ISR4351/K9, Cisco ISR 4000 Router, 200-400Mbps, 3 WAN/LAN, 3 SFP

What is the purpose of the GigabitEthernet0 on the Cisco 4000 Series?

The GigabitEthernet0 is the dedicated management port on the Cisco 4000 Series. This interface connects directly to the control-plane CPU and is ideal for managing the router through Telnet, Secure Shell (SSH) Protocol, Simple Network Management Protocol (SNMP), and other management protocols. It is also ideal for downloading software images, uploading logs, and connecting to other management devices such as RADIUS, Network Time Protocol (NTP), Domain Name System (DNS), Dynamic Host Configuration Protocol (DHCP), and TACACS servers. This interface should never be used for forwarding normal data traffic through the system because every packet goes directly to the control-plane CPU, bypassing the platform data plane. Because of this sensitivity, G0 is in a dedicated Mgmt-Intf Virtual Route Forwarding (VRF) port by default. This setup prevents accidental routing mistakes that could cause data traffic to be routed to the management network.

How does the system fan speed vary?

The Cisco 4000 Series ISRs use both an inlet temperature and an altitude sensor to determine the best fan-speed setting. There are four different inlet temperature ranges and five different altitude ranges for a total of 20 possible different fan-speed settings. The addition of an altitude sensor is an industry first for a branch-office platform. With altitude data incorporated into the fan speed, the system can account for the density of air cooling in order to select the most efficient and quietest fan-speed setting. All system fans run at the same speed.

PoE+ is available on the new SM-X Ethernet switch modules as well as on the FPGE ports.

Are the PoE interfaces PoE+?

With redundant power supplies, can we switch the power to primary when it fails and the router is running on the secondary power supply?

There is no concept of primary or secondary power supply for the Cisco 4451-X and 4351. The power supplies are simply redundant, so that when one fails the other power-supply unit (PSU) takes over by transparently providing power to the entire system. No switching or intervention is required. Both share the load when running in the system; however, when one fails the other provides power to the complete unit. When the failed PSU is replaced with a new PSU in the system, the two power supplies are redundant.

What power cables work with the Cisco 4000 Series?

All power-supply options for the 4000 Series use a standard IEC C13 connector. No special IEC C15 cord is necessary for the Power over Ethernet (PoE) power supply because higher-efficiency power supplies (85 percent) are used in the 4000 Series. This cord thus helps lower the maximum current the power supplies can draw.

What type of backplane is used between components in the Cisco 4000 Series?

The 4000 Series uses multigigabit fabric (MGF) for Layer 2 connectivity between the modules. On the 4451-X, the MGF can provide either 2 Gbps to all NIM slots or up to 10 Gbps to all SM-X slots. The MGF is completely nonblocking and can forward in excess of 50 Gbps.

Can I use the NIMs on the Cisco 1900, 2900, and 3900 Series ISRs?

No. The NIMs are designed for a newer architecture and will not work on the Cisco 1900, 2900, and 3900 Series ISRs.

In the case of control-plane memory, can I put a 4-GB DIMM in one slot and a 2-GB DIMM in the other slot?

No. the 4000 Series expects both DIMM slots to have the same size of memory; as an example, it must have either 4-GB memory in both slots for a total of 8 GB of control-plane memory, or 2-GB memory in both slots, for a total of 4 GB of control-plane memory. This setup is necessary because these platforms interleave memory devices for faster access.

How many dual inline memory modules (DIMMs) does the Cisco ISR4351/K9 have?

The Cisco ISR4351/K9 has two DIMMs.

What memory upgrade options are available on the Cisco ISR4351/K9?

The 4000 Series has separate data and control-plane memory. The control-plane memory comes with 4 GB as the default, and is upgradable up to 16 GB based on various platforms. The data-plane memory comes with 2 GB as the default and is not currently upgradable.

What is the cisco isr4351 k9?

The cisco isr4351 k9 is a Cisco Integrated Services Router (ISR) that provides high-performance connectivity and security for branch offices and remote sites. It supports a range of connectivity options, advanced security features, and application services for efficient network management.

What kind of connectivity options does the cisco isr4351 k9 support?

The cisco isr4351 k9 supports a range of connectivity options including Ethernet, Wi-Fi, and cellular for flexible and reliable connectivity in any environment. It also supports multiple WAN connections for high availability and load balancing.

What kind of security features does the cisco isr4351 k9 offer?

The cisco isr4351 k9 includes advanced security features such as firewall, VPN, and intrusion prevention to protect networks and data from cyber threats. It also includes features such as web filtering and URL categorization for enhanced security.

What kind of application services does the cisco isr4351 k9 support?

The cisco isr4351 k9 supports a range of application services such as Quality of Service (QoS), Network Address Translation (NAT), and voice and video services for efficient and effective network management. It also supports advanced services such as cloud-based applications and analytics.

Is the cisco isr4351 k9 easy to deploy and manage?

Yes, the cisco isr4351 k9 is designed for easy deployment and management, with features such as plug-and-play connectivity, a web-based user interface, and remote management capabilities for efficient and centralized management of multiple routers. It also supports software-defined networking (SDN) for greater automation and programmability.

What is Router-switch?

Router-switch is a company that sells networking equipment such as routers, switches, firewalls, and other related products.

What brands does Router-switch carry?

Router-switch carries a variety of networking equipment brands such as Cisco, Huawei, Juniper, HP, Dell, and more.

Does Router-switch ship internationally?

Yes, Router-switch ships their products internationally. However, customers may need to pay additional customs and taxes depending on their country's regulations.

Does Router-switch offer discounts or promotions?

Yes, Router-switch often offers discounts and promotions on their products. Customers can check their website or subscribe to their newsletter to stay updated on current offers.

Does Router-switch offer customized solutions for specific networking needs?

Yes, Router-switch offers customized solutions for specific networking needs. Customers can contact their sales team and provide their requirements to receive a personalized quote and solution.

What is the system throughput of the ISR4351/K9?

The ISR4351/K9 offers a system throughput of 200Mbps to 400Mbps.

How many WAN/LAN ports does the Cisco ISR4351/K9 have?

The ISR4351/K9 includes 3 WAN/LAN ports.

Are there any SFP ports on the ISR4351/K9 router?

Yes, the Cisco ISR4351/K9 has 3 SFP ports.

What type of CPU is used in the ISR4351/K9 router?

The ISR4351/K9 uses a multi-core CPU for improved performance.

How many service module slots are available on the ISR4351/K9?

The ISR4351/K9 features 2 service module slots.

Does the ISR4351/K9 router support security features?

Yes, the ISR4351/K9 supports extensive security features.

Can the ISR4351/K9 be used for VOIP applications?

Yes, the ISR4351/K9 supports voice services making it suitable for VOIP applications.

What are the intelligent features supported by the ISR4351/K9?

The ISR4351/K9 supports Intelligent WAN, Application Visibility and Control (AVC), and OnePK.

Does the ISR4351/K9 support WAN Optimization?

Yes, the ISR4351/K9 supports WAN Optimization services through WAAS.

Are there alternative products to the Cisco ISR4351/K9?

Yes, alternatives include the Cisco ISR4331/K9 and ISR4321/K9 within the same ISR 4000 series.

How cost-effective is the ISR4351/K9 router?

The ISR4351/K9 offers high performance with 200Mbps-400Mbps system throughput and supports intelligent WAN, making it a cost-effective choice for enterprise networks.

What are the characteristics of the ISR4351/K9?

The ISR4351/K9 features 3 WAN/LAN ports, 3 SFP ports, a multi-core CPU, and 2 service module slots, providing robust network performance and flexibility.

What are the application scenarios for the ISR4351/K9?

The ISR4351/K9 is ideal for medium to large-scale enterprises requiring secure, high-performance routing with advanced services like Security, Voice, and WAAS.

How do I install the Cisco ISR4351/K9 router?

Installation involves connecting the router to your network, configuring the ports, and setting up desired services through the CLI or GUI. Refer to the Cisco setup guide for detailed instructions.

Does the ISR4351/K9 need regular upgrades?

Yes, ensure your ISR4351/K9 is running the latest firmware and software to maintain security and performance. Regular updates are recommended.

Are there alternative products to the ISR4351/K9?

Alternatives include other models in the Cisco 4000 ISR series, such as the ISR4331/K9 and ISR4321/K9, which offer varied performance and port configurations.

What are common troubleshooting tips for the ISR4351/K9?

Common troubleshooting includes verifying power supply, checking port connections, and ensuring the firmware is up-to-date. Use Cisco's diagnostic tools for deeper issues.

What accessories are available for the Cisco ISR4351/K9?

Accessories for the ISR4351/K9 include rack-mount kits, additional service modules, and compatible SFP transceivers for enhanced network reach and speed.

How does the ISR4351/K9 compare to other similar products?

The ISR4351/K9 stands out with its multi-core CPU, high throughput, and extensive service module support, offering superior performance over many competitors in the same category.

What are the standout features of the ISR4351/K9?

Key features of the ISR4351/K9 include intelligent WAN (IWAN), application visibility and control (AVC), and support for Security, Voice, and WAAS, enhancing network performance and reliability.

Are the products sold on router-switch.com authentic?

Yes, router-switch.com only sells 100% genuine products from authorized brands. As a multi-brand authorized distributor, all items are sourced through official channels and include valid manufacturer warranties. Customers may verify authorization via brand websites or request certification documents.
