AntiDDoS8160-BASE-DC-200, Huawei AntiDDoS8160 Appliance, 200G Throughput/2xMPU/4xSFU200B

Brand: Huawei
Model: AntiDDoS8160-BASE-DC-200

$45,810.00

100% Genuine

Original, factory-verified

3-Year Warranty

Extended, enterprise-grade

24 Years Expertise

Proven, deployment-focused

Condition

Original New

Express Shipping to United States
Estimated shipping time: 2–6 business days via DHL, FedEx, UPS and more

Certified Expertise Builds Trust

CCIE · JNCIE · NSE7 · ACDX · HPE Master ASE · Dell Server/AI Expert

Faster Delivery, Globally Ready
20+ years of supply chain expertise for faster multi-stop delivery with smooth customs.
48H Worldwide Shipping
10+ Global Warehouses
Keep Projects On Time
Reliable availability and real-time shipment visibility to keep every critical IT project on schedule.
Track Your Order

Leading Global Distributor
Since 2002
A global ICT bridge delivering authentic hardware and trusted service for over 20 years.

Worry-Free Coverage with RSCare
3-Year warranty for enterprise hardware, including advanced RMA, diagnostics, spare parts support, and OEM service compatibility.
Cisco SmartNet
HPE Foundation Care
Dell ProSupport
Juniper Care
Fortinet Support
Your Trusted Genuine Source
Authorized partnerships with 30+ brands, including Cisco, HPE, Dell, Juniper, and Fortinet.
100% Authentic Products
100,000+ Multi-Brand SKUs Available

AntiDDoS8160-BASE-DC-200, Huawei AntiDDoS8160 Appliance, 200G Throughput/2xMPU/4xSFU200B

100% Genuine Ready to Ship

$45,810.00

Overview

Huawei AntiDDoS8160-BASE-DC-200 Overview

The Huawei AntiDDoS8160-BASE-DC-200 is a carrier-grade firewall appliance engineered for ultra-high-capacity DDoS mitigation in large data center and service provider networks. Delivering up to 1,440 Gbit/s throughput with 16 expansion slots and 80 μs latency, it enables real-time cleaning of massive volumetric attacks. Flexible GE, 10GE, 40GE, and 100GE interfaces plus robust DC/AC power options and hot-swappable PEM modules ensure scalable deployment and high availability for always-on protection.

Product Highlights

1,440Gbit/s

Total Thpt

60Mpps

Per-Slot Mit

16 Slots

Scale-Out

Product Applications Scenarios

Data Center

Protects hyperscale data centers from volumetric and application-layer DDoS, maintaining low latency and service uptime for critical workloads.

Service Providers

Enables ISPs and carriers to deliver managed DDoS scrubbing, safeguarding multi-tenant traffic and reducing outage risk for customers.

Security & Privacy

Acts as a high-capacity mitigation node in layered security architectures, stabilizing mission-critical services under sustained attacks.

Product Features Comparison


Model	AntiDDoS8160-BASE-DC-200, Huawei AntiDDoS8160 Appliance, 200G Throughput/2×MPU/4×SFU200B	AntiDDoS8030-BASE-DC	AntiDDoS8080-BASE-DC-200	AntiDDoS1520-AC
Brand	Huawei	Huawei	Huawei	Huawei
Firewall Throughput	Up to 1,440 Gbit/s	Up to 120 Gbit/s	Up to 720 Gbit/s	n/a
VPN Performance	n/a	n/a	n/a	IPSec VPN throughput 400Mbps
Interface Type and Count	24 x GE (SFP); 5 x 10 GE (SFP+); 6 x 10 GE (SFP+); 12 x 10 GE (SFP+); 1 x 40 GE (CFP); 1 x 100 GE (CFP)	24 x GE (SFP); 5 x 10 GE (SFP+); 6 x 10 GE (SFP+); 12 x 10 GE (SFP+); 1 x 40 GE (CFP); 1 x 100 GE (CFP)	24 x GE (SFP); 5 x 10 GE (SFP+); 6 x 10 GE (SFP+); 12 x 10 GE (SFP+); 1 x 40 GE (CFP); 1 x 100 GE (CFP)	4 x GE + 2 x Combo
Concurrent Sessions	n/a	n/a	n/a	Maximum number of concurrent SSL VPN connections 5,000
Security Features	n/a	Multiple DDoS attack defenses, protocol abuse, web, DNS, SIP, reflection attacks, IP reputation, traffic diversion and injection	n/a	SSL VPN, IPSec VPN, GRE VPN, L2TP VPN, MPLS VPN; user authentication and role-based control

Optional Add-ons

Model Number	Description
FW-LPUF-120	Huawei FW-LPUF-120 line processing unit with 2 sub-slots for AntiDDoS 8000/8160 expansion
FW-LPUF-240	Huawei FW-LPUF-240 high-capacity line processing unit with 2 sub-slots for AntiDDoS 8000/8160
ADS-SPC-80-01	Huawei ADS-SPC-80-01 service processing card for large-scale DDoS mitigation on AntiDDoS platforms

Quality Certifications

Specification

Huawei AntiDDoS8160-BASE-DC-200 Specification

Model

AntiDDoS8160-BASE-DC-200

Brand

Huawei

Throughput

Up to 1,440 Gbit/s

Throughput/Slot

Up to 160 Gbit/s

Mitigation Rate/Slot

Up to 60Mpps

Latency

80 μs

Expansion Slots

Expansion LPU

FW-LPUF-120, 2 sub-slots FW-LPUF-240, 2 sub-slots

Expansion Interfaces

24 x GE (SFP); 5 x 10 GE (SFP+); 6 x 10 GE (SFP+); 12 x 10 GE (SFP+); 1 x 40 GE (CFP); 1 x 100 GE (CFP)

Height x Width x Depth

1,420mm x 442mm x 650mm (32U)

Power Supply

Rated input voltage: DC: -48V AC: 175V to 264V; 50 Hz/60 Hz Maximum input voltage range: DC: -72V to -38V AC: 90V to 264V; 50 Hz/60 Hz

Power Consumption

6 x FW-LPUF-240 + 9 x ADS-SPUD-B + 18 x ADS-SPC-80-01: DC: 7,387W (avg.), 8,930W (max.) AC: 7,858W (avg.), 9,500W (max.)

Power Redundancy

DC: 8 hot-swappable PEM modules AC: 8 PEM modules + 2 external AC power chassis

Operating Temperature

0°C to 45°C (long-term), -5°C to 50°C (short-term)

Storage Temperature

-40°C to 70°C

Operating Humidity

5% RH to 85% RH, non-condensing (long-term), 5% RH to 95% RH, non-condensing (short-term)

Storage Humidity

0% RH to 95% RH

Safety Certifications

Electro Magnetic Compatibility (EMC) certification CB, Rohs, FCC, MET, C-tick, and VCCI certification

Weight

180 kg

Get more information

Discover unbeatable prices and fast shipping for the AntiDDoS8160-BASE-DC-200, Huawei AntiDDoS8160 Appliance, 200G Throughput/2×MPU/4×SFU200B . Access the detailed AntiDDoS8160-BASE-DC-200, Huawei AntiDDoS8160 Appliance, 200G Throughput/2×MPU/4×SFU200B datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at [email protected].

Quality Certifications

Need Help? Technical Experts Available Now.

+1-626-655-0998 (USA)
UTC 15:00-00:00
+852-2592-5389 (HK)
UTC 00:00-09:00
+852-2592-5411 (HK)
UTC 06:00-15:00

Get a Quote

Live Chat

Need Help? Technical Experts Available Now.

Customer Reviews

Write Your Own Review

Only registered users can write reviews. Please Sign in or create an account

Q&A

Questions & Answers

What accessories are available for the AntiDDoS8160-BASE-DC-200?

Accessories include additional MPUs, SFUs, power modules, and mounting kits for expanding or maintaining the existing AntiDDoS8160-BASE-DC-200 setup.

How does the AntiDDoS8160-BASE-DC-200 compare to similar products?

The AntiDDoS8160-BASE-DC-200 provides superior throughput and scalability compared to other 200G DDoS protection solutions, with Huawei's reliable support and integration capabilities.

How to use the AntiDDoS8160-BASE-DC-200 effectively?

To use the AntiDDoS8160-BASE-DC-200 effectively, ensure proper configuration of DDoS protection policies, regular monitoring, and timely updates to respond to new threats.

Is router-switch.com a reliable distributor?

Absolutely. As a multi-brand authorized distributor, router-switch.com is directly certified by leading technology manufacturers. We guarantee 100% genuine products, competitive pricing, and full manufacturer warranties and support.

Learn More

How cost-effective is the AntiDDoS8160-BASE-DC-200?

The AntiDDoS8160-BASE-DC-200 offers excellent cost-effectiveness by providing a robust defense against DDoS attacks with its 200G capacity, making it suitable for large-scale network deployments.

What are the key features of the AntiDDoS8160-BASE-DC-200?

The AntiDDoS8160-BASE-DC-200 features 200G capacity, a scalable chassis (X16 DC Chassis), and components like 2 MPUs and 4 SFU200Bs, ensuring high performance and adaptability.

What application scenarios is the AntiDDoS8160-BASE-DC-200 suitable for?

The AntiDDoS8160-BASE-DC-200 is ideal for large data centers, ISPs, and enterprise networks requiring high-capacity DDoS protection.

How to install the AntiDDoS8160-BASE-DC-200?

Installation involves mounting the X16 DC Chassis, then installing the 2 MPUs and 4 SFU200Bs, followed by connecting power cables and network interfaces.

Does the AntiDDoS8160-BASE-DC-200 require regular upgrades?

Regular firmware and software updates are recommended to ensure the AntiDDoS8160-BASE-DC-200 maintains optimal performance and security against evolving threats.

Are there alternative products to the AntiDDoS8160-BASE-DC-200?

Alternatives include other Huawei AntiDDoS series products like the AntiDDoS8000 series, depending on specific capacity and feature needs.

What are common troubleshooting steps for the AntiDDoS8160-BASE-DC-200?

Common steps include checking power connections, verifying active network links, updating firmware, and consulting system logs for error messages.
