The HPE ProLiant DL360 Gen9 Server delivers security, agility and flexibility without compromise. It supports the Intel® Xeon® Scalable processor with up to a 71% performance gain and 27% increase in cores, along with 2666 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB with an increase in performance of up to 66%. With the added performance that 12 NVDIMMs and 10 NVMe bring, the HPE ProLiant DL360 Gen10 means business. Deploy, update, monitor and maintain with ease by automating essential server life cycle management tasks with HPE OneView and HPE iLO 5. Deploy this 2P secure platform for diverse workloads in space constrained environments.
Features
Industry-leading Performance with Versatile Compute
HPE ProLiant DL360 Gen10 Server supports industry-standard technology leveraging the Intel Xeon Scalable processor with up to 28 cores, 12G SAS and 3.0 TB of 2666 MT/s HPE DDR4 SmartMemory.
Innovative Design for Flexibility and Choice
The premium 10 SFF NVMe chassis backplane provides the ability to mix and match SAS/SATA and NVMe within the same chassis along with 8 + 2 SFF and 4 LFF chassis that supports new uFF and M.2 storage options.
Security Innovations
HPE iLO 5 enables the world’s most secure industry standard servers with HPE Silicon Root of Trust technology to protect your servers from attacks, detect potential intrusions and recover your essential server firmware securely.
Industry-Leading Serviceability and Deployment
HPE ProLiant DL360 Gen10 Server comes with a complete set of services offered by HPE Pointnext, delivering confidence, reducing risk, and helping customers realize agility and stability.
Technical Specifications
Table 1 shows the Technical Specifications of DL360 Gen10 Servers.
|
Processor family
|
Intel® Xeon® Scalable 8100 series Intel® Xeon® Scalable 6100 series Intel® Xeon® Scalable 5100 series Intel® Xeon® Scalable 4100 series Intel® Xeon® Scalable 3100 series |
|
Processor core available |
28 or 26 or 24 or 22 or 20 or 18 or 16 or 14 or 12 or 10 or 8 or 6 or 4, depending on model |
|
Processor cache
|
8.25 MB L3 11.00 MB L3 13.75 MB L3 16.50 MB L3 19.25 MB L3 22.00 MB L3 24.75 MB L3 27.50 MB L3 30.25 MB L3 33.00 MB L3 35.75 MB L3 38.50 MB L3 |
|
Processor speed |
3.6 GHz |
|
Maximum memory |
3.0 TB with 128 GB DDR4 |
|
Memory slots |
24 DIMM slots |
|
NVDIMM type |
HPE NVDIMMs |
|
NVDIMM capacity |
64 GB, 128 GB, 192 GB, 384 GB |
|
Infrastructure management |
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView Advanced (require licenses) |
|
Power supply type |
2 Flex Slot |
|
Expansion slots |
3, for detailed descriptions refer to the QuickSpecs |
|
Network controller |
HPE 1 Gb 331i Ethernet adapter 4-ports per controller and/or optional HPE FlexibleLOM, depending on model |
|
Storage controller |
1 of the following, depending on model HPE Smart Array P408i-a SR Gen10 Controller or HPE Smart Array P816i-a SR Gen10 Controller or HPE Smart Array E208i-a SR Gen10 Controller |
|
System fan features |
Hot-plug redundant standard |
|
Form factor |
1U |
|
Product dimensions (H x W x D) |
17.11 x 27.83 x 1.69 in |
|
Weight |
28.74 lb minimum 35.86 lb maximum |
Table 2 shows the common model of ML360 Gen9 Servers.
|
|
HPE ProLiant DL360 Gen10 3106 1.7GHz 8C 85W 1P 16G-2R S100i 8SFF 1x500W Entry Server |
|
HPE ProLiant DL360 Gen10 4114 2.2GHz 10C 85W 1P 16G-2R P408i-a 8SFF 1x500W Base Server |
|
|
HPE ProLiant DL360 Gen10 5118 2.3GHz 12C 105W 2P 32G-2R P408i-a 8SFF 2x800W Performance Server |
|
|
HPE DL360 Gen10 Premium 10NVMe CTO Svr |
|
|
HPE DL360 Gen10 8SFF CTO Server |
