Licenses

    Table 2 shows the recommended elements for the USG9560-BASE-DC-V3.

    Category

    Model

    Description

    SRU

    E8KE-X8-SRUA-200

    X8 200Gbps Switch and Route Processing Unit A

    SFU

    E8KE-X8-SFUC-200

    X8 200Gbps Switch Fabric Unit C

    SPU and SPC

    SPU-X3-B

    X3 Service Processing Unit(Base Board)

    SPU-X3-20-O-E8KE

    20G X3 Firewall Service Processing Unit(oversea)

    SPC-IPS-20



    IPS Service Processing Card

    LPUF-120 and FPIC



    E8KE-X-101-24XGE-SFP



    24-Port 100/1000Base-X-SFP Flexible Card(P101,1/2wide,Occupy two sub-slots)

    E8KE-X-101-1X40GE-CFP



    1-Port 40GBase LAN CFP Flexible Card(P101,1/2wide,Occupy two sub-slots)

    Compare to Similar Items

    Table 3 shows the comparison of USG9520-BASE-AC-V3, USG9560-BASE-DC-V3 and USG9580-BASE-DC-V3.

    Product

    USG9520-BASE-AC-V3

    USG9560-BASE-DC-V3

    USG9580-BASE-DC-V3

    Expansion Slots

    3

    8

    16

    Maximum Firewall Throughput

    120 Gbit/s

    720 Gbit/s

    1.44 Tbit/s

    Maximum Number of Concurrent Sessions

    120 million

    720 million

    1.44 billion

    Basic Functions

    Routing/Transparent/Composite mode, state validation detection, blacklist and whitelist, access control, Application Specific Packet Filter (ASPF), security zone division, virtual firewall, smart route, and load balancing

    NAT/CGN

    Destination NAT/PAT, NAT NO-PAT, source NAT-IP address persistency, source IP address pool grouping, NAT Server, bi-directional NAT, NAT-ALG (Application Layer Gateway), unlimited IP address expansion, policy-based destination NAT, port range pre-allocation, hair pinning mode, SMART NAT, NAT64, DS-Lite, and 6RD (IPv6 Rapid Deployment)

    NGFW Functions

    Supports intrusion detection and prevention, URL filtering, antivirus, data loss prevention, etc.

    PKI

    PKI certificate requests (PKCS 10), Certificate Authority (CA)

    PKI authentication: EAP-SIM, EAP-AKA

    PKI protocol: SCEP, OCSP, and CMPv2
    Self-signed certificate

    Virtual System

    4,096-Virtual Firewall (VFW) definition, VLAN virtualization, security zones virtualization, user-defined virtual resources, route between VFW, and VFW-based traffic CAR

    DDoS Mitigation

    SYN-flood, ICMP-flood, TCP-flood, UDP-flood, and DNS-flood

    Port-scan, Smurf, Tear-drop, and IP-Sweep

    IPv6-extension-header defense, TTL detection, TCP-mss detection, and attack log output

    Get more information

    Do you have any question about the USG9560-BASE-DC-V3

    Contact us now via Live Chat or [email protected].

    Quality Certifications

    • ISO 14001
    • ISO 9001
    • RoHS
    • REACH
    • CE
    • FCC
    Specification

    Huawei USG9560-BASE-DC-V3 Specification

    USG9560 Specifications

    Performance and Capacity

    Firewall Throughput (maximum)*

    720 Gbit/s

    Firewall Throughput (IMIX Traffic)

    720 Gbit/s

    Maximum Number of Concurrent Sessions

    720 million

    IPSec VPN Performance (1,420 Bytes)

    336 Gbit/s

    Maximum Number of Concurrent IPSec Tunnels

    768,000

    IPS Performance

    209 Gbit/s

    Antivirus Performance

    187 Gbit/s

    Expansion and I/O

    Expansion Slots

    8 slots

    Number of MPU Slots

    2

    Interface Types

    GE, 10 GE, 40 GE, and 100 GE interfaces

    SPU

    Firewall and application security SPUs

    Dimensions, Power Supply, and Operating Environment

    Dimensions (H x W x D)

    175 mm x 442 mm x 650 mm DC

    220 mm x 442 mm x 650 mm DC

    Weight

    Vacant chassis: 15 kg, DC

    Full configuration: 30.7 kg, DC

    Vacant chassis: 25 kg, AC

    Full configuration: 40.7 kg, AC

    Redundant Power Supply

    Standard configuration

    AC Power Supply

    90V AC to 264V AC; 175V AC to 264V AC (recommended)

    DC Power Supply

    -38V to -72V; Rated -48V

    Power consumption

    3,960W

    Operating Temperature

    Long-term: 0°C to 45°C

    Short-term: -5°C to 55°C

    Storage: -40°C to 70°C

    Ambient Humidity

    Long-term: 5% RH to 85% RH, non-condensing

    Short-term: 5% RH to 95% RH, non-condensing

    Storage: 0% RH to 95% RH, non-condensing

    Quality Certifications

    Need Help? Technical Experts Available Now.

    • +1-626-655-0998 (USA)
      UTC 15:00-00:00
    • +852-2592-5389 (HK)
      UTC 00:00-09:00
    • +852-2592-5411 (HK)
      UTC 06:00-15:00
    Get a Quote
    Live Chat
    Need Help? Technical Experts Available Now.
    Q&A

    Questions & Answers

    What accessories are available for the USG9560-BASE-DC-V3?

    Accessories include additional SRUs, SFUs, power supply units, and rack-mount kits.

    How cost-effective is the USG9560-BASE-DC-V3?

    The USG9560-BASE-DC-V3 offers a balance of cost and performance, making it a cost-effective choice for large-scale network security.

    What is included in the basic configuration of the USG9560-BASE-DC-V3?

    The basic configuration includes an X8 DC chassis, 2 SRUs, and 1 SFU, providing a solid foundation for deployment.
