S5700-52P-LI-AC

Model: S5700-52P-LI-AC 02353174 Huawei Quidway S5700 Switch
Detail: 48 Ethernet 10/100/1000 ports, 4 Gig SFP, AC 110/220V
Price: US$818.52
List Price: US$3,027.36
You save: US$2,208.84 (73% OFF)
Condition: Brand New Sealed
Availability: In stock
US$ 818.52 In stock Brand New Sealed
OR
Product Overview

Overview (S5700-52P-LI-AC)

Huawei S5700-LI series switches deliver super-flexible, easy-to-manage platform that optimize L3 switching capacity and downstream port bandwidth from 100 Mbit/s to 1 Gbit/s. The S5700-52P-LI-AC offers AC Power Supply, 48 x 10/100/1000 Base-T Ethernet Ports and 4 x GE SFP Ports.

Quick Specs

Figure 1 shows the appearance of Huawei S5700-52P-LI-AC switch.

S5700-52P-LI-AC

Table 1 shows the Quick Specs.

Product Code

S5700-52P-LI-AC

Downlink Ports

48 x 10/100/1000 Base-T Ethernet Ports

Uplink Ports

4 x GE SFP Ports

MAC Address

16K

VLAN

4K

Forwarding Performance

78 Mpps

Switching Capacity

256 Gbit/s

Stack

Supported

Stack Ports

-V200R001: the last two uplink 1000Base-X optical ports

-V200R002 and later versions: four uplink 1000Base-X optical ports

Power

AC 110/220 V & RPS1800 redundant power supply

Heat Dissipation

Forced air cooling by Built-in fans

Memory (RAM)

256 MB

Flash

-V200R001: 64 MB

-V200R002 and later versions: 200 MB

Dimensions (W x D x H)

442.0mm × 310.0mm × 43.6mm

Product Details

Figure 2 shows the front panel of Huawei S5700-52P-LI-AC switch.

S5700-52P-LI-AC Front Panel

Note:

48 x 10/100/1000 Base-T Ethernet Ports

One console port

4 x 1000BASE-X ports

One mini USB port

Four 1000BASE-X ports support modules and cables:

- GE optical module

- GE-CWDM optical module

- GE-DWDM optical module

- GE copper module (applicable in V200R002C00 and later versions)

- Stack optical module (applicable in V200R007C00 and later versions)

- 1 m and 10 m SFP+ copper cables

- 3 m and 10 m AOC cables (applicable in V200R003C00 and later versions)

Figure 3 shows the back panel of Huawei S5700-52P-LI-AC switch.

S5700-52P-LI-AC Back Panel

Note:

Ground screw

Jack for AC terminal locking latch

RPS socket

AC socket

·Ground Screw is used with a ground cable.

·RPS Socket is used with an RPS cable which is not hot swappable.

·AC socket is used with an AC power cable.

·The AC terminal locking latch is not delivered with the switch.

The Transceiver

Huawei S5700-52P-LI-AC supports optical transceivers (GE, GE-CWDM, GE-DWDM), Stack optical transceiver and GE cooper transceivers.

Table 2 shows the recommended Stack optical transceiver.

Models

Description

SFP-6GE-LR

6GBase-LR Optical Transceiver,SFP,6G,Single-mode Module 1310nm,2km,LC

Table 3 shows the recommended GE optical transceivers.

Models

Description

LE2MGSC40DE0

Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 40km, LC)

LE2MGSC40ED0

Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1490/RX1310, 40km, LC)

S-SFP-GE-LH40-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 40km, LC)

S-SFP-GE-LH40-SM1550

Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 40km, LC)

S-SFP-GE-LH80-SM1550

Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 80km, LC)

SFP-GE-BXU1-SC

1000Base,BIDI Optical Transceiver, SFP, GE, Single-mode Module (TX1490nm/RX1310nm, 10km, SC)

SFP-GE-LX-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC)

SFP-GE-LX-SM1310-BIDI

Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1310/RX1490, 10km, LC)

SFP-GE-LX-SM1490-BIDI

Optical Transceiver, eSFP, GE, BIDI Single-mode Module (TX1490/RX1310, 10km, LC)

SFP-GE-ZBXD1

Optical Transceiver, eSFP, GE, BIDI Single-mode Module (1570nm (Tx) / 1490nm (Rx), 80km, LC)

SFP-GE-ZBXU1

Optical Transceiver, eSFP, GE, BiDi Single-mode Module (1490nm (Tx) / 1570nm (Rx) ,80km, LC)

eSFP-GE-SX-MM850

Optical Transceiver, eSFP, GE, Multi-mode Module (850nm, 0.5km, LC)

eSFP-GE-ZX100-SM1550

Optical Transceiver, eSFP, GE, Single-mode Module (1550nm, 100km, LC)

Table 4 shows the recommended GE-CWDM optical transceivers.

Models

Description

CWDM-SFPGE-1551

CWDM Optical Transceiver, eSFP, 2.5G,Single-mode Module (1551nm, 80km, LC)

CWDM-SFPGE-1571

CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1571nm, 80km, LC)

CWDM-SFPGE-1591

CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1591nm, 80km, LC)

CWDM-SFPGE-1611

CWDM Optical Transceiver, eSFP, 2.5G, Single-mode Module (1611nm, 80km, LC)

Table 5 shows the recommended GE-DWDM optical transceivers.

Models

Description

DWDM-SFPGE-1560-61

DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1560.61nm,120km,LC)

Table 6 shows the GE copper transceivers.

Models

Description

SFP-1000BaseT

Electrical Transceiver, SFP, GE, Electrical Interface Module (100m, RJ45)

Compare to Similar Items

Table 7 shows the comparison of Huawei S5700-52P-LI-AC and S5700-52X-LI-AC

Models

S5700-52P-LI-AC

S5700-52X-LI-AC

Downlink Ports

48 x 10/100/1000 Base-T Ethernet Ports

48 x 10/100/1000 Base-T Ethernet Ports

Uplink Ports

4 x GE SFP Ports

4 x 10GE SFP+ Ports

Power Supply

AC Power Supply

AC Power Supply

Comparison between LI, SI, EI and HI

Huawei S5700 Series Enterprise Switches deliver Lite (LI), Standard (SI), Enhanced (EI) and Hyper (HI) models. There are some differences of four models.

Click this PDF to konw more.

Comparison of Huawei S5700-LI, SI, EI and HI Series Switches.pdf

Get More Information

Do you have any question about the Huawei S5700-52P-LI-AC switch?

Contact us now via Live Chat or cisco@router-switch.com.

Specification

Specification (S5700-52P-LI-AC)

S5700-52P-LI-AC Specification

Manufacturer

Huawei

Manufacturer Part Number

S5700-52P-LI-AC

Form Factor

Fixed, Stackable

Switch Port

48 GE ports, 4 GE SFP ports

Power Over Ethernet (PoE)

Non-POE

Max Number of Stacks

48Gbps

DRAM Memory

256 MB

Flash Memory

32 MB

Performance

Forwarding performance

78 Mpps

MAC address table

IEEE 802.1d compliance

16 K MAC address entries

MAC address learning and aging

Static, dynamic, and blackhole MAC address entries

Packet filtering based on source MAC addresses

VLAN

4 K VLANs

Reliability

RRPP ring topology and RRPP multi-instance

Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level protection switchover

SEP

STP, RSTP, and MSTP

BPDU protection, root protection, and loop protection

E-Trunk

IP routing

Static routing, ECMP

RIPv1, RIPv2 and RIPng

IPv6 features

Neighbor Discovery (ND)

Path MTU (PMTU)

IPv6 ping, IPv6 tracert, and IPv6 Telnet

ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type

MLD v1/v2 snooping

6to4 tunnel, ISATAP tunnel, and manually configured tunnel

Multicast

IGMP v1/v2/v3 snooping and IGMP fast leave

Multicast forwarding in a VLAN and multicast replication between VLANs

Multicast load balancing among member ports of a trunk

Controllable multicast

Port-based multicast traffic statistics

QoS/ACL

Rate limiting on packets sent and received by an interface

Packet redirection

Port-based traffic policing and two-rate three-color CAR

Eight queues on each port

WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms

Re-marking of the 802.1p priority and DSCP priority

Packet filtering at Layers 2 through 4, filtering out invalid frames based on the source MAC address, destination

MAC address, source IP address, destination IP address, port number, protocol type, and VLAN ID

Rate limiting in each queue and traffic shaping on ports

Security

User privilege management and password protection

DoS attack defense, ARP attack defense, and ICMP attack defense

Binding of the IP address, MAC address, interface, and VLAN

Port isolation, port security, and sticky MAC

Blackhole MAC address entries

Limit on the number of learned MAC addresses

802.1x authentication and limit on the number of users on an interface

AAA authentication, RADIUS authentication, HWTACACS authentication, and NAC

SSH v2.0

Hypertext Transfer Protocol Secure (HTTPS)

CPU defense

Blacklist and whitelist

Management

Management and maintenance

Power Supply Specifications

Power Device

Power supply

Power Redundancy

No

Voltage Required

AC 120/230 V ( 50/60 Hz )

Dimensions / Weight / Miscellaneous

Width

44.2cm

Depth

31cm

Height

4.36cm

Weight

5.0kg

MTBF

37years

System Software

Software Version

Standard Version

Manufacturer Warranty

Service & Support

1 year warranty
