What are the key features of the H901XEHD02?

The H901XEHD02 features 8-port advanced 10G EPON OLT interface including PRX30 XFP optical modules, offering high bandwidth and efficient performance.

How cost-effective is the H901XEHD02 for system integrators?

The H901XEHD02 is cost-effective due to its high port density and advanced features, reducing the need for additional hardware.

What are the typical application scenarios for the H901XEHD02?

The H901XEHD02 is ideal for high-bandwidth applications such as IPTV, VoIP, and internet services.

How do you install the H901XEHD02?

The H901XEHD02 can be installed in a compatible chassis by following the user manual's detailed guidelines. It comes with necessary mounting accessories.

Does the H901XEHD02 require software upgrades?

The H901XEHD02 may require software upgrades to ensure optimal performance and compatibility with newer technologies.

What troubleshooting steps are available for the H901XEHD02?

Common troubleshooting includes verifying power supply, checking fiber connections, and updating firmware. Refer to the user manual for detailed steps.

H901XEHD02

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Name:	H901XEHD02
Model:	H901XEHD02 - Huawei MA5800-X7 PON Board
Brand:	Huawei
Detail:	8-port Advanced 10G EPON OLT Interface Board(including PRX30 XFP Optical Module)
	10 Questions
Availability:	Item Backordered
Condition:	New Factory Sealed

Shipping:

Express Shipping to United States
2-6 Days, via DHL, FedEx, UPS, etc.

Payment:

Pay by wire transfer.
Pay with your paypal.
Pay with your webmoney.
Pay with your onafriq.
Pay with your Visa credit card.
Pay with your Mastercard credit card.
Pay with your Discover Card.
Pay by Western Union.

Support:

TZS, XAF, TZS payment.

Safe, Fast, 100% Genuine. Your Reliable IT Partner.
Best Price Assurance, Bulk Savings, Trusted Worldwide.

H901XEHD02

8-port Advanced 10G EPON OLT Interface Board(including PRX30 XFP Optical Module)

Stable Global Supply Chain for Thriving Businesses.

$4,000,000 Inventory
500+ Reliable Vendors
Certified Partnerships
Collaborating with FedEx, UPS, DHL

100,000+ Diverse Products for All Your Needs

Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.

Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.

Projects and Technical Support
Easy Purchasing Supply
Product Lifecycle Protection
Exclusive F4 Team Support

Overview

H901XEHD02 Overview

H901XEHD02 is 8-port Advanced 10G EPON OLT Interface Board(including PRX30 XFP Optical Module).

Quick Spec

Figure 1 shows the appearance of H901XEHD02.

Table 1 shows the quick spec.

Part Number	02311FVD
Model	H901XEHD02
Product Description	8-port Advanced 10G EPON OLT Interface Board(including PRX30 XFP Optical Module)
Product Series	MA5800-X7
Dimensions (H x W x D)	442 mm x 268.7 mm x 263.9 mm
Maximum Number of Ports in a Subrack	112 x GPON/EPON 336 x GE/FE 56 x 10G GPON/10G EPON 56 x 10G GE 224 x E1
Switching Capacity of the System	7 Tbit/s
Maximum Number of MAC Addresses	262,143
Maximum Number of ARP/Routing Entries	64K

Compare to Similar Items

Table 2 shows the comparison between H901XEHD02 and H901GPHF02.

Product Code	H901XEHD02	H901GPHF02
Product Description	8-port Advanced 10G EPON OLT Interface Board(including PRX30 XFP Optical Module)	16-port Advanced GPON OLT Interface Board(including Class C+ SFP Optical Module)
Product Series	MA5800-X7	MA5800-X7
Dimensions (H x W x D)	442 mm x 268.7 mm x 263.9 mm	442 mm x 268.7 mm x 263.9 mm
Maximum Number of Ports in a Subrack	112 x GPON/EPON 336 x GE/FE 56 x 10G GPON/10G EPON 56 x 10G GE 224 x E1	112 x GPON/EPON 336 x GE/FE 56 x 10G GPON/10G EPON 56 x 10G GE 224 x E1

Get more information

Do you have any question about the Huawei H901XEHD02 Access Equipment

Quality Certifications

Specification

H901XEHD02 Specification

H901XEHD02 Specification
Part Number	02311FVD
Model	H901XEHD02
Product Description	8-port Advanced 10G EPON OLT Interface Board(including PRX30 XFP Optical Module)
Product Series	MA5800-X7
Dimensions (H x W x D)	442 mm x 268.7 mm x 263.9 mm
Maximum Number of Ports in a Subrack	112 x GPON/EPON 336 x GE/FE 56 x 10G GPON/10G EPON 56 x 10G GE 224 x E1
Switching Capacity of the System	7 Tbit/s
Maximum Number of MAC Addresses	262,143
Maximum Number of ARP/Routing Entries	64K
Ambient Temperature	-40°C to 65°C Note: The MA5800 can start up at a lowest temperature of -25°C and run at -40°C. The 65°C temperature refers to the highest temperature measured at the air intake vent
Working Voltage Range	-38.4V DC to -72V DC
Layer 2 Features	VLAN + MAC forwarding, SVLAN + CVLAN forwarding, PPPoE+, and DHCP option82
Layer 3 Features	Static route, RIP/RIPng, OSPF/OSPFv3, IS-IS, BGP/BGP4+, ARP, DHCP relay, and VRF
MPLS & PWE3	MPLS LDP, MPLS RSVP-TE, MPLS OAM, MPLS BGP IP VPN, tunnel protection switching, TDM/ETH PWE3, and PW protection switching
IPv6	IPv4/IPv6 dual stack, IPv6 L2 and L3 forwarding, and DHCPv6 relay
Multicast	IGMP v2/v3, IGMP proxy/snooping, MLD v1/v2, MLD Proxy/Snooping, and VLAN-based IPTV multicast
QoS	Traffic classification, priority processing, trTCM-based traffic policing, WRED, traffic shaping, HqoS, PQ/WRR/PQ + WRR, and ACL
System Reliability	GPON type B/type C protection, 10G GPON type B protection, BFD, ERPS (G.8032), MSTP, intra-board and inter-board LAG, In-Service Software Upgrade (ISSU) of the control board, 2 control boards and 2 power boards for redundancy protection, in-service board fault detection and rectification, and service overload control

Quality Certifications

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

Are there alternative products to the H901XEHD02?

Alternatives may include other Huawei OLT interface boards with different port configurations and features, like the H901GTHC.

How does the H901XEHD02 compare with similar products?

The H901XEHD02 offers superior 10G EPON performance with eight ports, while many competitors have fewer ports or lower bandwidth capabilities.

What accessories are available for the H901XEHD02?

Accessories include PRX30 XFP optical modules and necessary mounting hardware provided in the package.

How is the H901XEHD02 used in a network setup?

The H901XEHD02 is used as an OLT interface board in EPON setups for high-speed data transmission between service providers and end-users.
