main product photo
Name:

XFP-LH80-193.00

Model:XFP-LH80-193.00 - Huawei OSN 7500 SFP Module
Brand: Huawei
Detail:

Optical Transceiver,XFP,1553.33nm,9.95G~11.1Gbps,-1~3dBm,-24.0dBm,LC,SM,80km

Availability: Item Backordered
Condition:New Factory Sealed
Warranty:3 years warranty
Shipping:
Express Shipping to United States
2-6 Days, via DHL, FedEx, UPS, etc.
United States
Payment:
  • Pay by wire transfer.
  • Pay with your paypal.
  • Pay with your webmoney.
  • Pay with your onafriq.
  • Pay with your Visa credit card.
  • Pay with your Mastercard credit card.
  • Pay with your Discover Card.
  • Pay by Western Union.
More
Support:
TZS, XAF, TZS payment.
  • Safe, Fast, 100% Genuine. Your Reliable IT Partner.
    Safe, Fast, 100% Genuine. Your Reliable IT Partner.
  • Best Price Assurance, Bulk Savings, Trusted Worldwide.
    Best Price Assurance, Bulk Savings, Trusted Worldwide.
Expertise Builds Trust

Expertise Builds Trust

  • 22 Years, 200+ Countries
  • 18000+ Customers/Projects
  • CCIE, CISSP, JNCIE, NSE 7 AWS, Google Cloud Experts
Ask an Expert Now
24/7 Online Service
  • +1-626-655-0998(USA)
  • +852-25925389(HK)
  • +852-25925411(HK)
Live Chat

Join Partner Network

  • Exclusive Discounts/Service
  • Credit Terms/Priority Supply
In  United States
Partner Today

XFP-LH80-193.00

Optical Transceiver,XFP,1553.33nm,9.95G~11.1Gbps,-1~3dBm,-24.0dBm,LC,SM,80km

Overview
Specification
Reviews
Warranty
Download
Stable Global Supply Chain for Thriving Businesses.
  • $4,000,000 Inventory
  • 500+ Reliable Vendors
  • Certified Partnerships
  • Collaborating with FedEx, UPS, DHL
100,000+ Diverse Products for All Your Needs
Customized Support for Your Needs with CCIE, HCIE, HPE ASE, etc.
Personalized Service, Superior Product Maintenance for Ultimate Satisfaction.
  • Projects and Technical Support
  • Easy Purchasing Supply
  • Product Lifecycle Protection
  • Exclusive F4 Team Support
Overview

XFP-LH80-193.00 Overview

The Huawei XFP-LH80-193.00 Optical Transceiver is a superior networking component designed to meet high-speed data transmission demands. It operates within a wavelength of 1553.33nm and supports a data rate ranging from 9.95Gbps to 11.1Gbps. This transceiver covers long distances, up to 80 kilometers, making it ideal for extensive network setups.

Quick Spec

Brand Huawei
Model XFP-LH80-193.00
Wavelength 1553.33nm
Data Rate 9.95G~11.1Gbps
Maximum Distance 80km

Product Features

  • ● ● Supports high data rates from 9.95G to 11.1Gbps
  • ● ● Operates at a wavelength of 1553.33nm
  • ● ● Compatible with LC connector
  • ● ● Designed for Single Mode (SM) fiber
  • ● ● Capable of long-distance transmission up to 80km

Product Applications

  • ● ● Ideal for long-haul telecommunications networks
  • ● ● Suitable for data center interconnections
  • ● ● Perfect for metropolitan area network (MAN) applications

Supported Options

Accessory Model
LC Connector HX-LC01
Patch Cable HX-PC02
Transceiver Adapter HX-TA03

Compare to Similar Items

Model Differences
XFP-LH40-193.00 Max Distance: 40km, lower max distance
XFP-LH100-193.00 Max Distance: 100km, higher max distance
XFP-SH80-193.00 Supports shorter wavelength/economical rates

Get more information

Contact us through Live Chat or [email protected] for further information about the Huawei XFP-LH80-193.00 and its price. Check Huawei XFP-LH80-193.00 price and XFP-LH80-193.00 datasheet, buy Huawei XFP-LH80-193.00 Transceiver with best price and fast shipping. Free Live Chat support is available.

Quality Certifications

  • ISO 14001
  • ISO 9001
  • RoHS
  • REACH
  • CE
  • FCC
Specification

XFP-LH80-193.00 Specification

Huawei XFP-LH80-193.00 Specifications

Brand Huawei
Model XFP-LH80-193.00
Product Type Optical Transceiver
Form Factor XFP
Wavelength 1553.33nm
Data Rate 9.95G~11.1Gbps
Transmit Power -1~3dBm
Receiver Sensitivity -24.0dBm
Connector Type LC
Fiber Type Single Mode (SM)
Maximum Distance 80km
Operating Temperature 0 to 70°C
Storage Temperature -40 to 85°C
Power Supply Voltage 3.3V
Power Consumption <2.5W
Protocols SONET/SDH, 10G Ethernet, 10G Fibre Channel
Compliance RoHS
Digital Diagnostic Monitoring Yes
EMI/EMC FCC, CE, VCCI, RCM
Safety FDA, TUV
