XFP-10GLR-OC192SR

Model: XFP-10GLR-OC192SR Multirate XFP module for 10GBASE-LR and OC192 SR-1
Detail: Multirate XFP module for 10GBASE-LR and OC192 SR-1
List Price: US$4,000.00
Price: $1,880.00
You save: US$2,120.00 (53% OFF)
Condition: Original New
Shipping:
Express Shipping to Ashburn, VA, United States
2-6 Days, via DHL, FedEx, EMS, etc. ?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
US$ 1,880.00 Original New
SMARTnet
XFP-10GLR-OC192SR SMARTnet Service Tool.

Fast Quote Now

Ask Our Experts

Live Chat | Email

  • +1-626-239-8066 (USA)
  • +852-3174-6166 (HK)
  • +852-3050-1066 (Fax)
Get Quotes up to
2x Faster
Project Inquiry
Overview

Overview (XFP-10GLR-OC192SR)

original new
Cisco Original, Not OEM Compatible Transceiver.
Genuine Guaranteed, Cisco Systems Factory Sealed, Support Detail Full Contract Period - 1 Year

XFP-10GLR-OC192SR - Cisco Multirate 10GBASE-LR/-LW and OC-192/STM-64 SR-1 XFP Module for SMF, low power (1.5W).

The Cisco® XFP Module offers customers a variety of 10 Gigabit Ethernet and Packet-over-SONET/SDH (POS) connectivity options for data center, enterprise wiring closet, and service provider transport applications.

Main features of the Cisco XFP Module include:

● Supports 10GBASE Ethernet and OC-192/STM-64 data rates

● Hot-swappable input/output device plugs into a XFP port of a Cisco Systems® router to link the port with the network

● Provides flexibility of interface choice

● Supports “pay-as-you-populate” model

● Supports the digital optical monitoring capability

● Supports the Cisco quality identification (ID) feature that helps enable a Cisco switch or router to identify whether the module is a Cisco certified and tested XFP

● Supports optical interoperability with respective Cisco 10GBASE XENPAK and X2, and SFP+ modules on the same link

Quick Specs

Figure 1 shows the appearance of XFP-10GLR-OC192SR.

 XFP-10GLR-OC192SR

Table 1 shows the Quick Specs.



Wavelength (nm)

Cable Type

Core Size (micron)

Modal Bandwidth (MHz km)

Cable Distance

Cisco Multirate 10GBASE-LR/-LW and OC-192/STM-64 SR-1 XFP Module for SMF

1310

SMF

G.652

none

●  10 km (10 Gigabit Ethernet)

●  2 km (OC-192/STM-64 SR-1)

Table 2.Optical Transmit and Receive Specifications

Product

Type

Transmit Power (dBm)

Receive Power (dBm)

Transmit Wavelength (nm)

Receive Wavelength (nm)





Maximum

Minimum

Maximum

Minimum

Range

Range

Cisco Multirate 10GBASE-LR/-LW and OC-192/STM-64 SR-1 XFP Module for SMF

10GBASE-LR/-LW 1310-nm SMF

+0.5

-8.2

+0.5

-14.4

1260 to 1355

1260 to 1565

OC-192/STM-64 SR-1 1310-nm SMF

-1.0

-6.0

-1.0

-11.0

1290 to 1330

1260 to 1565

Get More Information

Do you have any question about the XFP-10GLR-OC192SR?

Contact us now via Live Chat or sales@router-switch.com.

Specification

Specification (XFP-10GLR-OC192SR)

Multirate XFP module for 10GBASE-LR and OC192 SR-1

SMARTnet

SMARTnet Support Quick Guide

Cisco SMARTnet Overview - Cisco SMARTnet Service Codes - Cisco SMARTnet Types
Cisco SMARTnet F.A.Q

XFP-10GLR-OC192SR SMARTnet Service Tool

Product Name Detail Price
CON-3SNT-XFPR10GL 3YR SNTC 8X5XNBD Multirate XFP module for 10GBASE-LR Inquiry
CON-3SNTP-XFPR10GL 3YR SNTC 24X7X4 Multirate XFP module for 10GBASE-LR Inquiry
CON-SNT-XFP10GSR SNTC-8X5XNBD Multirate XFP module for 10GBASE-LR and Inquiry
CON-SNTE-XFPR10GL SNTC-8X5X4 Multirate XFP module for 10GBASE-LR Inquiry
CON-SNTP-XFPR10GL SNTC-24X7X4 Multirate XFP module for 10GBASE-LR Inquiry
CON-NCD2-XFPR10GL CMB SVC 24X7X2 NCD2 Multirate XFP module for 10GBASE-LR Inquiry
CON-NCD2P-XFPR10GL CMBSV 24X7X2OS NCD2P Multirate XFP module for 10GBASE-LR Inquiry
CON-NCD4P-XFPR10GL CMBSV 24X7X4OS NCD4P Multirate XFP module for 10GBASE-LR Inquiry
CON-NCD4S-XFPR10GL CMB SV 8X5X4OS NCD4S Multirate XFP module for 10GBASE-LR Inquiry
CON-NCDCS-XFPR10GL CBSV 8X5XNBDOS NCDCS Multirate XFP module for 10GBASE-LR Inquiry
CON-NCDE-XFPR10GL CMB SVC 8X5X4 NCDE Multirate XFP module for 10GBASE-LR Inquiry
CON-NCDP-XFPR10GL CMB SVC 24X7X4 NCDP Multirate XFP module for 10GBASE-LR Inquiry
CON-NCDT-XFPR10GL CMBSVC 8X5XNBD NCDT Multirate XFP module for 10GBASE-LR Inquiry
CON-NCDW-XFPR10GL CMB SPT SVC SW NCDW Multirate XFP module for 10GBASE-LR Inquiry
CON-NCF2-XFPR10GL CMB SPT SVC 24X7X2 Multirate XFP module for 10GBASE-LR Inquiry
CON-NCF2P-XFPR10GL CMB SPT SVC 24X7X2OS Multirate XFP module for 10GBASE-LR Inquiry
CON-NCF4P-XFPR10GL CMB SPT SVC 24X7X4OS Multirate XFP module for 10GBASE-LR Inquiry
CON-NCF4S-XFPR10GL CMB SPT SVC 8X5X4OS Multirate XFP module for 10GBASE-LR Inquiry
CON-NCFCS-XFPR10GL CMB SPT SVC 8X5XNBDO Multirate XFP module for 10GBASE-LR Inquiry
CON-NCFE-XFPR10GL CMB SPT SVC 8X5X4 Multirate XFP module for 10GBASE-LR Inquiry
CON-NCFP-XFPR10GL CMB SPT SVC 24X7X4 Multirate XFP module for 10GBASE-LR Inquiry
CON-NCFT-XFPR10GL CMB SPT SVC 8X5XNBD Multirate XFP module for 10GBASE-LR Inquiry
CON-NCFW-XFPR10GL CMB SPT SVC SW Multirate XFP module for 10GBASE-LR Inquiry
CON-NCH2-XFPR10GL CMB SVC 24X7X2 NCH2 Multirate XFP module for 10GBASE-LR Inquiry
CON-NCH2P-XFPR10GL CMBSV 24X7X2OS NCH2P Multirate XFP module for 10GBASE-LR Inquiry
CON-NCH4P-XFPR10GL CMBSV 24X7X4OS NCH4P Multirate XFP module for 10GBASE-LR Inquiry
CON-NCH4S-XFPR10GL CMB SV 8X5X4OS NCH4S Multirate XFP module for 10GBASE-LR Inquiry
CON-NCHCS-XFPR10GL CBSV 8X5XNBDOS NCHCS Multirate XFP module for 10GBASE-LR Inquiry
CON-NCHE-XFPR10GL CMB SVC 8X5X4 NCHE Multirate XFP module for 10GBASE-LR Inquiry
CON-NCHP-XFPR10GL CMB SVC 24X7X4 NCHP Multirate XFP module for 10GBASE-LR Inquiry
CON-NCHT-XFPR10GL CMBSVC 8X5XNBD NCHT Multirate XFP module for 10GBASE-LR Inquiry
CON-NCHW-XFPR10GL CMB SPT SVC SW NCHW Multirate XFP module for 10GBASE-LR Inquiry
CON-NCJ2P-XFPR10GL CMBSV 24X7X2OS NCJ2P Multirate XFP module for 10GBASE-LR Inquiry
CON-NCJ4P-XFPR10GL CMBSV 24X7X4OS NCJ4P Multirate XFP module for 10GBASE-LR Inquiry
CON-NCJ4S-XFPR10GL CMB SV 8X5X4OS NCJ4S Multirate XFP module for 10GBASE-LR Inquiry
CON-NCJCS-XFPR10GL CBSV 8X5XNBDOS NCJCS Multirate XFP module for 10GBASE-LR Inquiry
CON-NCJE-XFPR10GL CMB SVC 8X5X4 NCJE Multirate XFP module for 10GBASE-LR Inquiry
CON-NCJP-XFPR10GL CMB SVC 24X7X4 NCJP Multirate XFP module for 10GBASE-LR Inquiry
CON-NCJT-XFPR10GL CMBSVC 8X5XNBD NCJT Multirate XFP module for 10GBASE-LR Inquiry
CON-NCJW-XFPR10GL CMB SPT SVC SW NCJW Multirate XFP module for 10GBASE-LR Inquiry
CON-S2P-XFPR10GL SNTC-24X7X2 Multirate XFP module for 10GBASE-LR Inquiry
CON-SSC2P-XFPR10GL SOLN SUPP 24X7X2OS Multirate XFP module for 10GBASE-LR Inquiry
CON-SSC4P-XFPR10GL SOLN SUPP 24X7X4OS Multirate XFP module for 10GBASE-LR Inquiry
CON-SSC4S-XFPR10GL SOLN SUPP 8X5X4OS Multirate XFP module for 10GBASE-LR Inquiry
CON-SSCS-XFPR10GL SOLN SUPP 8X5XNBDOS Multirate XFP module for 10GBASE-LR Inquiry
CON-SSS2P-XFPR10GL SOLN SUPP 24X7X2 Multirate XFP module for 10GBASE-LR Inquiry
CON-SSSNE-XFPR10GL SOLN SUPP 8X5X4 Multirate XFP module for 10GBASE-LR Inquiry
CON-SSSNP-XFPR10GL SOLN SUPP 24X7X4 Multirate XFP module for 10GBASE-LR Inquiry
CON-SSSNT-XFPR10GL SOLN SUPP 8X5XNBD Multirate XFP module for 10GBASE-LR Inquiry
CON-SW-XFPR10GL SNTC-NO RMA Multirate XFP module for 10GBASE-LR Inquiry
