Brocade Switch Reset: The Complete Troubleshooting & Recovery Guide

Resetting a Brocade switch (now RUCKUS ICX series) is a common task during troubleshooting, configuration recovery, or repurposing equipment. However, the exact reset method depends heavily on your scenario—incorrect operations may wipe the configuration or even break the boot sequence. This guide provides a step-by-step reset framework for Brocade switches across ICX 6xxx/7xxx/8xxx families, covering soft resets, factory resets, BootROM recovery, password recovery, stack operations, and post-reset best practices.

Table of Contents

• Part 1: When You Should Reset a Brocade/ICX Switch
• Part 2: Soft Reset (Non-Destructive Reboot)
• Part 3: Factory Reset (Clear Configuration to Default)
• Part 4: BootROM Recovery
• Part 5: Password Recovery
• Part 6: Resetting Brocade / RUCKUS ICX Stacks
• Part 7: Post-Reset Checklist

Part 1: When You Should Reset a Brocade/ICX Switch

A reset is usually required in the following scenarios:

• Minor Performance Issues: CPU spikes, CLI lag, management plane unresponsive → Use soft reboot.
• Configuration Errors: VLAN misconfiguration, stacking issues, wrong routing → Use factory reset.
• Switch Cannot Boot Normally: Corrupted image, wrong boot path, stuck in loader → Use BootROM recovery.
• Forgotten Password: Admin lockout, repurposing old devices → Use BootROM password recovery.

Part 2: Soft Reset (Non-Destructive Reboot)

Use this method if the switch is responsive and you only need to clear memory or reload an image.

Example CLI command to reload immediately:

reload

Example CLI command to schedule a reload after 5 minutes:

reload after 5

Notes:

• Startup-config is preserved.
• Only running processes are restarted.
• Safe for production if executed during a maintenance window.

Part 3: Factory Reset (Clear Configuration to Default)

Use factory reset for repurposing, decommissioning, or lab redeployment.

Reset Running Config (Non-destructive)

write erase
reload

Full Factory Reset (Clear Startup + System Files)

erase startup-config
erase flash system
reload

This deletes:

• Startup-config
• DHCP config
• User accounts
• VLAN database
• Static routes
• SNMP settings

What remains:

• Boot image (unless flash manually erased)
• Licensing state

Part 4: BootROM Recovery

If normal OS cannot load, enter BootROM menu using console cable.

1. Connect via console (9600/8/N/1)
2. Power cycle the switch
3. Press 'b' repeatedly to stop at boot monitor
4. In BootROM, select:
   6 — Restore to factory default
   7 — Erase flash (if firmware corrupted)

Part 5: Password Recovery (No Data Loss)

Steps to reset forgotten admin password safely:

1. Enter BootROM (power cycle + press b)
2. Select Recover password
3. Switch boots without password check
4. Enter enable mode:
   enable
5. Set new password:
   username admin password
6. Save:
   write memory

Part 6: Resetting Brocade / RUCKUS ICX Stacks

For stacks, reset individual members or entire stack:

Reset Single Member

stack unit  reboot

Factory Reset One Member (Without Breaking Stack)

stack unit  erase startup-config

Full Stack Factory Reset

erase startup-config
reload

Part 7: Post-Reset Checklist

After reboot or factory restore:

• Verify system status:

  show version
  show flash
  show running-config

• Confirm port/VLAN status:

  show vlan
  show interface brief

• Reload latest RUCKUS software:

  copy tftp flash
  boot system flash primary

• Hardening best practices: change default password, enable SSH, configure AAA/RADIUS, disable unnecessary services, set backup schedule.
