H83MMA5821U3, Huawei H83MMA Series Optical Access Equipment, 8xFE/10G GPON uplink/UK Power Cable

Brand: Huawei
Model: H83MMA5821U3

11 Questions

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Talk to an Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

H83MMA5821U3, Huawei H83MMA Series Optical Access Equipment, 8xFE/10G GPON uplink/UK Power Cable

100% Genuine Ready to Ship

Overview

Huawei H83MMA5821U3 Overview

The Huawei H83MMA5821U3 is carrier-grade 10G GPON remote optical access equipment from the MA5820 series, designed for FTTx and cable deployments. It integrates a single 10G GPON uplink SFP optical port and 8 FE user-side interfaces in a compact 1U chassis, powered by 220V AC with a UK power cable. With an extended operating temperature range from –40°C to 65°C and robust 6 kV surge protection on the power port, this H83MMA5821U3 platform suits harsh outdoor or cabinet environments across Asia, Europe, Africa, and North America. Its flexible PON auto-negotiation and multiple FE/GE/PoE user-side options make it ideal for distributors building scalable access portfolios, small and mid-size integrators delivering last-mile broadband projects, and end users seeking reliable optical access for enterprise branches or multi-dwelling units.

Product Highlights

10G PON

Uplink Speed

8 FE

User Ports

6 kV

Surge Guard

Product Applications Scenarios

Service Providers

The 10G GPON uplink and 8 FE access ports enable cost‑efficient FTTx aggregation, helping operators cut last‑mile deployment costs by up to 30% versus legacy copper.

Enterprise Network

Integrated 10G PON backhaul with temperature‑hardened design supports reliable campus or branch connectivity, reducing downtime and truck rolls for IT teams.

Edge & IoT

Wide –40°C to 65°C range and strong surge protection make it ideal for outdoor cabinets interconnecting IoT gateways, improving edge availability in harsh sites.

Product Features Comparison


Model	H83MMA5821U3, Huawei H83MMA Series Optical Access Equipment, 8×FE/10G GPON uplink/UK Power Cable	SLCI00V1R700, Huawei OptiX RTN 310 Radio Transmission System, V100R007C00/Documentation/Radio Transmission	OSPL47101, Huawei OSPL Series Optical Splitter, 1:16 SC/UPC, G.657A, 0.3m Pigtail	AA11H-NE, Huawei AA11H-NE Microwave Accessory, Antenna Adapter/10G&11G/With English doc
Brand	Huawei	Huawei	Huawei	Huawei
Compatible Models	n/a	n/a	n/a	AA10 & AA11H-NE
Accessory Type	10G GPON Remote Optical Access Equipment	Radio Transmission System	Bare Optical Splitter	Microwave Electric Accessory
Connector Type	One SFP optical port 10G PON or PON (auto-negotiation)	Ethernet and TDM	SC/UPC	N-type
Mounting Method	n/a	19-inch rack mountable	n/a	Panel Mount
Certification	n/a	IEEE, ITU-T, and ETSI standards	n/a	RoHS

Optional Add-ons

Model Number	Description
OSPL47101	Huawei OSPL47101 Bare Optical Splitter, 1:16 SC/UPC, ideal for splitting GPON optical power to multiple H83MMA5821U3-based drops.
OSPL38200	Huawei OSPL38200 Bare Optical Splitter, 2:16 SC/APC PLC, G.657A, 1.5m pigtail for flexible FTTx distribution with MA5820 series.
OSPL3B100	Huawei OSPL3B100 Bare Optical Splitter, 1:64 SC/UPC, supporting high-density GPON access behind MA5820 remote units.

Quality Certifications

Specification

Huawei H83MMA5821U3 Specification

Model

H83MMA5821U3

Brand

Huawei

Part Number

02232FSH

Product Description

10G GPON Remote Optical Access Equipment(AC, 8FE, including single 10G GPON uplink module, including Installation Material and Document, including UK Power Cable)

Product Series

MA5820

Dimensions (H x W x D)

43.6mm x 250mm x 180mm (8 FE) 43.6mm x 442mm x 220mm (16 FE/24 FE)

Operating Environment

–40°C to 65°C 5% RH to 95% RH

Power

AC: 220V

Network-side Ports

One SFP optical port 10G PON or PON (auto-negotiation)

User-side Ports

8 FE 16 FE 24 FE 24 GE PoE

Surge Protection

Power port: 6 kV FE/GE: 4 kV

Sub Product Family

FTTx and Cable

UOM

PCS

Get more information

Discover unbeatable prices and fast shipping for the H83MMA5821U3, Huawei H83MMA Series Optical Access Equipment, 8×FE/10G GPON uplink/UK Power Cable . Access the detailed H83MMA5821U3, Huawei H83MMA Series Optical Access Equipment, 8×FE/10G GPON uplink/UK Power Cable datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

Quality Certifications

Need Help? Technical Experts Available Now.

+1-626-655-0998 (USA)
UTC 15:00-00:00
+852-2592-5389 (HK)
UTC 00:00-09:00
+852-2592-5411 (HK)
UTC 06:00-15:00

Get a Quote

Live Chat

Need Help? Technical Experts Available Now.

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

What accessories are included with this Huawei product?

The H83MMA5821U3 includes a single 10G GPON uplink module, installation materials, documentation, and a UK power cable.

How does the H83MMA5821U3 compare to other 10G GPON equipment?

The H83MMA5821U3 stands out due to its comprehensive accessory package, integrated AC power supply, and 8FE ports, making it a versatile choice.

Is the H83MMA5821U3 suitable for expanding existing networks?

Yes, it provides a scalable solution for expanding enterprise and telecom networks with enhanced 10G GPON uplink capabilities.

Are the products sold on router-switch.com authentic?

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.

Learn More

What makes the H83MMA5821U3 cost-effective?

The H83MMA5821U3 offers high-performance 10G GPON connectivity with integrated AC power and essential accessories, providing a total solution that minimizes additional costs.

What are the main features of this Huawei product?

The H83MMA5821U3 features 10G GPON uplink, 8FE ports, an AC power supply, and comes with necessary installation materials and a UK power cable.

Where can I deploy the H83MMA5821U3?

The H83MMA5821U3 is ideal for remote optical access in enterprise networks and telecommunications service provider infrastructures.

How do I install this 10G GPON remote optical access equipment?

The H83MMA5821U3 comes with installation materials and documentation that guide you through a streamlined setup process.

Does the H83MMA5821U3 need firmware updates?

Yes, it is recommended to regularly check and install firmware updates for optimal performance and security.

Are there alternative products to the H83MMA5821U3?

For other options, consider similar Huawei GPON products that match your specific network requirements.

What common troubleshooting steps exist for the H83MMA5821U3?

Verify cable connections, ensure the power supply is stable, and check for firmware updates as initial troubleshooting steps.
