Overview

AR3670 Overview

The AR3670 router uses multi-core processors, fully meets customer requirements on the performance, delay, reliability and security, and guarantees continuous performance improvement and software application extension. With the built-in X86 platform, the AR3600 has great flexibility and is able to support virtualization. By integrating third-party network applications, the AR3600 provides more diversified services.

Quick Specs

Figure 1 shows the appearance of Huawei Router - AR3670.

ar3670-appearance

Table 1 shows the Quick Specs.

Product Code

Huawei Router - AR3670

Memory

24 GB

Flash

8 GB

Service interfaces (standard configuration)

WAN interfaces: 1 GE electrical interface

LAN interfaces: none

Extended slots

2 SIC slots and 7 WSIC slots

Power module type

Pluggable power module

Weight

11 kg (24.2 lb)

Dimensions (W x D x H)

130.5 mm x 442 mm x 470 mm

Product Details

Figure 2 shows the front panel of Huawei Router - AR3670.

  ar3670-front

Note:

Ground point

ESD jack

Seven WSIC slots

Two SIC slots

Figure 3 shows the back panel of Huawei Router - AR3670.

  ar3670-back

Note:

Two SRU slots

3G/LTE antenna interface

Two power module slots

The Modules, Cards

Table 2 shows the recommended elements for the Huawei Router - AR3670.

Model

Description

SupportedFan module

AR3670-FAN

Fan tray for AR3670

AC power module

PAC-700WB-L

700W AC power module

WAN interface card

AR-1E3T3M-W

1-Port Channelized/Unchannelized E3/T3 WAN Interface Card

AR0MSDE11A00

1-Port Fractional Channelized E1/T1 WAN Interface Card

xDSL interface card

AR01SLV1XA

1-Port VDSL2 over POTS WAN Interface Module

AR0MSLA1XA01

1-Port ADSL2+ ANNEX A/M WAN Interface Module

Compare to Similar Items

Table 3 shows the comparison between AR3670 and AR2220E .

Model

AR3670

AR2220E

SIC Slots

2

4

Memory

24 GB

1 GB

Flash

8 GB

512 MB

Weight

11 kg (24.2 lb)

6 kg (13.2 lb)



Dimensions (W x D x H)

130.5 mm x 442 mm x 470 mm

442.0 mm x 420.0 mm x 44.5 mm

Get more information

Do you have any question about the AR3670?

Contact us now via Live Chat or sales@router-switch.com.

Quality Certifications

  • ISO 14001
  • ISO 9001
  • RoHS
  • REACH
  • CE
  • FCC
Specification

AR3670 Specification

AR3670 Specification

Service Forwarding Performance

4.5 Gbit/s

SIC Slots

2

WSICSlots (default/maximum**)

7/8

XSIC slots (default/maximum**)

0/6

Management Port

One Ethernet port

USB 2.0 Ports

2

Mini-USB Port

1

Auxiliary or Console Port

1

Hard Disk

1 TB

Memory (default/maximum)

8 GB/24 GB

Flash

8 GB

Virtual Machines

8 (Based on VM, the customers can install Windows OS or Linux OS)

Maximum Power

700W per power supply (dual power supplies supported)

AC Power Supply

100V to 240V

Power Frequency

50/60 Hz

Dimensions (W x D x H)

442 mm x 470 mm x 130.5 mm

Weight

11 kg (without power modules and cards)

Ambient Temperature

0°C to 45°C

Environment Relative Humidity

5% to 95% (non-condensing)

Basic Functions

ARP, DHCP, NAT, and sub-interface management

WLAN (AC)

AP management (AC discovery/AP access/AP management), CAPWAP, WLAN user management, WLAN radio frequency management (802.11a/b/g/n), WLAN QoS (WMM), and WLAN security (WEP/WPA/WPA2/key management)

LAN

IEEE 802.1P, IEEE 802.1Q, IEEE 802.3, VLAN management, MAC address management, MSTP, and more

IPv4 Unicast Routing

Routing policy, static route, RIP, OSPF, IS-IS, and BGP

IPv6 Unicast Routing

Routing policy, static route, RIPng, OSPFv3, IS-ISv6, and BGP4+

Multicast

IGMP v1/v2/v3, IGMP snooping v1/v2/v3, PIM SM, PIM DM, and MSDP

MPLS

LDP, MPLS L3 VPN, static LSP, dynamic LSP, MPLS TE, IP FRR, LDP FRR, and TE FRR

VPN

IPSec VPN, GRE VPN, DSVPN, L2TP VPN, and smart VPN

QoS

DiffServ, MPLS QoS, priority mapping, CAR, traffic shaping, congestion avoidance (IP or DSCP priority-based WRED), congestion management (LAN interface: SP/WRR/SP + WRR; WAN interface: PQ/CBWFQ), MQC (traffic classifier, traffic behavior, and traffic policy), HQoS, FR QoS, SAC, and hardware QoS

Security

ACL, firewall, 802.1x authentication, MAC address authentication, web authentication, AAA authentication, RADIUS authentication, HWTACACS authentication, broadcast storm suppression, ARP security, ICMP anti-attack, URPF, IP source guard, DHCP snooping, CPCAR, blacklist, attack source tracing, and state-approved algorithms (SM1, SM2, SM3 SCB2 algorithms)

Management and Maintenance

Upgrade management, device management, web NMS, GTL, SNMP (v1/v2c/v3), NTP, CWMP, Auto-Config, USB-based deployment, Barcode Scanning, and command line

Quality Certifications

Q&A

Questions & Answers

What should I do if my Huawei AR3670 router malfunctions?

Common troubleshooting steps for the Huawei AR3670 include rebooting the router, checking connection cables, and ensuring firmware is up-to-date.

What accessories are available for the Huawei AR3670?

Accessories for the Huawei AR3670 include additional interface cards, power supply units, and rack-mount kits, enhancing its functionality and ease of installation.

How does the Huawei AR3670 compare to similar products?

The Huawei AR3670 excels in high slot capacity and power efficiency compared to similar products, offering more versatility and scalability options.

What is the power rating of the Huawei AR3670?

The Huawei AR3670 has a power rating of 700W with an AC power supply, suitable for handling demanding network services efficiently.
