MA5822-16FE-POTS

Huawei MA5822-16FE-POTS is a SmartAX MA5822 with 16FE + 16POTS. The SmartAX MA5822 is a multi-service access module launched by Huawei. The MA5822 applies to fiber to the building (FTTB) or fiber to the curb (FTTC) network applications for providing voice, data, and multicast services for community users.

Quick Spec

Table 1 shows the quick spec.

Product Details

Huawei SmartAX MA5822 series provides these highlights:

10G GPON Upstream Transmission

10G GPON provides a higher bandwidth to meet service requirements.

The 10G GPON transmission complies with ITU-T Recommendation G.987 and ITU-T Recommendation G.988, and provides asymmetric transmission rates in the upstream direction and the downstream direction.

10G GPON networks can coexist with the current GPON networks to fully use the existing optical distribution network (ODN) resources.

Rich and Complete Specifications

The MA5822 provides multiple specifications. Carriers can choose the ideal one according

to the user density, which best balances the input and output.

A Rich Variety of Services

The MA5822 support a rich variety of services, such as voice, data, and multicast services, and quality of service (QoS) assurance solutions.

Supports high-performance multicast services.

Supports IPv6 features.

Provides effective QoS management. rectification, data backup and uploading, and log collection.

Supports network performance monitoring. The MA5822 supports network optimization and

user monitoring.

Comprehensive Management and Maintenance

The MA5822 support multiple high efficient management and maintenance functions, such as remote software commissioning, acceptance, upgrade and patch installation, and fault location.

Supports one-stop deployment and plug-and-play. When transmitting services upstream through a PON port, the MA5822 support offline deployment and plug-and-play. It automatically obtains configuration data from the iManager U2000 network management system (U2000) and reports its status to the U2000 after going online. The configuration data automatically takes effect.

Supports remote batch upgrade. The MA5822 provides a software-and-patch integrated package for one-stop upgrade, and supports automatic batch upgrade and rollback in case of an upgrade failure.

Supports zero-touch routine maintenance. The MA5822 supports remote fault location and rectification, data backup and uploading, and log collection.

Supports network performance monitoring. The MA5822 supports network optimization and user monitoring.

High-Reliability Design

Complies with carrier-class reliability specifications.

Passes the electrostatic discharge (ESD) test.

Provides surge protection and anti-interference functions.

Complies with the following surge protection standards:

- AC power port: 6 kV common mode; 6 kV differential mode.

- User port: 4 kV common mode for GE/FE ports; 4 kV common mode and differential mode for POTS ports.

Uses derating designs for electronic components, improving system reliability.

Uses an anticorrosion design and fewer lines routed across the surface of a board to achieve a proper heat dissipation effect (producing a temperature difference to prevent condensation).

Compare to Similar Items

Table 2 shows the comparison.
