CISCO1921-T1SEC/K9

Model: CISCO1921-T1SEC/K9 Cisco 1921 Router ISR G2
Detail: Cisco 1921 T1 Bundle incl. HWIC-1DSU-T1,256F/512D, SEC Lic
Price: US$1,193.00
List Price: US$2,295.00
You save: US$1,102.00 (48% OFF)
Condition: Brand New Sealed
Availability: In stock
US$ 1,193.00 In stock Brand New Sealed
OR
Product Overview

Overview (CISCO1921-T1SEC/K9)

CISCO1921-T1SEC/K9 includes Cisco 1921 T1 Bundle - HWIC-1DSU-T1, and 256F/512D, SEC License. The Cisco 1921 builds on the best-in-class. All Cisco 1900 Series Integrated Services Routers offer embedded hardware encryption acceleration, and advanced security services. In addition, the platforms support the industry's widest range of wired and wireless connectivity options such as Serial, T1/E1, xDSL, Gigabit Ethernet, and third-generation (3G) wireless.

Quick Specs

Figure 1 shows the front view of CISCO1921-T1SEC/K9.

CISCO1921-T1SEC/K9

Table 1 shows the Quick Specs of the CISCO1921-T1SEC/K9.

Product Code

CISCO1921-T1SEC/K9

Bundle

HWIC-1DSU-T1, and 256F/512D, SEC License

Enclosure Type

Desktop, rack-mountable - modular - 1U

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Network / Transport Protocol

IPSec, L2TPv3

Routing Protocol

OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, static IP routing, IGMPv3,GRE,PIM-SSM,

static IPv4 routing, static IPv6 routing, policy-based routing (PBR), MPLS

Remote Management Protocol

SNMP, RMON

Compliant Standards

IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag

Power

AC 120/230 V ( 50/60 Hz )

Dimensions (WxDxH)

34.3 cm x 29.2 cm x 4.4 cm

Manufacturer Warranty

1 year warranty

Product Details

Figure 2 shows the ports and LEDs on the front panel of CISCO1921/K9, only for reference. The appearance of CISCO1921-T1SEC/K9 is the same as this router’s, except that it has the installed HWIC-1DSU-T1.

CISCO1921-K9 For Reference

Note:

EHWIC slot

USB serial port

Auxiliary port

EN(RJ-45 console port)

GE 0/0(down)and 0/1(up)

RJ-45 serial console port

Kensington security slot

USB port

On/Off switch

Baud reset

Input power connector

POE

Flash LED

Ground connector

EN (USB serial console port)



The Accessories

Table 2 shows some recommended accessories of CISCO1921-T1SEC/K9.

Models

Description

EHWIC-1GE-SFP-CU

Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU

EHWIC-4ESG

Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers

HWIC-2FE

HWIC two routed port Cisco Router High-Speed WAN Interface card

HWIC-1T

1-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card

HWIC-2T

2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card

VWIC3-1MFT-T1/E1

Cisco Voice/WAN Card VWIC3-1MFT-T1/E1

VWIC3-2MFT-T1/E1

Cisco Voice/WAN Card VWIC3-2MFT-T1/E1

VWIC3-1MFT-G703

Cisco Voice & WAN T1/E1 interface moudle VWIC3-1MFT-G703

VWIC3-2MFT-G703

Cisco Voice/WAN Card VWIC3-2MFT-G703

Compare to Similar Switches

Table 3 shows the comparison between CISCO1921-T1SEC/K9 and CISCO1921-SEC/K9.

Model

CISCO1921-T1SEC/K9

CISCO1921-SEC/K9

DRAM

512 MB (installed) / 512 MB (max)

512 MB (installed) / 512 MB (max)

Flash Memory

256 MB (installed) / 256 MB (max)

256 MB (installed) / 256 MB (max)

Bundle

HWIC-1DSU-T1,256F/512D,

SEC Lic

w/SEC license PAK

Get More Information

Do you have any question about the CISCO1921-T1SEC/K9?

Contact us now via Live Chat or cisco@router-switch.com.

Specification

Specification (CISCO1921-T1SEC/K9)

General
Device Type: Router
Form Factor: External, modular, 1U
Width: 13.5 in
Depth: 11.5 in
Height: 1.7 in
Weight: 11.9 lbs
Memory
RAM: 512 MB (installed) / 512 MB (max)
Flash Memory: 256 MB (installed) / 256 MB (max)
Networking
Connectivity Technology: Wired
Line Rate: T-1
Line Coding Format: AMI, B8ZS
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol: L2TP, IPSec
Routing Protocol: OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing
Remote Management Protocol: SNMP, RMON
Features: Firewall protection, VPN support, MPLS support, VLAN support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Quality of Service (QoS)
Compliant Standards: IEEE 802.3ah, IEEE 802.1ag
Communications
Type: DSU/CSU
Protocols & Specifications: HDLC
Max Transfer Rate: 1.544 Mbps
Expansion / Connectivity
Expansion Slots Total (Free): 2 ( 1 ) x EHWIC
Interfaces: 2 x network, Ethernet 10Base-T/100Base-TX/1000Base-T, RJ-45 , 1 x serial, console , 1 x management, console, mini-USB Type B , 1 x serial, auxiliary , 1 x Hi-Speed USB, 4 pin USB Type A , 1 x m
Miscellaneous
Compliant Standards: VCCI, CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, ICES-003 Class A, CS-03, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1
Power
Power Device: Power supply, internal
Voltage Required: AC 120/230 V ( 50/60 Hz )
Software / System Requirements
OS Provided: Cisco IOS Security
Manufacturer Warranty
Service & Support: 1 year warranty
Service & Support Details: Limited warranty, 1 year
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 10, 85%
