eSFP-LH120-SM194.20 Overview

The Huawei eSFP-LH120-SM194.20 is an advanced optical transceiver designed to support a wide range of data transmission applications. With a wavelength of 1543.73nm and data rates ranging from 125Mbps to 2.67Gbps, this eSFP provides reliable performance over distances up to 120km. The LC interface ensures compatibility with standard optical networks, making it an invaluable component for long-haul communications.

Quick Spec

Wavelength 1543.73nm
Data Rate 125M~2.67Gbps
Transmission Distance 120km
Output Power 0~4.0dBm
Receiver Sensitivity -28.0dBm

Product Features

  • ● ● Long-distance transmission up to 120km
  • ● ● Wide data rate support: 125M~2.67Gbps
  • ● ● Compatibility with LC interfaces
  • ● ● Stable operational wavelength at 1543.73nm
  • ● ● High receiver sensitivity of -28.0dBm

Product Applications

  • ● ● Long-haul optical communication networks
  • ● ● Extended enterprise WAN deployments
  • ● ● Telecommunications backbone infrastructure

Supported Options

Accessory Model
LC to LC Duplex Patch Cord Huawei LC-PC-3M
SFP Module Adapter Huawei SFP-ADP-01
Cleaning Kit Huawei CK-01

Compare to Similar Items

Model Differences
Huawei eSFP-LH80-SM192.12 Transmission Distance of 80km
Huawei eSFP-SH200-SM195.30 Transmission Distance of 200km, Different Wavelength
Huawei eSFP-SH40-SM193.11 Transmission Distance of 40km

Get more information

For further information about the Huawei eSFP-LH120-SM194.20, please contact us through Live Chat or email us at [email protected]. Check Huawei eSFP-LH120-SM194.20 price and eSFP-LH120-SM194.20 datasheet, buy Huawei eSFP-LH120-SM194.20 with best price and fast shipping. Free Live Chat support is available.

Quality Certifications

  • ISO 14001
  • ISO 9001
  • RoHS
  • REACH
  • CE
  • FCC
Specification

eSFP-LH120-SM194.20 Specification

eSFP-LH120-SM194.20 Specifications

Brand Huawei
Model eSFP-LH120-SM194.20
Type Optical Transceiver
Form Factor eSFP
Wavelength 1543.73nm
Data Rate 125M~2.67Gbps
Transmitter Output Power 0~4.0dBm
Receiver Sensitivity -28.0dBm
Connector Type LC
Maximum Transmission Distance 120km
Operating Temperature -40 to 85 °C
Storage Temperature -40 to 85 °C
Voltage Supply 3.3V
Power Consumption <2.0W
Protocol SFP MSA INF-8074i and CNSC
Compliance RoHS, CE, FCC
Digital Diagnostic Monitoring (DDM) Yes
Hot Swappable Yes
Application Telecom, Datacom
MTBF > 1,000,000 Hours
