main product photo
Name:

AP8030DN

Model:AP8030DN Huawei Dual-band Outdoor Wireless Access point
Brand: Huawei
Detail:
AP8030DN Mainframe (11ac, General AP Outdoor,3x3 Double Frequency, Built-in Antenna)
Rating:
100%
5/5.0
2 Reviews
Price:US$775.00
Coupon
Up to $80 Coupons
Get Now
$10.00
Order Over $100
RS10
$20.00
Order Over $2000
RSTW
$50.00
Order Over $5000
RSFI
$80.00
Order Over $8000
RSEI
Availability: Item Backordered
Condition:New Factory Sealed
Warranty:3 years warranty
Shipping:
Express Shipping to United States
2-6 Days, via DHL, FedEx, UPS, etc.
Ships to:
United States
Payment:
  • Pay by wire transfer.
  • Pay with your paypal.
  • Pay with your webmoney.
  • Pay with your onafriq.
  • Pay with your Visa credit card.
  • Pay with your Mastercard credit card.
  • Pay with your Discover Card.
  • Pay by Western Union.
More
Support:
TZS, XAF, TZS payment.
  • Safe, Fast, 100% Genuine. Your Reliable IT Partner.
    Safe, Fast, 100% Genuine. Your Reliable IT Partner.
  • Best Price Assurance, Bulk Savings, Trusted Worldwide.
    Best Price Assurance, Bulk Savings, Trusted Worldwide.
Expertise Builds Trust

Expertise Builds Trust

  • 22 Years, 200+ Countries
  • 18000+ Customers/Projects
  • CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts
Ask an Expert Now
24/7 Online Service
  • +1-626-655-0998(USA)
  • +852-25925389(HK)
  • +852-25925411(HK)
Live Chat

Join Partner Network

  • Exclusive Discounts/Service
  • Credit Terms/Priority Supply
In  United States
Partner Today

You may also be interested in the following product(s)

AP6510DN-AGN

AP6510DN-AGN

Rating:
100%
5/5.0
1 Review

AP8030DN

AP8030DN Mainframe (11ac, General AP Outdoor,3x3 Double Frequency, Built-in Antenna)

Price: US$775.00
Overview
Specification
Reviews
Q&A
Warranty
Download
Stable Global Supply Chain for Thriving Businesses.
  • $4,000,000 Inventory
  • 500+ Reliable Vendors
  • Certified Partnerships
  • Collaborating with FedEx, UPS, DHL
100,000+ Diverse Products for All Your Needs
Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.
Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.
  • Projects and Technical Support
  • Easy Purchasing Supply
  • Product Lifecycle Protection
  • Exclusive F4 Team Support
Overview

AP8030DN Overview

Huawei AP8030DN Access Point sets a new standard in outdoor networking with innovative RF optimization techniques that boosts data rates to 1.75 Gbit/s, nearly tripling the throughput of typical 802.11n APs. This 802.11ac APs offer simultaneous 2.4 GHz and 5 GHz connectivity for large outdoor environments including pedestrian/public areas and bridging, backhaul, and video surveillance scenarios. IEEE 802.11a/b/g/n/ac compatibility, flexible networking, and integrated quality controls ensure high performance, easy migration, and simple deployment.

Quick Specs

Table 1 shows the Quick Specs.

Product Number

AP8030DN

Power Input

PoE: In compliance with IEEE 802.3at

Maximum Power Consumption

20.1W

Operating Temperature

−40°C to 65°C

Antenna Type

Built-in directional antennas

Maximum Number of Users

≤ 256

Maximum Transmit Power

2.4G: 28 dBm (combined power)
5G: 26 dBm (combined power)

MIMO: Spatial Streams

3 x 3:3

Radio Protocols

802.11a/b/g/n/ac

Maximum Speed

1.75 Gbit/s

Power Input

PoE: In compliance with IEEE 802.3at

Dimensions (H x W x D)

290 mm x 260 mm x 100 mm

Weight

3.6 kg

Product Details

Figure 1 shows the front interfaces of AP8030DN.

AP8030DN Front Interfaces

Note:

①

GE0/PoE interface: a 10/100/1000M interface, which connects to the wired Ethernet and supports the PoE power supply.

②

GE1 interface: a 10/100/1000M interface, which connects to the wired Ethernet.

③

SFP: an optical interface.

Figure 2 shows the left interfaces of AP8030DN.

AP8030DN Left Interfaces

Note:

①

Console interface

②

Default button: restores the factory settings and restarts the AP if you remove the screw and hold down the button more than 3s from the hole.

③

Security slot: Connects to a security lock.

The Accessories

Table 2 shows the recommended accessories.

Model

Description

W0ACPSE11

Adapter,  -25degC,  60degC, 90V, 264V, 56V/1.52A, C8/RI45, POE ADAPTER

OGSC10DD0

Transceiver, eSFP, 1310nm, 1.25Gb/s, -9.5~-3dBm, -20dBm, LC (-40~85), single-mode, 10km

E000CMC00

Network Interface Connector, 8PIN, 8bit, Shielded, Crystal Model Connector, 23-24AWG Single Solid Wire, CAT6

FDLCUPC02

Optical Cable Assembly, DLC/UPC, DLC/UPC, Single-mode, GYFJH 2B1.3 (LSZH), 20m, 7.0mm, 2 Cores, 0.03m/0.34m, 2mm, Outdoor Protected Branch Cable

Compare to Similar Items

Table 3 shows the comparison of AP8030DN and AP8130DN.

Product Number

AP8030DN

AP8130DN

Power Input

PoE: In compliance with IEEE 802.3at

PoE: In compliance with IEEE 802.3at

Maximum Power Consumption

20.1W

22.4W

Operating Temperature

−40°C to 65°C

−40°C to 65°C

Antenna Type

Built-in directional antennas

Outdoor external antennas

Maximum Number of Users

≤ 256

≤ 256

Maximum Transmit Power

2.4G: 28 dBm (combined power)
5G: 26 dBm (combined power)

2.4G: 28 dBm (combined power)
5G: 26 dBm (combined power)

MIMO: Spatial Streams

3 x 3:3

3 x 3:3

Radio Protocols

802.11a/b/g/n/ac

802.11a/b/g/n/ac

Maximum Speed

1.75 Gbit/s

1.75 Gbit/s

Get more information

Do you have any question about the AP8030DN?

Contact us now via Live Chat or sales@router-switch.com.

Quality Certifications

  • ISO 14001
  • ISO 9001
  • RoHS
  • REACH
  • CE
  • FCC
Specification

AP8030DN Specification

AP8030DN Specifications

Technical

Dimensions (H × W × D)

39 in. x 10.2 in. x 11.4 in. (100 mm x 260 mm x 290 mm)

Weight

7.94 lb

System memory

256 MB DDR3

64 MB flash memory

Power

Power input

PoE: in compliance with IEEE 802.3at

Maximum power consumption

20.1W

Note: Maximum power consumption depends on local laws and regulations

Environment

Operating temperature

-40oF to 14oF (-40oC to 60oC)

Storage temperature

-40oF to 158oF (-40oC to 70oC)

Humidity

5% to 95% (Non-condensing)

Waterproof grade

IP67

Altitude

196.8 ft. to 16,404.1 ft. (-60m to 5,000m)

Radio frequency specifications

Antenna Type

Built-in

Antenna Gain

·2.4G: 2.5 dBi

·5G: 4 dBi

Maximum Number of Users

≤ 256

Note: The number of concurrent online users on each VAP or radio frequency cannot exceed 128

Maximum Transmit Power for each Radio Frequency

2.4 GHz: 23 dBm

5 GHz: 21 dBm

Note: The 2.4 GHz radio frequency does not support the 40M bandwidth in F.C.C. regions (including America). The actual transmit power depends on local laws and regulations.

You can adjust the transmit power to the maximum transmit power of 15 dB in 1 dB steps

Channel Rates

802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s

802.11b: 1, 2, 5.5, and 11 Mbit/s

802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbit/s

802.11n: 6.5 Mbit/s to 450 Mbit/s

802.11ac: 6.5 Mbit/s to 1,300 Mbit/s

Receiver Sensitivity

2.4 GHz

802.11b (CCK)

-100 dBm @ 1 Mbit/s

-90 dBm @ 11 Mbit/s

2.4 GHz

802.11g (Non-HT20)

-95 dBm @ 6 Mbit/s

-82 dBm @ 54 Mbit/s

2.4 GHz

802.11n (HT20)

-95 dBm @ MCS0

-74 dBm @ MCS23

2.4 GHz

802.11n (HT40)

-92 dBm @ MCS0

-71 dBm @ MCS23

5 GHz

802.11a (non-HT20)

-96 dBm @ 6 Mbit/s

-80 dBm @ 54 Mbit/s /s

5 GHz

802.11n (5T20)

-95 dBm @ MCS0

-74 dBm @ MCS23

5 GHz

802.11n (HT40)

-92 dBm @ MCS0

-71 dBm @ MCS23



5 GHz

802.11ac (VHT20)

-95 dBm @ MCS0NSS1

-67 dBm @ MCS9NSS1

5 GHz

802.11ac (VHT40)

-92 dBm @ MCS0NSS1

-63 dBm @ MCS9NSS3

5 GHz

802.11ac (VHT80)

-90 dBm @ MCS0NSS1

-59 dBm @ MCS9NSS3



Quality Certifications

Q&A

Questions & Answers

What accessories are available for the AP8030DN?

Available accessories for the AP8030DN include mounting kits, AC/DC power adapters, and weatherproof enclosures.

How does the AP8030DN compare to similar products?

The AP8030DN stands out with its built-in antenna and 3x3 double-frequency support, offering superior performance compared to many rivals.

How can I troubleshoot common issues with the AP8030DN?

For troubleshooting, check connections, verify power supply, update firmware, and consult Huawei's support documentation if issues persist.

What is the coverage range of the AP8030DN?

The AP8030DN offers extensive coverage due to its advanced 11ac technology and built-in antenna, ensuring high-quality connectivity over large outdoor areas.
