Name: OSX010N03
SKU: OSX010N03
Rating: 5 (1 reviews)

Skip to the beginning of the images gallery

Name:	OSX010N03
Model:	OSX010N03 - Huawei OptiX OSN 8800 SFP Module
Brand:	Huawei
Detail:	Optical Transceiver,XFP,1310nm,8.5~10.5Gb/s,-6dBm~-1dBm,-14.4dBm,LC,SM,10km
	Rating: 100% 5/5.0 1 Review
Availability:	Item Backordered
Condition:	New Factory Sealed

Shipping:

Express Shipping to United States
2-6 Days, via DHL, FedEx, UPS, etc.

Payment:

Pay by wire transfer.
Pay with your paypal.
Pay with your webmoney.
Pay with your onafriq.
Pay with your Visa credit card.
Pay with your Mastercard credit card.
Pay with your Discover Card.
Pay by Western Union.

Support:

TZS, XAF, TZS payment.

Safe, Fast, 100% Genuine. Your Reliable IT Partner.
Best Price Assurance, Bulk Savings, Trusted Worldwide.

OSX010N03

Optical Transceiver,XFP,1310nm,8.5~10.5Gb/s,-6dBm~-1dBm,-14.4dBm,LC,SM,10km

Stable Global Supply Chain for Thriving Businesses.

$4,000,000 Inventory
500+ Reliable Vendors
Certified Partnerships
Collaborating with FedEx, UPS, DHL

100,000+ Diverse Products for All Your Needs

Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.

Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.

Projects and Technical Support
Easy Purchasing Supply
Product Lifecycle Protection
Exclusive F4 Team Support

Overview

OSX010N03 Overview

The Huawei OSX010N03 is a high-performance XFP optical transceiver designed for data transmission rates between 8.5 and 10.5 Gb/s. It operates at a wavelength of 1310nm and is suitable for use in single-mode fiber (SM) networks up to 10km. The transceiver ensures efficient and reliable data transfer with LC connectors and offers power levels ranging from -6dBm to -1dBm.

Quick Spec

Form Factor	XFP
Wavelength	1310nm
Data Rate	8.5~10.5Gb/s
Interface	LC
Transceiver Distance	10km

Product Features

● ● High data transmission rate of 8.5~10.5Gb/s
● ● Operates at a wavelength of 1310nm
● ● Long-distance transmission up to 10km
● ● Compatible with single-mode fiber (SM)
● ● Utilizes LC connectors for easy installation

Product Applications

● ● Long-haul telecommunications networks for stable data transmission
● ● High-speed data communication networks within data centers
● ● Network interface cards (NICs) in enterprise networking solutions

Supported Options

Accessory	Model
LC Connector Patch Cable	HLC-10G-1M
Single-Mode Fiber Cable	HSMF-20M
Fiber Clean Kit	HFCK-01

Compare to Similar Items

Model	Differences
OSX010N04	Supports up to 20km transmission
OSX020N03	Operates at a wavelength of 1550nm
OSX010N02	Lower data transmission rate (4.25~6.25Gb/s)

Get more information

For more information about the Huawei OSX010N03, including pricing and the datasheet, please contact us through Live Chat or email us at [email protected]. Check "Huawei OSX010N03" price and "OSX010N03 datasheet", buy "Huawei OSX010N03" with the best price and fast shipping. Free Live Chat support is available.

Quality Certifications

Specification

OSX010N03 Specification

OSX010N03 Specifications
Brand	Huawei
Model	OSX010N03
Product Type	Optical Transceiver
Form Factor	XFP
Wavelength	1310 nm
Data Rate	8.5~10.5 Gb/s
Transmit Power Range	-6 dBm ~ -1 dBm
Receiver Sensitivity	-14.4 dBm
Connector Type	LC
Fiber Type	Single Mode (SM)
Maximum Distance	10 km
Operating Temperature	0°C to 70°C
Digital Diagnostics	Yes
Hot Swappable	Yes
Compliance	IEEE 802.3ae
Max Power Consumption	1.5 W
Laser Safety	Class 1
RoHS	Compliant
Warranty	1 Year
Application	Data Center, Telecommunication
