AR2220-S

5 1
5/5.0
1 Review(s)
Model: Huawei AR2200 Series Router AR2220-S AR0M022SBA00
Detail: AR2220-S, 3 Gigabit Ethernet WAN (RJ-45 or SFP) port, 2 USB, 4 SIC, 2 WSIC, 1 DSP Slot
Price: US$900.00
Condition: Brand New Sealed
Availability: In stock
US$ 900.00 In stock Brand New Sealed
OR

Ask Our Experts

Live Chat | Email

  • +1-626-239-8066 (USA)
  • +852-3174-6166 (HK)
  • +852-3050-1066 (Fax)
Get Quotes up to
2x Faster
Project Inquiry
Overview

Overview (AR2220-S)

Huawei AR G3 AR2200 series router AR2220-S is the next-generation enterprise-class routers based on the Huawei proprietary Versatile Routing Platform (VRP) and designs for mid size enterprise or branch office.

Quick Specs

Figure 1 shows the appearance of Huawei Router - AR2220-S.

 AR2220-S-appearance

Table 1 shows the Quick Specs.

Product Code

Huawei Router - AR2220-S

Memory

2 GB

Flash

2 GB

Service interfaces (standard configuration)

WAN interfaces: 2 GE electrical interfaces and 1 GE combo interface

LAN interfaces: none

Extended slots

4 SIC slots and 2 WSIC slots

Power module type

Pluggable power module

Weight

6 kg (13.2 lb)

Dimensions (W x D x H)

442.0 mm x 420.0 mm x 44.5 mm

Product Details

Figure 2 shows the front panel of AR2220-S.

 AR2220-S-front

Note:

Micro SD

ESD jack

Two GE Combo

Two GE electrical interface

Mini USB

CON/AUX

RST button

Figure 3 shows the back panel of AR2220-S.

 AR2220-S-back

Note:There are 4 SIC slots and 2 WSIC slots on the back panel. These cards must purchase separately.

The Modules, Optical Transceiver

Table 2 shows the recommended elements for the AR2220-S.

Model

Description

AC power module

AR0MPSAR15A

150W RPS Power Module

FE-SFP Optical Transceiver

SFP-FE-SX-MM1310

SFP,100M/155M,Multi-mode Module(1310nm,2km,LC)

eSFP-FE-LX-SM1310

eSFP,100M/155M,Single-mode Module(1310nm,15km,LC)

S-SFP-FE-LH40-SM1310

eSFP,FE,Single-mode Module(1310nm,40km,LC)

GE-SFP Optical Transceiver

SFP-1000BaseT

SFP,GE,Electrical Interface Module(100m,RJ45)

eSFP-GE-SX-MM850

eSFP,GE,Multi-mode Module(850nm,0.55km,LC)

SFP-GE-LX-SM1310

eSFP,GE,Single-mode Module(1310nm,10km,LC)

S-SFP-GE-LH40-SM1310

eSFP,GE,Single-mode Module(1310nm,40km,LC)

S-SFP-GE-LH40-SM1550

eSFP,GE,Single-mode Module(1550nm,40km,LC)

Compare to Similar Items

Table 3 shows the comparison between AR2220-S and AR2220E.

Model

AR2220-S

AR2220E

WAN Speed with Services

1 Gbit/s

800 Mbit/s

Fixed WAN Ports

1 x GE Combo

2 x GE

Fixed LAN Ports

4 x GE + 4 x GE SFP +2 x GE Combo

3 x GE (1 x Combo)

Wireless Controller

Wireless Controller is integrated in software

Memory

2 GB

1 GB

Get More Information

Do you have any question about the AR2220-S?

Contact us now via Live Chat or cisco@router-switch.com.

Specification

Specification (AR2220-S)

AR2220-S Specification

WAN Speed with Services***

400 Mbit/s

Firewall Performance (large packets)

1.9 Gbit/s

Number of recommended users

300

Fixed WAN Ports

3 x GE (1 x Combo port)

SIC Slots

4

WSIC Slots (default/max**)

2/4

XSIC Slots (default/max**)

0/2

EXSIC Slot (shared with XSIC slots)

0

DSP Slots

1

USB 2.0 Ports

2

Mini-USB Ports

1

Console Port

1

Memory

2 GB

Flash
(default/max**)

2 GB/8 GB

Maximum Power

150W

Redundant Power Supply

-

AC Power

100V to 240V

Frequency

50 Hz/60 Hz

DC Power

-48V to -60V

Dimensions (height x width x depth)

44.5 mm x 442 mm x 420 mm

Weight

4.95 kg (without power module and interface card)

Ambient Temperature

0°C to 45°C

Relative Humidity

5% to 95% (non-condensing)

Shipping & Payment

Delivery

Cargo will be delivered within 1 day after payment arrived. Tracking Number will be offered once delivery done.

Delivery OptionsEstimated Delivery Time
DHL 2-4 business days
Fedex 2-4 business days
Hong Kong EMS 5-10 business days
Hong Kong Air Parcel 10-20 business days
By Sea 10-20 business days

Notice:

Above mentioned information are just for your reference only,we will keep you posted for the tracking delivery schedule.There are two delivery options available for by air and by sea:

Deliver to port:

Router-switch.com is responsible for transporting goods to port. All subsequent customs and transportation fees are the
responsibility of the buyer. Router-switch will recommend trustworthy local freight forwarders to you.Router-switch.com can facilitate the progress under buyer's permission and at buyer's expense.

Deliver to door:

Router-switch.com will quote all destination charge prior once we have confirmed order.
Router-switch.com is responsible for transporting goods to door after you have made the payment.

Payment Methods

Paypal Master Card Visa
Discover American
Express
JCB
Wire Transfer eCheck WestUnion
Warranty

Warranty

100% Low Price Guarantee:

Router-switch.com provides high-quality products at low wholesale prices

All items are ORIGINAL and GENUINE only:

Item conditions are all "New Sealed".
All items are fully tested with working conditions by Huawei certified engineer under customers' permission.

100% Money Back Guarantee:

If your returns meet our relevent standards,you can contact our customer service team to exchange or return any product that you bought from us.

Professional Technical Support:

Router-switch.com experienced technical team can provide support over the phone, by chat, by email or by remotely login.

Flexible Secure Payment & Shipment:

Verified authorization: Mcafee Secure, VeriSign Secured

Return Material Authorization (RMA) Process

Standard Hardware Warranty Policy:

Original new sealed Huawei product: 1 Year.

The Support Contacts:

If your Huawei products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.

Reviews

Customer Reviews

5 5
5 (1 reviews)
5 Stars
1
4 Stars
0
3 Stars
0
2 Stars
0
1 Stars
0

Share your thoughts with other customers?

Posted on 5/13/2015
Verified Buyer
55
AR2220-S

I havn't bought it but it seems good. 3 GE port, 2 USB, 4 SIC, 2 WSIC, 1 DSP Slot?? Good configuration. I think I will buy it when I need in the future.
