TNNS0VBSWF15, Huawei OptiX OSN 7500 Software License, V200R015/Per Subrack

Brand: Huawei
Model: TNNS0VBSWF15

1 Questions

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Talk to an Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

TNNS0VBSWF15, Huawei OptiX OSN 7500 Software License, V200R015/Per Subrack

100% Genuine Ready to Ship

Overview

Huawei TNNS0VBSWF15 Overview

The Huawei TNNS0VBSWF15 OptiX OSN 7500 II basic software license is a carrier-grade networking platform license designed for multi-service transport in metro and backbone networks. Delivered per subrack with V200R015 system software, it enables full MSTP and OTN capabilities, high switch capacity, and rich Ethernet, SDH, PDH, and WDM interfaces. This license is ideal for operators and integrators standardizing on Huawei OSN 7500 II for scalable packet and TDM transport.

Product Highlights

560Gbit/s

OTN Core

320Gbit/s

Packet Cap

32 Slots

Dense IO

Product Applications Scenarios

Service Providers

The OSN 7500 II software license enables high-capacity packet+SDH transport, helping carriers scale backbone and metro rings while reducing downtime and simplifying multi-service provisioning for converged networks.

Enterprise Network

For large enterprises, the license activates rich Ethernet, SAN, and PCM interfaces, consolidating legacy TDM and modern IP services, cutting separate platform costs and easing centralized management.

Public Infrastructure

In transport, utilities, and government backbones, advanced QoS, MPLS-TP protection, and SDH/ASON resilience ensure mission-critical communications stay available and predictable under heavy load.

Product Features Comparison


Model	TNNS0VBSWF15, Huawei OptiX OSN 7500 Software License, V200R015/Per Subrack	TNNS0PFUNC01, Huawei OSN 7500 II License, Packet Function/License/OSN 7500 II	SSNS0VBSWF01, Huawei OptiX OSN 3500 Software License, V100R003 Per Subrack	TNVS0000SW05, Huawei OptiX 9800 Universal Platform, Subrack/Basic Software/V100R002
Brand	Huawei	Huawei	Huawei	Huawei
Licensed Feature	OptiX OSN 7500 II-Basic Software Package,V200R015(Per Subrack)	Packet Function License for OSN 7500 II	OptiX OSN 3500 Software License, V100R003 Per Subrack	OptiX 9800 Universal Platform Basic Software Package, V100R002
License Term	n/a	n/a	n/a	n/a
Supported Devices	OSN 7500 II	OSN 7500 II	OptiX OSN 3500	OptiX 9800 Universal
Activation Method	n/a	n/a	n/a	n/a
User Limit	n/a	n/a	n/a	n/a

Optional Add-ons

Model Number	Description
TNNS0PFUNC01	Huawei OSN 7500 II Packet Function License enabling advanced packet features on OSN 7500 II platforms.
NDSSPACKET03	Huawei OptiX OTN PACKET Function Fee License for per-subrack packet transport enhancement.
SS4-SW-Update	Huawei OptiX Metro 1000 software release update license for R(N)->R(N+1) per subrack upgrades.

Quality Certifications

Specification

Huawei TNNS0VBSWF15 Specification

Model

TNNS0VBSWF15

Brand

Huawei

Part Number

88032XCR

Description

OptiX OSN 7500 II-Basic Software Package,V200R015(Per Subrack)

Discount Category

Basic Software

Product Line

Networking

Sub Product Family

MSTP

Product Series

OSN 7500 II

UOM

PCS

Dimensions

800mm (H) x 496mm (W) x 295mm (D)

Switch Capacity

Packet: 320 Gbit/s and TDM: 360 Gbit/s (higher order), 40 Gbit/s (lower order), OTN: 560Gbit/s

Service Slots

32 slots, 16 slots for interface boards and 16 slots for processing boards with same bandwidth per slot

Ethernet interface

FE/GE/10GE/40GE

SDH interface

STM-1/4/16/64

PDH interface

E1/T1, E3/T3, E4

ATM interface

E1, STM-1

WDM interface

40 DWDM wavelengths, compliant with ITU-T G.694.1 8 CWDM wavelengths, compliant with ITU-T G.694.2

SAN interface

FDDI, ESCON, FICON/FICON Express, FC100/200/400/800/1200

PCM interface

FXS/FXO, 2/4W VF & E&M X.21/V.35/V.11/V.24/V.28, RS232/RS422, RS449/RS423A/RS422A, RS530/RS530A,RS485, G.703 64 kbit/s codirectional

Other interface

DDN, Video

Networking Mode

Supports packet, hybrid (packet + SDH or OTN + SDH) or SDH networking Supporting WDM networking Supporting single-fiber bidirectional transmission

Power Supply

48V DC/-60V DC

Ethernet Feature

E-Line and E-LAN, QinQ MPLS-TP based VPWS and VPLS Multi-section pseudo-wire (MS-PW) ETH PWE3, TDM PWE3, A TM/IMA PWE3 IGMP Snooping V2 Blacklist, Broadcast packet suppression, ACL VLAN SWAP

PCM Feature

Voice or data Conference/Meeting,P2MP,MP2MP FXO/FXS mode can be set by software E&M Interface voltage can be set by software (-48V/-12V) E&M signaling can be set by software (Bell types I, II, III, IV, V and British Telecom SSDC5)

QoS

Hierarchical QoS scheduling and traffic shaping DiffServ mode based on traffic classification, eight priority queues Simple traffic classification, complex traffic classification, per hop behavior (PHB),and A CL Committed access rate (CAR), shaping based on port scheduling priority PQ scheduling priority, weighted fair queuing (WFQ) and PQ+WFQ queuing Tail drop and weighted random early detection (WRED)

MPLS OAM

LSP/PW OAM: FDI, BDI,CV, FFD, TraceRoute, Ping, LM, DM PW OAM: CES PW VCCV

Ethernet OAM

ETH-CC, ETH-Loopback, ETH-Link Trace, Remote Loopback, Remote Fault Detection, RMON(RFC 2819)

MPLS-TP based Service Protection

LSP/PW Linear protection, Ring protection Anti multifailure protection based on MS-PW LAG, MC-LAG, Dual-homing protection, LPT

SDH based Service Protection

2/4 fiber MS-SP Ring; 1+1/1:n (n SNCP/SNCTP Tributary protection for E1/T1, E3/T3, E4, STM-1(e) and FE

ASON

Distributed restorable rerouting protection 5-level service dedicated protection scheme based on different SLA: Diamond, Gold, Silver, Copper and Iron services Based on VC-4 and VC-12 granularity

Synchronization

Both Ethernet and SDH networks supporting clock synchronization Supporting G.813, Synchronous Ethernet and IEEE 1588v2 synchronization Adaptive clock recovery (ACR) Two external clock inputs/outputs (2MHz or 2 Mbit/s) Two external time signals (1pps+TOD)
