main product photo

TNN1HUNS307, Huawei Smart Line Service Board, 40G bandwidth/Tx -7dBm~2.3dBm/Rx -13.7dBm

  • Brand: Huawei
  • Model: TNN1HUNS307
  • 100% Genuine
    100% Genuine
    Original, factory-verified
    3-Year Warranty
    3-Year Warranty
    Extended, enterprise-grade
    23 Years Expertise
    24 Years Expertise
    Proven, deployment-focused
    • Condition
    • Original New
    expert
    Certified Expertise Builds Trust
    CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert
    Talk to an Expert
    • Faster Delivery, Globally Ready

      Faster Delivery, Globally Ready

      20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.

      48H Worldwide Shipping
      10+ Global Warehouses
    • Keep Projects On Time

      Keep Projects On Time

      Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.

      Track Your Order
    • Leading Global Distributor Since 2002

      Leading Global Distributor
      Since 2002

      A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

        21500+ Enterprise Clients Served200+ Countries & Regions Covered
    • Worry-Free Coverage with RSCare

      Worry-Free Coverage with RSCare

      3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.

      Cisco SmartNet
      HPE Foundation Care
      Dell ProSupport
      Juniper Care
      Fortinet Support
    • Your Trusted Genuine Source

      Your Trusted Genuine Source

      Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.

      100% Authentic Products
      100,000+ Multi-Brand SKUs Available
    TNN1HUNS307, Huawei Smart Line Service Board, 40G bandwidth/Tx -7dBm~2.3dBm/Rx -13.7dBm

    TNN1HUNS307, Huawei Smart Line Service Board, 40G bandwidth/Tx -7dBm~2.3dBm/Rx -13.7dBm

    100% Genuine Ready to Ship
    Overview
    Specification
    Reviews
    Q&A
    Warranty
    Download
    Overview

    Huawei TNN1HUNS307 Overview

    The Huawei TNN1HUNS307 is a carrier-grade smart 40G line service processing board designed for OSN 7500 II MSTP and WDM transport networks. It delivers 40G bandwidth with coherent optical performance, supporting FE/GE/10GE/40GE Ethernet, SDH, PDH, ATM, SAN, PCM and WDM interfaces on a single platform. With packet, SDH and OTN hybrid networking, advanced QoS, MPLS-TP, Ethernet OAM, ASON, and IEEE 1588v2 synchronization, the TNN1HUNS307 enables high-capacity, protected multiservice backbones for service providers and large enterprises.

    Product Highlights

    40Gbit/s
    Line Rate
    560Gbit/s
    OTN Xcap
    142W
    Low Power

    Product Applications Scenarios

    Service Providers
    The TNN1HUNS307 aggregates PDH, SDH, Ethernet and SAN services onto a resilient WDM backbone, reducing transport layers and cutting long-haul bandwidth costs by up to 30% for regional and national carriers.
    Enterprise Network
    In large campus and HQ data hubs, the board consolidates legacy E1/T1, video and 10GE/40GE traffic with strict QoS and protection schemes, improving backbone utilization while simplifying multi-service management.
    Public Infrastructure
    For transportation, power and government networks, its ASON, MPLS-TP and SDH protection ensure sub-50 ms recovery for mission-critical services, helping operators meet stringent SLA and regulatory targets.

    Product Features Comparison

    Huawei TNN1HUNS307, Huawei Smart Line Service Board, 40G bandwidth/Tx -7dBm~2.3dBm/Rx -13.7dBm Huawei TN15OPM801, Huawei OptiXtrans, 8ch optical power monitor, C_Band, 37.5-400GHz Huawei TNU1N402PT53, Huawei TNU1N Series Line Service Board, 2×100G/200G or 1×400G, Programmable, Coherent, LC Huawei TN58NS4T51, Huawei TN58NS4T51 Line Service Processing Board, 100Gbit/s, Coherent, Tunable
    Model TNN1HUNS307, Huawei Smart Line Service Board, 40G bandwidth/Tx -7dBm~2.3dBm/Rx -13.7dBm TN15OPM801, Huawei OptiXtrans, 8ch optical power monitor, C_Band, 37.5-400GHz TNU1N402PT53, Huawei TNU1N Series Line Service Board, 2×100G/200G or 1×400G, Programmable, Coherent, LC TN58NS4T51, Huawei TN58NS4T51 Line Service Processing Board, 100Gbit/s, Coherent, Tunable
    Brand Huawei Huawei Huawei Huawei
    Module Type n/a n/a Programable Line Service Processing Board n/a
    Port Configuration n/a n/a 2*100G/200G or 1*400G n/a
    Supported Speed Switch Capacity Packet: 320 Gbit/s and TDM: 360 Gbit/s (higher order), 40 Gbit/s (lower order), OTN: 560Gbit/s n/a Max Line Capacity 400G Rate per Channel (maximum) 100G/ 200G
    Compatible Platform Product Series OSN 7500 II Product Series OptiX OSN 8800 n/a OptiX OSN 8800 UPS
    Installation Type n/a Mounting Type Rack Mountable Dimensions Standard Line Card n/a

    Optional Add-ons

    Model Number Description
    TN15OPM801 Huawei OptiX OSN 8800 8-channel C-Band optical power monitor board for integrated WDM performance monitoring with TNN1HUNS307 line services.
    TN11MR405 Huawei 4-channel OADM board for adding and dropping DWDM wavelengths alongside TNN1HUNS307 in metro and long-haul rings.
    TN11DCU11 Huawei dispersion compensation unit for G.655 fiber, used with TNN1HUNS307 links to optimize long-distance optical transmission.

    Quality Certifications

    • ISO 14001
    • ISO 9001
    • RoHS
    • REACH
    • CE
    • FCC
    Specification

    Huawei TNN1HUNS307 Specification

    Model
    TNN1HUNS307
    Brand
    Huawei
    Part Number
    03055299
    Description
    Smart 40G Line Service Processing Board (SH,Tx_-7dBm~2.3dBm,Rx_-13.7dBm,LC)
    Discount Category
    PID Hardware
    Product Line
    Networking
    Sub Product Family
    MSTP
    Product Series
    OSN 7500 II
    UOM
    PCS
    Net Dimension(D*W*H mm)
    261*267*50
    Typic Power(W)
    142
    Dimensions
    800mm (H) x 496mm (W) x 295mm (D)
    Switch Capacity
    Packet: 320 Gbit/s and TDM: 360 Gbit/s (higher order), 40 Gbit/s (lower order), OTN: 560Gbit/s
    Service Slots
    32 slots, 16 slots for interface boards and 16 slots for processing boards with same bandwidth per slot
    Ethernet interface
    FE/GE/10GE/40GE
    SDH interface
    STM-1/4/16/64
    PDH interface
    E1/T1, E3/T3, E4
    ATM interface
    E1, STM-1
    WDM interface
    40 DWDM wavelengths, compliant with ITU-T G.694.1 8 CWDM wavelengths, compliant with ITU-T G.694.2
    SAN interface
    FDDI, ESCON, FICON/FICON Express, FC100/200/400/800/1200
    PCM interface
    FXS/FXO, 2/4W VF & E&M X.21/V.35/V.11/V.24/V.28, RS232/RS422, RS449/RS423A/RS422A, RS530/RS530A,RS485, G.703 64 kbit/s codirectional
    Other interface
    DDN, Video
    Networking Mode
    Supports packet, hybrid (packet + SDH or OTN + SDH) or SDH networking Supporting WDM networking Supporting single-fiber bidirectional transmission
    Power Supply
    48V DC/-60V DC
    Ethernet Feature
    E-Line and E-LAN, QinQ MPLS-TP based VPWS and VPLS Multi-section pseudo-wire (MS-PW) ETH PWE3, TDM PWE3, A TM/IMA PWE3 IGMP Snooping V2 Blacklist, Broadcast packet suppression, ACL VLAN SWAP
    PCM Feature
    Voice or data Conference/Meeting,P2MP,MP2MP FXO/FXS mode can be set by software E&M Interface voltage can be set by software (-48V/-12V) E&M signaling can be set by software (Bell types I, II, III, IV, V and British Telecom SSDC5)
    QoS
    Hierarchical QoS scheduling and traffic shaping DiffServ mode based on traffic classification, eight priority queues Simple traffic classification, complex traffic classification, per hop behavior (PHB),and A CL Committed access rate (CAR), shaping based on port scheduling priority PQ scheduling priority, weighted fair queuing (WFQ) and PQ+WFQ queuing Tail drop and weighted random early detection (WRED)
    MPLS OAM
    LSP/PW OAM: FDI, BDI,CV, FFD, TraceRoute, Ping, LM, DM PW OAM: CES PW VCCV
    Ethernet OAM
    ETH-CC, ETH-Loopback, ETH-Link Trace, Remote Loopback, Remote Fault Detection, RMON(RFC 2819)
    MPLS-TP based Service Protection
    LSP/PW Linear protection, Ring protection Anti multifailure protection based on MS-PW LAG, MC-LAG, Dual-homing protection, LPT
    SDH based Service Protection
    2/4 fiber MS-SP Ring; 1+1/1:n (n SNCP/SNCTP Tributary protection for E1/T1, E3/T3, E4, STM-1(e) and FE
    ASON
    Distributed restorable rerouting protection 5-level service dedicated protection scheme based on different SLA: Diamond, Gold, Silver, Copper and Iron services Based on VC-4 and VC-12 granularity
    Synchronization
    Both Ethernet and SDH networks supporting clock synchronization Supporting G.813, Synchronous Ethernet and IEEE 1588v2 synchronization Adaptive clock recovery (ACR) Two external clock inputs/outputs (2MHz or 2 Mbit/s) Two external time signals (1pps+TOD)

    Get more information

    Discover unbeatable prices and fast shipping for the TNN1HUNS307, Huawei Smart Line Service Board, 40G bandwidth/Tx -7dBm~2.3dBm/Rx -13.7dBm . Access the detailed TNN1HUNS307, Huawei Smart Line Service Board, 40G bandwidth/Tx -7dBm~2.3dBm/Rx -13.7dBm datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

    Quality Certifications

    Need Help? Technical Experts Available Now.

    • +1-626-655-0998 (USA)
      UTC 15:00-00:00
    • +852-2592-5389 (HK)
      UTC 00:00-09:00
    • +852-2592-5411 (HK)
      UTC 06:00-15:00
    Get a Quote
    Live Chat
    Need Help? Technical Experts Available Now.
    Q&A

    Questions & Answers

    What accessories are available for TNN1HUNS307?

    Accessories include compatible LC fiber optic cables, Huawei compatible chassis, and transceivers.

    How does TNN1HUNS307 compare to similar products?

    The TNN1HUNS307 offers a unique balance of Tx and Rx power ranges, and compatibility with LC connectors, distinguishing it from competitors.

    How do I troubleshoot connectivity issues with TNN1HUNS307?

    Verify that the fiber optic cables are securely connected, and check that the Tx and Rx power levels are within the specified ranges for the TNN1HUNS307.
