main product photo

TNN1HUNS306, Huawei Smart 40G Line Service Processing Board, 40G line card/Tx 0~4.5dBm/Rx -22dBm

  • Brand: Huawei
  • Model: TNN1HUNS306
  • 100% Genuine
    100% Genuine
    Original, factory-verified
    3-Year Warranty
    3-Year Warranty
    Extended, enterprise-grade
    23 Years Expertise
    24 Years Expertise
    Proven, deployment-focused
    • Condition
    • Original New
    expert
    Certified Expertise Builds Trust
    CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert
    Talk to an Expert
    • Faster Delivery, Globally Ready

      Faster Delivery, Globally Ready

      20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.

      48H Worldwide Shipping
      10+ Global Warehouses
    • Keep Projects On Time

      Keep Projects On Time

      Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.

      Track Your Order
    • Leading Global Distributor Since 2002

      Leading Global Distributor
      Since 2002

      A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

        21500+ Enterprise Clients Served200+ Countries & Regions Covered
    • Worry-Free Coverage with RSCare

      Worry-Free Coverage with RSCare

      3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.

      Cisco SmartNet
      HPE Foundation Care
      Dell ProSupport
      Juniper Care
      Fortinet Support
    • Your Trusted Genuine Source

      Your Trusted Genuine Source

      Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.

      100% Authentic Products
      100,000+ Multi-Brand SKUs Available
    TNN1HUNS306, Huawei Smart 40G Line Service Processing Board, 40G line card/Tx 0~4.5dBm/Rx -22dBm

    TNN1HUNS306, Huawei Smart 40G Line Service Processing Board, 40G line card/Tx 0~4.5dBm/Rx -22dBm

    100% Genuine Ready to Ship
    Overview
    Specification
    Reviews
    Q&A
    Warranty
    Download
    Overview

    Huawei TNN1HUNS306 Overview

    The Huawei TNN1HUNS306 is a carrier-grade Smart 40G line service processing board for OSN 7500 II multiservice transport platforms. It delivers 40G line capacity with LH optical performance (Tx 0–4.5dBm, Rx -22dBm) and integrates a 10G license to flexibly handle FE/GE/10GE/40GE services. Supporting packet, SDH, and OTN networking with rich WDM, PDH, ATM, SAN, and PCM interfaces, this MSTP module enables converged transmission for metro, backbone, and data transport networks across diverse operator and enterprise environments.

    Product Highlights

    40G line
    Line Speed
    560G OTN
    OTN Core
    320G pkt
    Pkt Switch

    Product Applications Scenarios

    Service Providers
    The TNN1HUNS306 aggregates FE/GE/10GE/40GE, SDH, and OTN traffic with 560Gbit/s OTN switching, helping carriers build converged metro and backbone transport, reduce legacy SDH overlay costs, and improve protection and QoS for premium SLA services.
    Enterprise Network
    In large enterprise networks, the board delivers high-capacity packet and TDM grooming, supporting SAN, PCM, and Ethernet interfaces to consolidate data, storage, and voice transport, cutting leased-line complexity and improving uptime.
    Data Center
    For regional and carrier data centers, its 40GE and 10GE support with WDM interfaces enables scalable interconnects and resilient backup links, enhancing bandwidth utilization while maintaining strict synchronization and low-latency transport.

    Product Features Comparison

    Huawei Huawei Huawei Huawei
    Model TNN1HUNS306, Huawei Smart 40G Line Service Processing Board, 40G line card/Tx 0~4.5dBm/Rx -22dBm H83D00UP2AA1, Huawei H83D00UP2AA1 Interface Card, 2×EPON/GPON/GE/TypeC NSDS000T3203, Huawei OptiX OSN 8800T32, Subrack Speedup/100G Bus/100G OTN TNM1CXL01, Huawei TNM1CXL Series Optical Interface Board, 1xSTM1(S-1.1,LC)/20G HO Cross-connect/5G LO Cross-connect
    Brand Huawei Huawei Huawei Huawei
    Module Type Smart 40G Line Service Processing Board (LH,Tx_0dBm~4.5dBm,Rx_-22dBm,LC,with 10G license) EPON/GPON/GE TypeC Uplink Interface Card Standard Subrack Speedup, 100G Bus for 100G OTN (Per Subrack) TNM1CXL Series Optical Interface Board, System Control and Cross-connection
    Port Configuration FE/GE/10GE/40GE; SDH STM-1/4/16/64; PDH, ATM, WDM, SAN, PCM, DDN, Video Network-side Ports: GPON/GE; User-side Ports: ADSL2+, VDSL2, POTS, G.SHDSL, E1, ISDN, FE, GE Supports OTN, SDH, and Ethernet modules (Subrack-level backplane) 1xSTM1(S-1.1, LC) with SDH optical interface
    Supported Speed Packet: 320 Gbit/s; TDM: 360 Gbit/s HO, 40 Gbit/s LO; OTN: 560 Gbit/s GE/GPON uplink; multiple DSL and E1 access rates Up to 100Gbps transmission rate 155Mbps (STM-1)
    Compatible Platform OSN 7500 II MSTP, Networking product line Huawei MA5616 series Huawei OptiX OSN 8800T32 Huawei optical transmission systems using TNM1CXL series
    Installation Type Installed in OSN 7500 II service slot, packet/hybrid/SDH networking Installed in MA5616 subrack, FTTx and Cable sub product family Standard subrack speedup chassis for OSN 8800T32 Board form factor, rack-mounted within host system

    Optional Add-ons

    Model Number Description
    SST1PSXCSA02 Huawei OSN 7500 360G TDM/160G packet switching and synchronous timing board for high-capacity cross-connect.
    TN52SCC02 Huawei OSN 9800 system control and communication board providing main control, management, and communication.
    SSN3GSCC Huawei OptiX OSN series system control board with built-in clock and Gigabit Ethernet management ports.

    Quality Certifications

    • ISO 14001
    • ISO 9001
    • RoHS
    • REACH
    • CE
    • FCC
    Specification

    Huawei TNN1HUNS306 Specification

    Model
    TNN1HUNS306
    Brand
    Huawei
    Part Number
    03055300
    Description
    Smart 40G Line Service Processing Board (LH,Tx_0dBm~4.5dBm,Rx_-22dBm,LC,with 10G license)
    Discount Category
    PID Hardware
    Product Line
    Networking
    Sub Product Family
    MSTP
    Product Series
    OSN 7500 II
    UOM
    PCS
    Net Dimension(D*W*H mm)
    261*267*50
    Typic Power(W)
    142
    Dimensions
    800mm (H) x 496mm (W) x 295mm (D)
    Switch Capacity
    Packet: 320 Gbit/s and TDM: 360 Gbit/s (higher order), 40 Gbit/s (lower order), OTN: 560Gbit/s
    Service Slots
    32 slots, 16 slots for interface boards and 16 slots for processing boards with same bandwidth per slot
    Ethernet interface
    FE/GE/10GE/40GE
    SDH interface
    STM-1/4/16/64
    PDH interface
    E1/T1, E3/T3, E4
    ATM interface
    E1, STM-1
    WDM interface
    40 DWDM wavelengths, compliant with ITU-T G.694.1 8 CWDM wavelengths, compliant with ITU-T G.694.2
    SAN interface
    FDDI, ESCON, FICON/FICON Express, FC100/200/400/800/1200
    PCM interface
    FXS/FXO, 2/4W VF & E&M X.21/V.35/V.11/V.24/V.28, RS232/RS422, RS449/RS423A/RS422A, RS530/RS530A,RS485, G.703 64 kbit/s codirectional
    Other interface
    DDN, Video
    Networking Mode
    Supports packet, hybrid (packet + SDH or OTN + SDH) or SDH networking Supporting WDM networking Supporting single-fiber bidirectional transmission
    Power Supply
    48V DC/-60V DC
    Ethernet Feature
    E-Line and E-LAN, QinQ MPLS-TP based VPWS and VPLS Multi-section pseudo-wire (MS-PW) ETH PWE3, TDM PWE3, A TM/IMA PWE3 IGMP Snooping V2 Blacklist, Broadcast packet suppression, ACL VLAN SWAP
    PCM Feature
    Voice or data Conference/Meeting,P2MP,MP2MP FXO/FXS mode can be set by software E&M Interface voltage can be set by software (-48V/-12V) E&M signaling can be set by software (Bell types I, II, III, IV, V and British Telecom SSDC5)
    QoS
    Hierarchical QoS scheduling and traffic shaping DiffServ mode based on traffic classification, eight priority queues Simple traffic classification, complex traffic classification, per hop behavior (PHB),and A CL Committed access rate (CAR), shaping based on port scheduling priority PQ scheduling priority, weighted fair queuing (WFQ) and PQ+WFQ queuing Tail drop and weighted random early detection (WRED)
    MPLS OAM
    LSP/PW OAM: FDI, BDI,CV, FFD, TraceRoute, Ping, LM, DM PW OAM: CES PW VCCV
    Ethernet OAM
    ETH-CC, ETH-Loopback, ETH-Link Trace, Remote Loopback, Remote Fault Detection, RMON(RFC 2819)
    MPLS-TP based Service Protection
    LSP/PW Linear protection, Ring protection Anti multifailure protection based on MS-PW LAG, MC-LAG, Dual-homing protection, LPT
    SDH based Service Protection
    2/4 fiber MS-SP Ring; 1+1/1:n (n SNCP/SNCTP Tributary protection for E1/T1, E3/T3, E4, STM-1(e) and FE
    ASON
    Distributed restorable rerouting protection 5-level service dedicated protection scheme based on different SLA: Diamond, Gold, Silver, Copper and Iron services Based on VC-4 and VC-12 granularity
    Synchronization
    Both Ethernet and SDH networks supporting clock synchronization Supporting G.813, Synchronous Ethernet and IEEE 1588v2 synchronization Adaptive clock recovery (ACR) Two external clock inputs/outputs (2MHz or 2 Mbit/s) Two external time signals (1pps+TOD)

    Get more information

    Discover unbeatable prices and fast shipping for the TNN1HUNS306, Huawei Smart 40G Line Service Processing Board, 40G line card/Tx 0~4.5dBm/Rx -22dBm . Access the detailed TNN1HUNS306, Huawei Smart 40G Line Service Processing Board, 40G line card/Tx 0~4.5dBm/Rx -22dBm datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

    Quality Certifications

    Need Help? Technical Experts Available Now.

    • +1-626-655-0998 (USA)
      UTC 15:00-00:00
    • +852-2592-5389 (HK)
      UTC 00:00-09:00
    • +852-2592-5411 (HK)
      UTC 06:00-15:00
    Get a Quote
    Live Chat
    Need Help? Technical Experts Available Now.
    Q&A

    Questions & Answers

    What accessories are available for the TNN1HUNS306?

    Accessories include compatible LC connectors, fiber optic cables, and additional licenses.

    How does TNN1HUNS306 compare to similar products?

    The TNN1HUNS306 offers superior performance in 40G line processing with specific features like its transmission and reception ranges.

    How is the TNN1HUNS306 used in network environments?

    TNN1HUNS306 is integrated into network infrastructures to manage and optimize high-speed data transmission and processing tasks.
