Is LS-S3328TP-EI-24S-AC cost-effective?

Yes, it's a cost-effective solution with comprehensive features for mid-sized networks.

What are the main features of LS-S3328TP-Ei-24S-AC?

It includes 24 100BASE-X ports, 2 Combo GE ports, and 2 SFP GE ports.

What applications is it suitable for?

Ideal for enterprise networks requiring high-speed connectivity and data transfer.

How do I install LS-S3328TP-EI-24S-AC?

Follow the included installation guide and ensure proper connection to power and network.

Does LS-S3328TP-EI-24S-AC need upgrades?

Periodic firmware updates from Huawei are recommended for optimal performance.

Are there alternative products to LS-S3328TP-EI-24S-AC?

Alternatives include Huawei S5700 series switches with similar port configurations.

What accessories are available for LS-S3328TP-EI-24S-AC?

Accessories include SFP transceivers, power cables, and mounting kits.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

LS-S3328TP-EI-24S-AC, Huawei S3328TP-EI Switch, 24x100BASE-X/2 Combo GE/2 SFP GE/AC 110/220V

Name: LS-S3328TP-EI-24S-AC, Huawei S3328TP-EI Switch, 24x100BASE-X/2 Combo GE/2 SFP GE/AC 110/220V
SKU: LS-S3328TP-EI-24S-AC
Price: 603 USD
Availability: OutOfStock
Rating: 4.5 (2 reviews)

Brand: Huawei
Model: LS-S3328TP-EI-24S-AC

Rating:

90%

4.5/5.0

2 Reviews

11 Questions

$603.00

Price Alert

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Express Shipping to United States
Estimated shipping time: 2–6 business days via DHL, FedEx, UPS and more

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Talk to an Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

LS-S3328TP-EI-24S-AC, Huawei S3328TP-EI Switch, 24x100BASE-X/2 Combo GE/2 SFP GE/AC 110/220V

100% Genuine Ready to Ship

$603.00

Overview

Huawei LS-S3328TP-EI-24S-AC Overview

The Huawei LS-S3328TP-EI-24S-AC is an enterprise-class Layer 2/Layer 3 switch designed for campus aggregation and high-performance fiber access. It delivers 24 x 100Base-FX SFP ports plus Gigabit uplinks, 12.8Gbps switching capacity, and 9.6Mpps forwarding to support converged services in medium and large networks across Asia, Europe, Africa, and North America. With rich IPv4/IPv6 routing, advanced multicast, carrier-grade reliability, and comprehensive QoS and security, it fits distributors, regional system integrators, and demanding enterprise end users seeking scalable, secure optical connectivity.

Product Highlights

24+4

Fiber Ports

12.8Gbps

Switch Cap

9.6Mpps

Fwd Rate

Product Components Breakdown

Front Panel of the Product:

Product Applications Scenarios

Enterprise Network

Ideal as a fiber aggregation switch for multi-site enterprises, delivering stable Layer 3 routing, rich VLAN services, and QoS to cut operational issues and improve uptime.

Service Providers

Used at metro or access edges, the dense 100Base-FX SFP ports and RRPP protection help carriers reduce downtime and simplify FTTx or leased-line aggregation.

Public Infrastructure

Deployed in transportation, education, and government fiber rings, the switch offers 7kV surge protection and robust multicast for CCTV and IP voice services.

Product Features Comparison


Model	LS-S3328TP-EI-24S-AC, Huawei S3328TP-EI Switch, 24×100BASE-X/2 Combo GE/2 SFP GE/AC 110/220V	S3700-28TP-EI-MC-AC, Huawei S3700 Switch, 24×10/100Base-T/2×GE SFP/AC Power	WS-C3560CG-8TC-S, Cisco Catalyst 3560-C Switch, 8×GE/2×Dual Uplink/IP Base	OS6900-X40-F
Brand	Huawei	Huawei	Cisco	Alcatel-Lucent
Port Configuration	24 x 100Base-FX SFP ports, 2 x 1000Base-X SFP ports, and 2 x Gigabit Combo ports (10/100/1000Base-T or 100/1000Base-X)	24*10/100Base-TX	10	40 x 10 Gigabit SFP+
Switching Capacity	Port Switching Capacity 12.8Gbps; Backplane Switching Capacity 64Gbps	n/a	n/a	Switching capacity: 1.28 Tbps
Forwarding Rate	9.6Mpps	n/a	n/a	Throughput: 960 Mpps
PoE Budget	n/a	n/a	n/a	n/a
Stacking Capability	iStack (except S33HI)	iStack	n/a	Stackable

Optional Add-ons

Model Number	Description
SSP-100FX-SM-MM	Huawei 100BASE-FX SFP module, single-mode/multimode options for LS-S3328TP-EI-24S-AC fiber access
SSX1GLH40-SM	Huawei 1000BASE-LH SFP module, long-distance GE uplink for Huawei S3300/S3328 series switches
AC-POWER-CBL-2M	Huawei compatible 2m AC power cable for enterprise rack-mount switches

Quality Certifications

Specification

Huawei LS-S3328TP-EI-24S-AC Specification

Model

LS-S3328TP-EI-24S-AC

Brand

Huawei

Port

24 x 100Base-FX SFP ports, 2 x 1000Base-X SFP ports, and 2 x Gigabit Combo ports (10/100/1000Base-T or 100/1000Base-X)

Forwarding Performance

9.6Mpps

Port Switching Capacity

12.8Gbps

Backplane Switching Capacity

64Gbps

MAC Address Table

16K MAC address entries, automatic learning and aging, static/dynamic/blackhole MAC entries, packet filtering based on source MAC address

VLAN Features

Up to 4,096 VLANs; guest, voice, and super VLANs; VLAN assignment by MAC, protocol, and IP subnet; basic and selective QinQ; 1:1 and N:1 VLAN switching

Reliability

RRPP ring topology, intersecting rings, multi-instance; Smart Link tree and multi-instance with millisecond-level switchover; STP, RSTP, MSTP; BPDU/root/loopback protection; SEP; BFD for OSPF, IS-IS, VRRP, and PIM

IPv4 Routing

Static routing, RIP v1/v2, ECMP, OSPF, IS-IS, BGP

IPv6 Routing

Static routing, RIPng, OSPFv3

IPv6 Features

Neighbor Discovery (ND), PMTU, IPv6 Ping, IPv6 Tracert, IPv6 Telnet, manually configured tunnels, 6-to-4 tunnels, ISATAP tunnels, ACLs based on source/destination IPv6 address, Layer 4 port, protocol type, MLD v1/v2 snooping

Multicast

1,024 multicast groups; IGMP v1/v2/v3 snooping and fast leave; multicast VLAN and cross-VLAN multicast replication; multicast load sharing on bundled ports; controllable multicast; port-based multicast traffic statistics; IGMP v1/v2/v3, PIM-SM, PIM-DM

QoS / ACL

Rate limiting on sent/received packets per port; packet redirection; port-based traffic policing; two-rate three-color CAR; 8 queues per port; WRR, DRR, SP, WRR+SP, DRR+SP scheduling; WRED (S3300HI only); 802.1p and DSCP remarking; packet filtering based on L2–L4 (source/destination MAC, source/destination IP, port, protocol, VLAN ID); queue-based rate limit and traffic shaping on ports

Security

Hierarchical user management and password protection; DoS, ARP, and ICMP attack defense; IP/MAC/port/VLAN binding; port isolation, port security, sticky MAC, blackhole MAC; limit on learned MAC addresses; IEEE 802.1X authentication and per-port user limit; AAA, RADIUS, HWTACACS+, NAC; SSH v2; CPU protection; blacklisting and whitelisting

Surge Protection

7 kV surge protection per port; up to 15 kV per port with external surge protection device

Management and Maintenance

iStack (except S33HI); MAC Forced Forwarding (MFF); auto-config and HGMP; Telnet remote configuration and maintenance; Virtual Cable Test (VCT); Ethernet OAM (IEEE 802.3ah, 802.1ag); Dying Gasp power-off alarm (S3328TP-EI-MC and S3326C-HI only); local port mirroring, RSPAN, packet forwarding on observing port; SNMP v1/v2/v3, RMON; MUX VLAN, GVRP; NMS and Web management; SSH v2; HTTPS (S3300HI only); 802.3az EEE (S3300HI only); system logs and multi-level alarms

Operating Environment

Operating temperature: 0°C to 50°C (long term), -5°C to 55°C (short term); relative humidity: 10% to 90% (non-condensing)

Power Supply

AC input: rated 100 V to 240 V, 50/60 Hz; maximum 90 V to 264 V, 50/60 Hz

Dimensions (W x D x H)

442mm x 220mm x 43.6mm

Power Consumption

< 55W

Weight

6.17 kg
