main product photo
Name:

OSU015B01

Model:OSU015B01 - Huawei OSN 7500 SFP Module
Brand: Huawei
Detail:

BiDi Transceiver,eSFP,1490nm(Tx)1310nm(Rx),125M~2.67Gbps,-5dBm,0dBm,-18dBm,LC,SM,15km,-40~85 degC

Rating:
100%
5/5.0
1 Review
Availability: Item Backordered
Condition:New Factory Sealed
Warranty:3 years warranty
Shipping:
Express Shipping to United States
2-6 Days, via DHL, FedEx, UPS, etc.
United States
Payment:
  • Pay by wire transfer.
  • Pay with your paypal.
  • Pay with your webmoney.
  • Pay with your onafriq.
  • Pay with your Visa credit card.
  • Pay with your Mastercard credit card.
  • Pay with your Discover Card.
  • Pay by Western Union.
More
Support:
TZS, XAF, TZS payment.
  • Safe, Fast, 100% Genuine. Your Reliable IT Partner.
    Safe, Fast, 100% Genuine. Your Reliable IT Partner.
  • Best Price Assurance, Bulk Savings, Trusted Worldwide.
    Best Price Assurance, Bulk Savings, Trusted Worldwide.
Expertise Builds Trust

Expertise Builds Trust

  • 22 Years, 200+ Countries
  • 18000+ Customers/Projects
  • CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts
Ask an Expert Now
24/7 Online Service
  • +1-626-655-0998(USA)
  • +852-25925389(HK)
  • +852-25925411(HK)
Live Chat

Join Partner Network

  • Exclusive Discounts/Service
  • Credit Terms/Priority Supply
In  United States
Partner Today

OSU015B01

BiDi Transceiver,eSFP,1490nm(Tx)1310nm(Rx),125M~2.67Gbps,-5dBm,0dBm,-18dBm,LC,SM,15km,-40~85 degC

Overview
Specification
Reviews
Q&A
Warranty
Download
Stable Global Supply Chain for Thriving Businesses.
  • $4,000,000 Inventory
  • 500+ Reliable Vendors
  • Certified Partnerships
  • Collaborating with FedEx, UPS, DHL
100,000+ Diverse Products for All Your Needs
Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.
Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.
  • Projects and Technical Support
  • Easy Purchasing Supply
  • Product Lifecycle Protection
  • Exclusive F4 Team Support
Overview

OSU015B01 Overview

The Huawei OSU015B01 is a high-performance BiDi Transceiver designed to enhance your networking setup. With its 1490nm (Tx) and 1310nm (Rx) wavelength functionality, it supports data rates ranging from 125M to 2.67Gbps. Ideal for both short and medium-range fiber connections, this eSFP module operates efficiently over single-mode fiber up to 15km, ensuring robust performance in varying temperatures.

Quick Spec

Brand Huawei
Product Name OSU015B01
Wavelength 1490nm(Tx) / 1310nm(Rx)
Data Rate 125M~2.67Gbps
Transmission Distance 15 km

Product Features

  • ● ● Supports asymmetric wavelengths for efficient bi-directional communication
  • ● ● Wide data rate range from 125M to 2.67Gbps
  • ● ● Operates over single-mode fibers (SM)
  • ● ● Wide operating temperature range from -40 to 85 degrees Celsius
  • ● ● Compact eSFP form factor with LC connector

Product Applications

  • ● ● Metropolitan Area Networks (MAN)
  • ● ● Fiber to the home (FTTH) solutions
  • ● ● Enterprise LAN and data center interconnects

Supported Options

Accessory Model
Fiber Patch Cable OSFP-LC-5M
Hot Swappable SFP Cage SFP-CAGE-HS
Dust Cap SFP-DUSTC-01

Compare to Similar Items

Model Differences
Huawei OSU010B01 Wavelengths: 1510nm(Tx) / 1330nm(Rx), shorter distance (10km)
Huawei OSU020B01 Wavelengths: 1550nm(Tx) / 1310nm(Rx), supports up to 20km
Cisco BIDI-1.25G-10D Brand: Cisco, Data rate up to 1.25Gbps, Distance 10km

Get more information

For further details about the Huawei OSU015B01 and its pricing, please contact us through Live Chat or at [email protected]. Check Huawei OSU015B01 price and OSU015B01 datasheet, buy Huawei OSU015B01 transceiver with the best price and fast shipping. Free Live Chat support is available.

Quality Certifications

  • ISO 14001
  • ISO 9001
  • RoHS
  • REACH
  • CE
  • FCC
Specification

OSU015B01 Specification

OSU015B01 Specifications

Brand Huawei
Product Name OSU015B01
Type BiDi Transceiver
Form Factor eSFP
Transmit Wavelength (Tx) 1490nm
Receive Wavelength (Rx) 1310nm
Transmission Speed 125M~2.67Gbps
Max Optical Output Power 0dBm
Min Optical Output Power -5dBm
Sensitivity -18dBm
Interface LC
Media Type Single-Mode Fiber (SM)
Max Transmission Distance 15km
Operating Temperature -40~85°C
Connector LC
Fiber Mode Single-Mode
Digital Diagnostics Yes
Compatibility Multi-Vendor MSA Compatible
Power Supply 3.3V
Power Dissipation <1.5W
Compliance RoHS, CE, FCC
