PVDM2-48

Model: PVDM2-48 Router Voice DSP Module
Detail: 48-Channel Packet Voice/Fax DSP Module
List Price: US$2,400.00
Price: $1,128.00
You save: US$1,272.00 (53% OFF)
Condition: Brand New Sealed
Availability: In stock
Shipping:
Express Shipping to Worldwide
2-6 Days, via DHL, FedEx, EMS, etc. ?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
US$ 1,128.00 In stock Brand New Sealed
OR

PVDM2-48 SMARTnet Service Tool

Order Cisco SMARTnet Warranty? Fast Quote Now

Ask Our Experts

Live Chat | Email

  • +1-626-239-8066 (USA)
  • +852-3174-6166 (HK)
  • +852-3050-1066 (Fax)
Get Quotes up to
2x Faster
Project Inquiry
Overview

Overview (PVDM2-48)

The Cisco ® High-Density Packet Voice Digital Signal Processor (DSP) Module (PVDM2) enables Cisco Integrated Services Routers to provide high-density voice connectivity, conferencing, and transcoding capabilities in Cisco IP Communications solutions. Cisco Integrated Services Routers provide enterprises and service providers with a toll bypass solution by connecting their existing telephony equipment (such as private branch exchanges [PBXs], key systems, analog telephones, and fax machines) to a toll-free data network and eventually migrating customers to Cisco Unified Communication Architecture for Voice, Video and Integrated Data IP telephony solutions.

The high-density packet voice DSP modules are available in five versions: PVDM2-8, PVDM2-16, PVDM2-32, PVDM2-48, and PVDM2-64.

Quick Specs

Figure 1 shows the appearance of PVDM2-48.

PVDM2-48 Appearance

Table 1 shows the Quick Specs.

Product Code

PVDM2-48

Description

48-channel packet fax and voice DSP module

Maximum Number of Channels in G.711

48

Maximum Number of Channels in High-Complexity Codecs

18

Maximum Number of Channels in Medium-Complexity Codecs

24

Product Details

Figure 2 shows PVDM2 SIMM Slots on the Cisco High-Density Digital Voice Network Modules.

 PVDM2 SIMM Slots on the Cisco High-Density Digital Voice Network Modules

Compare to Similar Items

Table 2 shows the comparison of PVDM2-8, PVDM2-32, PVDM2-64, PVDM2-16 and PVDM2-48.

Product Code

PVDM2-8

PVDM2-16

PVDM2-32

PVDM2-64

PVDM2-48

Description

8-channel packet fax and voice DSP module

16-channel packet fax and voice DSP module

32-channel packet fax and voice DSP module

64-channel packet fax and voice DSP module

48-channel packet fax and voice DSP module

Maximum Number of Channels in G.711

8

16

32

64

48

Maximum Number of Channels in High-Complexity Codecs

4

6

12

24

18

Maximum Number of Channels in Medium-Complexity Codecs

4

8

16

32

24

Get More Information

Do you have any question about the PVDM2-48?

Contact us now via Live Chat or sales@router-switch.com.

Specification

Specification (PVDM2-48)

PVDM2 Modules Specifications

Components

DSP

• Texas Instruments TNETV2510GGW for PVDM2-16, PVDM2-32, PVDM2-48, and PVDM2-64

• Texas Instruments TNETV2505GGW for PVDM2-8

DSP CPU Clock

• 200 MHz for TNETV2510GGW

• 175MHz for TNETV2505GGW

DSP External Memory

128-megabit synchronous dynamic RAM for each DSP (for both TI 2510 and TI 2505)

Interface

80-pin SIMM interface

Features

Echo Cancellation

Software echo cancellation compliant with ITU-I G.168, with 64-ms tail coverage

Approvals and Compliance

Safety

• IEC 60950 (worldwide) and AS/NZS 3260 (Australia and New Zealand)

• CAN/CSA-C22.2 No. 60950 (Canada) and GB4943-95 (People's Republic of China)

• EN60950 (CENELEC; includes EU and EFTA)

• SS337 (Singapore; PSB approval), NOM-019-SCFI-1998 (Mexico), and UL 60950 3rd edition (United States)

Homologation

Platform dependent

Mean Time between Failure (MTBF)

System dependent

EMC

CISPR22, Class B

Emissions

EN55022, Class B

Emissions

CFR47, Part 15, Subpart B, Class B

Emissions

EN61000-3-2

Harmonics

EN61000-3-3

Flicker

CISPR24

Immunity

EN 55024

Immunity

EN50082-1

Immunity

EN61000-3-2

Harmonics

EN 61000-3-3

Flicker

EN 61000-4-2

Electrostatic discharge (ESD)

EN 61000-4-3

Radio frequency (RF) fields

EN 61000-4-4

EFT

EN 61000-4-5

Surge

EN 61000-4-6

Conducted RF

EN 6100-4-8

Power-frequency magnetic fields

EN 61000-4-11

Voltage dips, sags, and interruptions
