901-H550-WW00, Ruckus H550 Access Point, Dual-band Wi-Fi 6/Wall plate design/802.11ax

The Ruckus 901-H550-WW00 is an enterprise-class, wall-mounted access point engineered to deliver flexible Wi-Fi in dense environments with space-saving design. Leveraging its true dual band architecture, the device supports both 2.4GHz and 5GHz frequencies, allowing simultaneous wireless connectivity for high-density locations. Integrated with advanced 802.11ax technology, also known as Wi-Fi 6, this wall plate AP ensures faster speeds, greater capacity, and improved performance for modern IoT and mobile-first applications. Its robust 2x2:2 MIMO radios are paired with 16 adaptive antenna patterns per band and a maximum physical layer rate of 1,200 Mbps on 5GHz and 574 Mbps on 2.4GHz, making it suitable for hospitality, education, and large-scale deployments. This AP accommodates up to 512 concurrent users and provides 5 x 1GbE Ethernet ports for wired IoT endpoints or network expansion—combining the versatility of switches with secure wireless networking. With support for management through ZoneDirector, SmartZone, Unleashed, and RUCKUS Cloud, the 901-H550-WW00 offers streamlined provisioning regardless of deployment scale. Built-in features like ChannelFly, SmartMesh, and PD-MRC optimize channel utilization and mesh coverage, ensuring always-on connectivity in dynamic enterprise scenarios. Its compact, wall plate form factor is ideal for discreet installation in Asian, European, African, or North American environments, making it the optimal solution for distributors, system integrators, and end users seeking advanced, internationally-compliant networking options.

Product Features Comparison

Model	Ruckus 901-H550-WW00	9U1-R510-WW00	901-R700-WW00	Ruckus 901-C110-AR00
Brand	Ruckus	Ruckus	Ruckus	Ruckus
Wi-Fi Standard	802.11ax (5GHz) 802.11ax (2.4GHz)	802.11ac Wave 2	802.11ac	Dual Band 802.11ac
Maximum Data Rate	1,200 Mbps (5GHz) 574 Mbps (2.4GHz)	867 Mbps (5 GHz) 300 Mbps (2.4 GHz)	Up to 1,300 Mbps	n/a
Supported Frequency Band	Dual band	Dual-band	Dual-Band	2.4GHz and 5GHz
Client Capacity	512	Up to 512 clients per AP	n/a	Up to 100
Network Interface	5 x 1GbE	2 x 1 GbE	Dual Ethernet Ports	1 x 10/100/1000 Mbps port
