Overview

Overview (S5710-28C-EI)

The S5710-28C-EI gigabit enterprise switch is next-generation energy-saving switch developed by Huawei to meet the demand for high-bandwidth access and Ethernet multi-service aggregation. With 24 GE ports and 2 extended slots, it provides a large switching capacity and high-density GE ports to implement 10 Gbit/s upstream transmissions, widely used in various application scenarios like enterprise park access, convergence, gigabit access of data center application scenarios. The S5710-28C-EI is easy to install and maintain, reducing workloads for network planning, construction, and maintenance, then it uses advanced reliability, security, and energy conservation technology to help enterprise customers build a next-generation IT network.

Quick Specs

Figure 1 shows the appearance of Huawei S5710-28C-EI.

S5710-28C-EI Appearance

 Table 1 shows the Quick Specs.

Product Code

S5710-28C-EI

Fixed Ports

24 Ethernet 10/100/1,000 ports, 4 of which are dual-purpose 10/100/1,000 or SFP, 4 10 Gig SFP+ ports

Extended Slots

2 extended slots

Memory (RAM)

512 MB

Flash

V200R001: 64 MB

V200R002 and later versions: 200 MB

MAC Address Table Size Forwarding Performance

32K MAC

Forwarding Performance

156 Mpps

Switching Capacity

416 Gbit/s

Power Supply

Double hot-swappable AC/DC power supplies

Voltage Required

AC:

Rated voltage range: 100V to 240V AC, 50/60 Hz Maximum voltage range: 90V to 264V AC, 50/60 Hz

DC:

Rated voltage range: –48V to –60V, DC Maximum voltage range: –36V to –72V, DC

Power Consumption Operational

< 100W

Dimensions (W x D x H)

442 mm x 420 mm x 43.6 mm

Weight

7 kg

Product Details

Figure 2 shows the front panel of Huawei S5710-28C-EI.

S5710-28C-EI Front Panel

 Note:

Twenty 10/100/1000BASE-T ports

Four combo ports (10/100/1000BASE-T + 100/1000BASE-X)

Four 10GE SFP+ ports

ETH management port

One mini USB port

One console port

One USB port





Figure 3 shows the back panel of Huawei S5710-28C-EI.

S5710-28C-EI Back Panel

 Note:

Ground screw

Rear card slot 1

Rear card slot 2

ESN label

Power module slot 2

Power module slot 1

* The ground screw is used with a ground cable.

* You can draw the label out to view the ESN and MAC address of the switch.

Optical Modules

Table 2 shows the recommended optical modules.



Model

Description

FE-SFP Optical Transceiver

SFP-FE-SX-MM1310

Optical Transceiver,SFP,100M/155M,Multi-mode Module(1310nm,2km,LC)

eSFP-FE-LX-SM1310

Optical Transceiver,eSFP,100M/155M,Single-mode Module(1310nm,15km,LC)

S-SFP-FE-LH40-SM1310

Optical Transceiver, SFP, FE, Single-mode Module(1310nm,40km,LC)

GE-SFP Optical Transceiver

SFP-1000BaseT

Electrical Transceiver, SFP, GE, Electrical Interface Module(100m,RJ45)

eSFP-GE-SX-MM850

Optical Transceiver, eSFP, GE, Multi-mode Module(850nm,0.55km,LC)

SFP-GE-LX-SM1310

Optical Transceiver, eSFP, GE, Single-mode Module(1310nm,10km,LC)

S-SFP-GE-LH40-SM1310

Optical Transceiver, eSFP, GE, Sngle-mode Module(1310nm,40km,LC)

S-SFP-GE-LH40-SM1550

Optical Transceiver, eSFP, GE, Single-mode Module(1550nm,40km,LC)

10G-SFP+ Optical Transceiver

SFP-10G-USR

10GBase-USR Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.1km,LC)

OMXD30000

Optical Transceiver,SFP+,10G,Multi-mode Module(850nm,0.3km,LC)

OSX010000

Optical Transceiver,SFP+,10G,Single-mode Module(1310nm,10km,LC)

Compare with Similar Item

Table 3 shows the comparison of Huawei S5700-28C-EI, 5710-28C-EI and S5710-28C-PWR-EI-AC.

Models

S5700-28C-EI

S5710-28C-EI

S5710-28C-PWR-EI-AC

Fixed Ports

24 x 10/100/1,000 Base-T

24 x 10/100/1,000 Base-T, 4 of which are dual-purpose 10/100/1,000 or SFP, 4 x 10 GE SFP+

24 x 10/100/1,000 Base-T, 4 of which are dual-purpose 10/100/1,000 or SFP, 4 x 10 GE SFP+

Extended Slots

2 extended slots, one for an uplink subcard and the other for a stack card

2 extended slots  for uplink subcards

2 extended slots  for uplink subcards.

Power Supply

Double hot-swappable AC/DC

Double hot-swappable AC/DC

Double hot-swappable AC, PoE+

Forwarding Performance

96 Mpps

 156 Mpps

156 Mpps

Switching Capacity

256 Gbit/s

  416 Gbit/s

416 Gbit/s

Power Consumption

< 60W

< 100W

< 942W

Comparison between LI, SI, EI and HI

Huawei S5700 Series Enterprise Switches provides LI (Lite), SI (Standard), EI (Enhanced) and HI (Hyper) models for users. There are some differences among these four versions.

Click this PDF to know more.

Comparison of Huawei S5700-LI, SI, EI and HI Series Switches.pdf

Get More Information

Do you have any question about the Huawei S5710-28C-EI switch?

Contact us now via Live Chat or sales@router-switch.com.

Specification

Specification (S5710-28C-EI)

S5710-28C-EI Specification

Fixed port

24x10/100/

1000Base-T

Extended slot

S5700C Provide two extended slots, one for an uplink subcard and the other for a stack card.

S5710C Provide two extended slots for uplink subcards.

MAC address table

IEEE 802.1d compliance

32K MAC

MAC address learning and aging

Static, dynamic, and blackhole MAC address entries

Packet filtering based on source MAC addresses

VLAN

4K VLANs

Guest VLAN and voice VLAN

GVRP

MUX VLAN

VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports

1:1 and N:1 VLAN Mapping

Reliability

RRPP ring topology and RRPP multi-instance

Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level

protection switchover

SEP

ERPS (G.8032)

BFD for OSPF, BFD for IS-IS, BFD for VRRP, and BFD for PIM

STP(IEEE 802.1d), RSTP(IEEE 802.1w), and MSTP(IEEE 802.1s)

BPDU protection, root protection, and loop protection

E-Trunk

IP routing

Static routing, RIPv1/v2, RIGng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, and ECMP

IPv6 features

Neighbor Discovery (ND)

Path MTU (PMTU)

IPv6 ping, IPv6 tracert, and IPv6 Telnet

ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol

type

MLD v1/v2 snooping

IPv4 and IPv6 dual stack

6to4 tunnel, ISATAP tunnel, and manually configur ed tunnel

Multicast

IGMP v1/v2/v3 snooping and IGMP fast leave

Multicast forwarding in a VLAN and multicast replication between VLANs

Multicast load balancing among member ports of a trunk

Controllable multicast

Port-based multicast traffic statistics

IGMP v1/v2/v3, PIM-SM, PIM-DM, and PIM-SSM

MSDP

QoS/ACL

Rate limiting on packets sent and received by an interface

Packet redirection

Port-based traffic policing and two-rate three-color CAR

Eight queues on each port

WRR, DRR, SP, WRR+SP, and DRR+SP queue scheduling algorithms

WRED (supported by the S5710-EI)

Re-marking of the 802.1p priority and DSCP priority

Packet filtering at Layer 2 to Layer 4, filtering out invalid fr ames based on the source MAC

address, destination MAC address, source IP address, destination IP address, TCP/UDP port

number, protocol type, and VLAN ID

Rate limiting in each queue and traffic shaping on ports

Security

User privilege management and password protection

DoS attack defense, ARP attack defense, and ICMP attack defense

Binding of the IP address, MAC address, interface, and VLAN

Port isolation, port security, and sticky MAC

Blackhole MAC address entries

Limit on the number of learned MAC addresses

802.1x authentication and limit on the number of users on an interface

AAA authentication, RADIUS authentication, HWTACACS+ authentication, and NAC

SSH v2.0

Hypertext Transfer Protocol Secure (HTTPS)

CPU defense

Blacklist and whitelist

Management and maintenance



iStack

MAC Forced Forwarding (MFF)

Virtual cable test

SNMP v1/v2c/v3

RMON

Web NMS

System logs and alarms of different levels

NetStream (supported by S5710-EI)

sFlow

Interoperability

Supports VBST (Compatible with PVST/PVST+/RPVST)

Supports LNP (Similar to DTP)

Supports VCMP (Similar to VTP)

Operating environment



Operating temperature: 0oC–50oC

Relative humidity: 5%–95% (non-condensing)

Input voltage

AC:

Rated voltage range: 100 V to 240 V AC, 50/60 Hz

Maximum voltage range: 90 V to 264 V AC, 50/60 Hz

DC:

Rated voltage range: –48 V to –60 V, DC

Maximum voltage range: –36 V to –72 V, DC

Note: PoE-support switches do not use DC power supplies.

Dimensions(W x D x H)

442 mm x 420 mm x 43.6 mm

Power consumption

Non-PoE model:< 60W

PoE model: < 842W(PoE: 740W)

Shipping & Payment
