S5720-36C-EI-AC

4.8 11
4.8/5.0
11 Review(s)
| 10 answered questions
Model: S5720-36C-EI-AC Huawei S5720 Series Switch
Detail: S5720-36C-EI-AC(28 Ethernet 10/100/1000 ports,4 of which are dual-purpose 10/100/1000 or SFP,4 10 Gig SFP+, 1 interface slot,with 150W AC)
Price: $1,819.00
Condition: Brand New Sealed
Availability: In stock
Shipping:
Express Shipping to Worldwide
2-6 Days, via DHL, FedEx, EMS, etc. ?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
US$ 1,819.00 In stock Brand New Sealed
OR

Ask Our Experts

Live Chat | Email

  • +1-626-239-8066 (USA)
  • +852-3174-6166 (HK)
  • +852-3050-1066 (Fax)
Get Quotes up to
2x Faster
Project Inquiry
Overview

Overview (S5720-36C-EI-AC)

Huawei S5720-36C-EI-AC Gigabit Switch provides resilient, energy-efficient GE ports for access switching in data centers, and aggregation switching in enterprise campus networks. With twenty-eight 10/100/1,000 Base-T Ethernet ports, four combo 100/1,000 Base-X SFP ports and four 10G SFP+ ports, its performance enhancements include advanced processing hardware, large MAC address and routing tables; It also has multiple cards modules to meet customer s' different needs. Super Virtual Fabric (SVF) support enables intelligent virtualization, iStack clustering, and operation in N + 1 backup mode for simplified O&M and high availability. Mature IPv6 features ensure smooth migration to next-generation IP networking.

Quick Specs

Figure 1 shows the appearance of Huawei S5720-36C-EI-AC switch.

S5720-36C-EI-AC

 Table 1 shows the Quick Specs.

Product Code

S5720-36C-EI-AC

Fixed Ports

28 x 10/100/1,000 Base-T (4 GE Combo SFP)

4 x 10 Gig SFP+

Extended Slots

One extended slot

Memory (RAM)

2 GB

Flash

340 MB

MAC Address Table Size Forwarding Performance

64 MAC

Forwarding Performance

132 Mpps

Switching Capacity

598 Gbit/s

Power Supply

AC power supply

PoE

Not Supported

Voltage Required

AC

Rated voltage range: 100V to 240V AC, 50/60 Hz

Maximum voltage range: 90V to 264V AC, 47 Hz/63 Hz

Front Power Input

No No

Typical Power Consumption

39.5W

Dimensions (W x D x H)

442 mm x 420 mm x 44.4 mm

Weight

9.76 kg

Product Details

Figure 2 shows the front panel of Huawei S5720-36C-EI-AC switch.

S5720-36C-EI-AC-front

 Note:

Twenty-four 10/100/1000BASE-T ports

Four combo ports (10/100/1000BASE-T + 100/1000BASE-X)

Four 10GE SFP+ ports

One mini USB port

ETH management port

One USB port

One console port





* The console port is used  with a console cable. The console cable is not delivered with the switch and needs to be separately purchased if needed.

Figure 3 shows the back panel of Huawei S5720-36C-EI-AC switch.

 S5720-36C-EI-AC-back

Note:

Ground screw

ESN label

Rear card slot

Fan slot

Power module slot 2

Power module slot 1

*The ground screw is used with a ground cable.

* You can draw the ESN label out to view the ESN and MAC address of the switch.

Recommended Modules

Table 2 shows the recommended optical modules.

Model

Description

GE-SFP Optical Transceiver

eSFP-GE-SX-MM850

Optical Transceiver, eSFP, GE, Multi-mode Module(850nm,0.55km,LC)

SFP-GE-LX-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,10km,LC)

S-SFP-GE-LH40-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,40km,LC)

S-SFP-GE-LH40-SM1550

Optical Transceiver, eSFP, GE, Single-mode Module(1550nm,40km,LC)

SFP-1000BaseT

Electrical Transceiver, SFP , GE ,Electrical Interface Module(100m,RJ45)

10G-SFP+ Optical Transceiver

SFP-10G-USR

10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module(850nm,0.1km,LC)

OMXD30000

Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.3km,LC)

OSX010000

Optical Transceiver, SFP+, 10G, Single-mode Module(1310nm,10km,LC)

Card

ES5D21X02S01

2 10 Gig SFP+ Interface Card(used in S5720EI series)

ES5D21X02T01

2 10 Gig RJ45 Interface Card(used in S5720EI series)

ES5D21VST000

Dedicated stack card with 2*QSFP+ interface(Including one PCS of 1M QSFP+ cable ,Used in S5720EI series)

Compare with Similar Item

Table 3 shows the comparison of Huawei S5720-36C-EI-AC, S5720-36C-PWR-EI-AC  and S5720-36C-EI-28S-AC.

Models

S5720-36C-EI-AC

S5720-36C-PWR-EI-AC

S5720-36C-EI-28S-AC

Fixed Ports

28 x 10/100/1,000 Base-T (4 GE Combo SFP), 4 x 10 Gig SFP+

 28 x 10/100/1,000 Base-T (4 GE Combo SFP), 4 x 10 Gig SFP+

28 x 100/1,000 Base-X SFP (4 GE Combo), 4 x 10 Gig SFP+

Extended Slots

One extended slot

One extended slot

One extended slot

PoE

Not supported

   Supported

N  Not supported

Forwarding Performance

132 Mpps

132 Mpps

132 Mpps

Switching Capacity

598 Gbit/s

598 Gbit/s

598 Gbit/s

Front Power Input

No

No

No

Power Consumption

39.5W

without PD: 48.5W, with PD: < 864.3W (PoE: 740W)

47.9W

Comparison between LI, SI, EI and HI

Huawei S5720 Series Enterprise Switches provides LI (Lite), SI (Standard), EI (Enhanced) and HI (Hyper) models for users. There are some differences among these four versions.

Click this PDF to know more.

Comparison of Huawei S5720-LI, SI, EI and HI Series Switches.pdf

Get More Information

Do you have any question about the Huawei S5720-36C-EI-AC switch?

Contact us now via Live Chat or sales@router-switch.com.

Specification

Specification (S5720-36C-EI-AC)

S5720-36C-EI-AC  Specification

MAC address table

IEEE 802.1d compliance

MAC address learning and aging

Static, dynamic, and blackhole MAC address entries

Packet filtering based on source MAC addresses

MAC address entries:
S5700S-LI series: 8K, S5700-LI/S5700-SI series: 16K, S5700-EI series: 32K, S5720-EI series: 64K, S5700-HI series: S5700-HI: 32K, S5710-HI: 456K, S5720-HI: 128K

VLAN

4K VLANs

Guest VLAN and voice VLAN

GVRP

MUX VLAN

VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports

1:1 and N:1 VLAN Mapping

SuperVLAN(supported by the S5700-SI/S5700-EI/S5700-HI series)

Ring protection

RRPP ring topology and RRPP multi-instance

Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level protection switchover

SEP

ERPS(G.8032)(supported by the S5700-LI/S5700-SI/S5700-EI/S5700-HI series)

STP, RSTP, and MSTP

BPDU protection, root protection, and loop protection

BPDU Tunnel

Reliability

Ethernet OAM (IEEE 802.3ah and 802.1ag)

ITU-Y.1731

DLDP

LACP

E-Trunk(supported by the S5700-SI/S5700-EI/S5700-HI series)

BFD for OSPF, BFD for IS-IS, BFD for VRRP, and BFD for PIM (supported by the S5700-EI/S5700-HI series)

MPLS features

MPLS L3VPN

MPLS L2VPN(VPWS/VPLS)

MPLS-TE

MPLS QoS

Notes: supported by S5710-EI, S5700-HI and S5710-HI

IP routing

Static routing

RIPv1, RIPv2 and RIPng,ECMP(supported by the S5700-SI/S5700-EI/S5700-HI series)

OSPF, OSPFv3, IS-IS, IS-ISv6, BGP and BGP4+ (supported by the S5700-EI/S5700-HI series)

IPv6 features

Neighbor Discovery (ND)

Path MTU (PMTU)

IPv6 ping, IPv6 tracert, and IPv6 Telnet

ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type

MLD v1/v2 snooping

6to4 tunnel, ISATAP tunnel, and manually configured tunnel(supported by the S5700-SI/S5700-EI/S5700-HI series)

Multicast

IGMP v1/v2/v3 snooping and IGMP fast leave

Multicast forwarding in a VLAN and multicast replication between VLANs

Multicast load balancing among member ports of a trunk

Controllable multicast

Port-based multicast traffic statistics

IGMP v1/v2/v3, PIM-SM, PIM-DM, PIM-SSM, MSDP (supported by the S5700-EI/S5700-HI series)

QoS/ACL

Rate limiting on packets sent and received by an interface

Packet redirection

Port-based traffic policing and two-rate three-color CAR

Eight queues on each port

WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms

WRED (supported by the S5710-EI and S5700-HI)

Re-marking of the 802.1p priority and DSCP priority

Packet filtering at Layers 2 through 4, filtering out invalid frames based on the source MAC address, destination MAC address, source IP address, destination IP address, TCP/UDP port number, protocol type, and VLAN ID

Rate limiting in each queue and traffic shaping on ports

Security

User privilege management and password protection

DoS attack defense, ARP attack defense, and ICMP attack defense

Binding of the IP address, MAC address, interface, and VLAN

Port isolation, port security, and sticky MAC

MFF

Blackhole MAC address entries

Limit on the number of learned MAC addresses

802.1x authentication and limit on the number of users on an interface

AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC

SSH v2.0

Hypertext Transfer Protocol Secure (HTTPS)

CPU defense

Blacklist and whitelist

Access Security

DHCP Relay, DHCP Server, DHCP Snooping, DHCP Security

Management and maintenance

Virtual cable test

Port mirroring and RSPAN (remote port mirroring)

Remote configuration and maintenance using Telnet

SNMP v1/v2c/v3

RMON

Web NMS

HGMP

System logs and alarms of different levels

802.3az EEE (supported by the S5700(S)-LI, S5710-EI, S5700-HI and S5710-HI)

Dying gasp (supported by the S5700-HI, S5710-HI and S5700(S)-LI(except battery LAN switches)

NetStream (supported by the S5710-EI, S5700-HI and S5710-HI)

sFlow(supported by the S5700(S)-LI/S5700-EI/S5700-HI series)

Interoperability

Supports VBST (Compatible with PVST/PVST+/RPVST)

Supports LNP (Similar to DTP)

Supports VCMP (Similar to VTP)

Operating environment

Operating temperature: 0℃–50℃

Relative humidity: 10%–90% (non-condensing)

Input voltage

AC:

Rated voltage range: 100 V to 240 V AC, 50/60 Hz

Maximum voltage range: 90 V to 264 V AC, 47/63 Hz

DC:

Rated voltage range: –48 V to –60 V, DC

Maximum voltage range: –36 V to –72 V DC

Note: PoE-support switches do not use DC power supplies.

Q&A

Faq (S5720-36C-EI-AC)

What Is the Working Temperature of the Switch?

· Operating temperature: 0°C to +45°C (altitude 0 to 1800 m) · Storage temperature: -40°C to +70°C

What Is the Authorized Directory for an FTP User?

The authorized directory for the FTP service must be an existing directory on the local device. If the authorized directory is incorrect, run the local-user user-name ftp-directory directory command to configure a correct directory.

 Can a Traffic Policy Be Configured in a Super-VLAN or Sub-VLAN to Make the Traffic Policy Take Effect?

The packets received and sent by the switch configured with VLAN aggregation carry sub-VLAN tags but not super-VLAN tags, so a traffic policy must be configured in all sub-VLANs of a super-VLAN. A traffic policy in the super-VLAN does not take effect.

What Should I Do When Finding a MAC Address Flapping Alarm?

If the alarm is reported only once, ignore it. If the alarm is reported multiple times, find the first and second interfaces where the MAC address is learned. Shut down the second interface to locate the loop. Then adjust the networking to remove the loop.

Does the S5720-36C-EI-AC Support QinQ?

Yes, it support both basic QinQ and selective QinQ.

Which VLAN Does the Interface Enabled with VLAN Mapping or QinQ Obtain Through MAC Address Learning?

The VLAN mapping or QinQ implementation is prior to the MAC address learning. Thus, after the VLAN mapping or QinQ implementation, the interface obtains the outer VLAN through MAC address learning.

Does the Switch Support the NAT Function?

The switch does not support the NAT function.

Can Layer 2 Multicast Be Configured in Dynamic VLANs?

Layer 2 multicast cannot be configured in dynamic VLANs.

Does S5720-36C-EI-AC Support IPSG?

Yes,the S5720-36C-EI-AC supports IPSG.

How Can I Obtain the MACsec Plug-in and Related Documentation?

By default, switches do not support the MACsec function. The MACsec function is available only when a plug-in is installed on the switch.

Shipping & Payment

Delivery

Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.

Delivery OptionsEstimated Delivery Time
DHL 2-4 business days
Fedex 2-4 business days
Hong Kong EMS 5-10 business days
Hong Kong Air Parcel 10-20 business days
By Sea 10-20 business days

Notice:

Above mentioned information are just for your reference only,we will keep you posted for the tracking delivery schedule.There are two delivery options available for by air and by sea:

Deliver to port:

Router-switch.com is responsible for transporting goods to port. All subsequent customs and transportation fees are the
responsibility of the buyer. Router-switch will recommend trustworthy local freight forwarders to you.Router-switch.com can facilitate the progress under buyer's permission and at buyer's expense.

Deliver to door:

Router-switch.com will quote all destination charge prior once we have confirmed order.
Router-switch.com is responsible for transporting goods to door after you have made the payment.

Payment Methods

Paypal Master Card Visa
Discover American
Express
JCB
Wire Transfer eCheck WestUnion
Warranty

Warranty

100% Low Price Guarantee:

Router-switch.com provides high-quality products at low wholesale prices

All items are ORIGINAL and GENUINE only:

Item conditions are all "New Sealed".
All items are fully tested with working conditions by Huawei certified engineer under customers' permission.

100% Money Back Guarantee:

If your returns meet our relevent standards,you can contact our customer service team to exchange or return any product that you bought from us.

Professional Technical Support:

Router-switch.com experienced technical team can provide support over the phone, by chat, by email or by remotely login.

Flexible Secure Payment & Shipment:

Verified authorization: Mcafee Secure, VeriSign Secured

Return Material Authorization (RMA) Process

Standard Hardware Warranty Policy:

Original new sealed Huawei product: 1 Year.

The Support Contacts:

If your Huawei products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.

Reviews

Customer Reviews

4.8 5
4.8 (11 reviews)
5 Stars
9
4 Stars
2
3 Stars
0
2 Stars
0
1 Stars
0

Share your thoughts with other customers?

Posted on 8/11/2016
Verified Buyer
45
5stars

Have available stock, fast delivery, good quality, 5 stars.

Posted on 7/11/2016
Verified Buyer
55
Fast delivery

Thank you for your fast delivery, I receive the switch already

Posted on 6/25/2016
Verified Buyer
55
S5720-36C-EI-AC-excellent quality

I bought this higher version that provides excellent quality. Great!

Posted on 6/16/2016
Verified Buyer
55
Exactly what we needed

The purchase process was quite simple and it is easy to see the S5720-36C-EI-AC along with specs. Excellent website!

Posted on 4/8/2016
Verified Buyer
55
Quality is OK

Switch has work 7 months, still very well, perfect.

Posted on 11/28/2015
Verified Buyer
45
S5720-36C-EI-AC-Configuring MAC address??

This EI type also support the function of Configuring MAC address learning priorities for interfaces.

Posted on 11/21/2015
Verified Buyer
55
Considerate service

They help me complete everything, nice purchase.

Posted on 10/21/2015
Verified Buyer
55
S5720-36C-EI-AC-support Smart Link and VRRP

it supports Smart Link and VRRP, which implement backup of uplinks.

Posted on 9/18/2015
Verified Buyer
55
S5720-36C-EI-AC-one extended slot

It has one extended slot.

Posted on 9/8/2015
Verified Buyer
55
Work great

Work great as its name for

Posted on 8/17/2015
Verified Buyer
55
Good communication

My Enlish no good, thank your for your patience, good communication

You may also be interested in the following product(s)

Product Tags

Register now to get updates on promotions and coupons

We’ll never share your email address with a third-party.

Router-switch.com is neither a partner of nor an affiliate of Cisco Systems. Logos remain the property of the corresponding company.
Copyright @ 2002-2017 Router-switch Ltd. | HongKong Yejian Technologies Co., Ltd | All Rights Reserved.
