H901XGHD01, Huawei MA5800 OLT Interface Board, 8x10G GPON/with Class N1 SFP

Brand: Huawei
Model: H901XGHD01

11 Questions

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Talk to an Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

H901XGHD01, Huawei MA5800 OLT Interface Board, 8x10G GPON/with Class N1 SFP

100% Genuine Ready to Ship

Overview

Huawei H901XGHD01 Overview

The Huawei H901XGHD01 is a carrier-grade 10G GPON OLT interface board for MA5800-X7 platforms, designed for high-density FTTx access in telecom and large enterprise networks. It integrates 8×10G GPON ports with Class N1 SFP optics to deliver ultra-broadband services over existing fiber infrastructure. Backed by a 7 Tbit/s system switching capacity, rich Layer 2/Layer 3 features, MPLS, multicast, and QoS, it enables scalable triple-play, mobile backhaul, and enterprise VPN aggregation across Asia, Europe, Africa, and North America.

Product Highlights

7 Tbit/s

System Cap

262,143

MAC Scale

64K

ARP Route

Product Applications Scenarios

Service Providers

The H901XGHD01 aggregates high-density 10G GPON access, helping service providers deliver converged voice, data, and IPTV while simplifying OLT slots and reducing backbone upgrade costs by up to 25%.

Enterprise Network

In campus and enterprise Metro-E scenarios, the board’s advanced QoS and VRF features support secure VPN access, segmenting services and cutting separate aggregation device needs by around 20%.

Public Infrastructure

For smart city and public infrastructure networks, its multicast and IPv6 dual-stack capabilities enable large-scale IPTV and sensor backhaul, improving fiber utilization and easing phased expansions.

Product Features Comparison


Model	H901XGHD01, Huawei MA5800 OLT Interface Board, 8×10G GPON/with Class N1 SFP	TN51RPC03, Huawei TN51 Series Board, C-Band & Extended C-Band, Forward Raman, Processing Board	H836ASDF, Huawei H836 Series Analog Subscriber DSP Card, 256 channels/Analog support/DSP module	TNFOVOASFP01, Huawei TNFOVOASFP01 Optical Attenuator, 1525~1570nm/0~20dB/LC
Brand	Huawei	Huawei	Huawei	Huawei
Module Type	8-port Advanced 10G GPON OLT Interface Board(including Class N1 SFP Optical Module)	C-Band and Extended C-Band Forward Raman Processing Board	Analog Subscriber DSP Card-256 channels	Variable Optical Attenuator
Port Configuration	112 x GPON/EPON 336 x GE/FE 56 x 10G GPON/10G EPON 56 x 10G GE 224 x E1	n/a	n/a	n/a
Supported Speed	7 Tbit/s	500 mW	n/a	0~20dB
Compatible Platform	MA5800-X7	OptiX OSN 8800	MA5616	n/a
Installation Type	n/a	Hot Swappable	n/a	SFP

Optional Add-ons

Model Number	Description
H901MPUD	Huawei MA5800 series main control board for managing H901XGHD01 GPON service cards
H902PISD	Huawei MA5800 DC power interface board providing redundant power to OLT interface boards
GPFD	Huawei GPON ONT for CPE-side deployment with MA5800/H901XGHD01 OLT platforms

Quality Certifications

Specification

Huawei H901XGHD01 Specification

Model

H901XGHD01

Brand

Huawei

Part Number

02311DHH

Product Description

8-port Advanced 10G GPON OLT Interface Board(including Class N1 SFP Optical Module)

Product Series

MA5800-X7

Dimensions (H x W x D)

442mm x 268.7mm x 263.9mm

Maximum Number of Ports in a Subrack

112 x GPON/EPON 336 x GE/FE 56 x 10G GPON/10G EPON 56 x 10G GE 224 x E1

Switching Capacity of the System

7 Tbit/s

Maximum Number of MAC Addresses

262,143

Maximum Number of ARP/Routing Entries

64K

Ambient Temperature

40°C to 65°C Note: The MA5800 can start up at a lowest temperature of -25°C and run at -40°C. The 65°C temperature refers to the highest temperature measured at the air intake vent

Working Voltage Range

38.4V DC to -72V DC

Layer 2 Features

VLAN + MAC forwarding, SVLAN + CVLAN forwarding, PPPoE+, and DHCP option82

Layer 3 Features

Static route, RIP/RIPng, OSPF/OSPFv3, IS-IS, BGP/BGP4+, ARP, DHCP relay, and VRF

MPLS & PWE3

MPLS LDP, MPLS RSVP-TE, MPLS OAM, MPLS BGP IP VPN, tunnel protection switching, TDM/ETH PWE3, and PW protection switching

IPv6

IPv4/IPv6 dual stack, IPv6 L2 and L3 forwarding, and DHCPv6 relay

Multicast

IGMP v2/v3, IGMP proxy/snooping, MLD v1/v2, MLD Proxy/Snooping, and VLAN-based IPTV multicast

QoS

Traffic classification, priority processing, trTCM-based traffic policing, WRED, traffic shaping, HqoS, PQ/WRR/PQ + WRR, and ACL

System Reliability

GPON type B/type C protection, 10G GPON type B protection, BFD, ERPS (G.8032), MSTP, intra-board and inter-board LAG, In-Service Software Upgrade (ISSU) of the control board, 2 control boards and 2 power boards for redundancy protection, in-service board fault detection and rectification, and service overload control

Get more information

Discover unbeatable prices and fast shipping for the H901XGHD01, Huawei MA5800 OLT Interface Board, 8×10G GPON/with Class N1 SFP . Access the detailed H901XGHD01, Huawei MA5800 OLT Interface Board, 8×10G GPON/with Class N1 SFP datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

Quality Certifications

Need Help? Technical Experts Available Now.

+1-626-655-0998 (USA)
UTC 15:00-00:00
+852-2592-5389 (HK)
UTC 00:00-09:00
+852-2592-5411 (HK)
UTC 06:00-15:00

Get a Quote

Live Chat

Need Help? Technical Experts Available Now.

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

How does the H901XGHD01 compare with similar products in its category?

Compared to similar products, the H901XGHD01 boasts superior data throughput, high port density, and advanced 10G capabilities, making it suitable for demanding network environments.

What are common troubleshooting steps for the H901XGHD01?

Common troubleshooting for the H901XGHD01 includes checking optical module connections, verifying firmware versions, and using Huawei's network management software to diagnose issues.

What are the product's benefits for distributors?

The H901XGHD01 offers distributors a high-demand product with key features like advanced 10G GPON support, making it a strategic addition to their inventory for high-speed network solutions.

Are the products sold on router-switch.com authentic?

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.

Learn More

What is the main feature of the H901XGHD01?

The H901XGHD01 is an advanced 8-port 10G GPON OLT interface board that includes a Class N1 SFP Optical Module, supporting high-speed data transmission.

How cost-effective is the H901XGHD01 for system integrators?

The H901XGHD01 offers excellent performance-to-cost ratio with advanced 10G GPON capabilities and multi-port support, making it a valuable addition to high-capacity network infrastructures.

What are the typical application scenarios for the H901XGHD01?

The H901XGHD01 is ideal for metro networks, campus networks, and large-scale enterprise network environments requiring high bandwidth and reliability.

How do I install the H901XGHD01 into my existing network setup?

The H901XGHD01 can be seamlessly integrated into Huawei's OLT chassis. Make sure to follow the manufacturer's guidelines for slot allocation and cabling.

Does the H901XGHD01 need regular firmware upgrades?

Like most network interface boards, the H901XGHD01 may require periodic firmware upgrades to ensure optimal performance and security. Check the Huawei support site for updates.

Are there alternative products to the H901XGHD01?

Alternatives to the H901XGHD01 include other Huawei OLT interface boards like the H901GPHF and H901GPHC, depending on your specific network requirements.

What accessories are available for the H901XGHD01?

Accessories for the H901XGHD01 may include additional SFP optical modules, power cables, and management tools for monitoring and maintenance.
