H901MPLA, Huawei MA5800 Main Processing Board, 2x10GE/1.8 GHz CPU/4GB DDR4

Brand: Huawei
Model: H901MPLA

11 Questions

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Talk to an Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

H901MPLA, Huawei MA5800 Main Processing Board, 2x10GE/1.8 GHz CPU/4GB DDR4

100% Genuine Ready to Ship

Overview

Huawei H901MPLA Overview

The Huawei H901MPLA is a carrier-grade main processing board for MA5800-X7 OLT platforms, delivering centralized control, high-density GPON/EPON aggregation, and advanced Layer 2/Layer 3 service processing for FTTx and IPTV deployments. With 7 Tbit/s system switching capacity, rich MPLS & PWE3 capabilities, and IPv4/IPv6 dual stack support, it enables scalable, multi-service access for service providers and enterprise campus networks in Asia, Europe, Africa, and North America.

Product Highlights

7 Tbit/s

Switch Fab

262,143

MAC Scale

64K

Route Ent

Product Applications Scenarios

Service Providers

The H901MPLA consolidates large GPON, 10G PON, and Ethernet access on MA5800-X7, cutting central office footprint and reducing multi-service OLT deployment costs by up to 30% for regional and national carriers.

Enterprise Network

Advanced Layer 2/Layer 3, QoS, and multicast features enable converged voice, video, and data access, simplifying enterprise campus aggregation while improving SLA assurance for critical services by about 25%.

Public Infrastructure

High port density and robust protection mechanisms support municipal broadband, education, and utility networks, extending fiber-based last-mile coverage and lowering long-term maintenance overhead by roughly 20%.

Product Features Comparison


Model	H901MPLA, Huawei MA5800 Main Processing Board, 2×10GE/1.8 GHz CPU/4GB DDR4	CR52-MPUD, Huawei CR52 Series Main Processing Unit, Dual-core CPU/8GB DDR4/1x40GE QSFP+	WEN11AFBI, Huawei EN11AFBI Power Backplane, 1U height, 2.5U width, Module type	TN11ROP01, Huawei TN11 Series Remote Optical Pump Processing Board, 1×optical port, C-band, 80km
Brand	Huawei	Huawei	Huawei	Huawei
Module Type	Main Processing Board MPLA	Main Processing Unit D	Power Backplane	Remote Optical Pump Processing board
Port Configuration	112 x GPON/EPON; 336 x GE/FE; 56 x 10G GPON/10G EPON; 56 x 10G GE; 224 x E1 (in subrack)	Gigabit Ethernet; 4 x USB 3.0; 2 x PCIe Gen3	1U*2.5U Module	1×optical port
Supported Speed	7 Tbit/s switching capacity; GPON/10G GPON/EPON/10G EPON; GE/10GE	3.2GHz CPU; 16GB DDR4; Gigabit Ethernet	100-240V AC; 600W output	C-band (1525-1565 nm); +23 dBm output
Compatible Platform	MA5800-X7	n/a	Compatible with Huawei systems	n/a
Installation Type	Installed in MA5800 subrack	n/a	Rack-mounted	n/a

Optional Add-ons

Model Number	Description
H80D00VDPM01	Huawei H80D00VDPM01 64-port VDSL2/POTS service board for MA5800 multi-service access
H80D00XGHD	Huawei MA5800 16-port 10G GPON service board for high-bandwidth FTTH deployment
H80D00GPHF	Huawei MA5800 16-port GPON service board for large-scale fiber access expansion

Quality Certifications

Specification

Huawei H901MPLA Specification

Model

H901MPLA

Brand

Huawei

Part Number

03022XTN

Product Description

Main Processing Board MPLA

Product Series

MA5800-X7

Dimensions (H x W x D)

442mm x 268.7mm x 263.9mm

Maximum Number of Ports in a Subrack

112 x GPON/EPON 336 x GE/FE 56 x 10G GPON/10G EPON 56 x 10G GE 224 x E1

Switching Capacity of the System

7 Tbit/s

Maximum Number of MAC Addresses

262,143

Maximum Number of ARP/Routing Entries

64K

Ambient Temperature

40°C to 65°C Note: The MA5800 can start up at a lowest temperature of -25°C and run at -40°C. The 65°C temperature refers to the highest temperature measured at the air intake vent

Working Voltage Range

38.4V DC to -72V DC

Layer 2 Features

VLAN + MAC forwarding, SVLAN + CVLAN forwarding, PPPoE+, and DHCP option82

Layer 3 Features

Static route, RIP/RIPng, OSPF/OSPFv3, IS-IS, BGP/BGP4+, ARP, DHCP relay, and VRF

MPLS & PWE3

MPLS LDP, MPLS RSVP-TE, MPLS OAM, MPLS BGP IP VPN, tunnel protection switching, TDM/ETH PWE3, and PW protection switching

IPv6

IPv4/IPv6 dual stack, IPv6 L2 and L3 forwarding, and DHCPv6 relay

Multicast

IGMP v2/v3, IGMP proxy/snooping, MLD v1/v2, MLD Proxy/Snooping, and VLAN-based IPTV multicast

QoS

Traffic classification, priority processing, trTCM-based traffic policing, WRED, traffic shaping, HqoS, PQ/WRR/PQ + WRR, and ACL

System Reliability

GPON type B/type C protection, 10G GPON type B protection, BFD, ERPS (G.8032), MSTP, intra-board and inter-board LAG, In-Service Software Upgrade (ISSU) of the control board, 2 control boards and 2 power boards for redundancy protection, in-service board fault detection and rectification, and service overload control
