CISCO2921-V/K9

4.6 7
4.6/5.0
7 Review(s)
| 1 answered questions
Model: CISCO2921-V/K9 Cisco Router ISR G2 Voice Bundle
Detail: Cisco 2921 Voice Bundle, PVDM3-32, UC License PAK
List Price: US$5,150.00
Price: $2,163.00
You save: US$2,987.00 (58% OFF)
Condition: Brand New Sealed
Availability: In stock
Shipping:
Express Shipping to Worldwide
2-6 Days, via DHL, FedEx, EMS, etc. ?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
US$ 2,163.00 In stock Brand New Sealed
OR

CISCO2921-V/K9 SMARTnet Service Tool

Order Cisco SMARTnet Warranty? Fast Quote Now

Ask Our Experts

Live Chat | Email

  • +1-626-239-8066 (USA)
  • +852-3174-6166 (HK)
  • +852-3050-1066 (Fax)
Get Quotes up to
2x Faster
Project Inquiry
Overview

Overview (CISCO2921-V/K9)

The Cisco 2921 router, supporting voice module, is designed for small offices. CISCO2921-V/K9 include Voice Bundle.

Quick Specs

Figure 1 shows the appearance of the CISCO2921-V/K9.

cisco2921-v-k9

Table 1 shows the Quick Specs of the CISCO2921-V/K9.

Product Code

CISCO2921-V/K9

Voice Bundle

· High-density-packet voice DSP module, optimized for voice and video support
· Standards-certified VoiceXML browser services
· Cisco Unified Border Element capabilities
· Cisco Unity Express voicemail support
· Support for Cisco Communications Manager Express and Survivable
· Remote Site Telephony

Rack Units

2U

Interfaces

3 integrated 10/100/1000 Ethernet ports (RJ-45 only)

Expansion Slot(s)

2 service module slot

1 Internal Service Module slot

3 onboard digital signal processor slots

4 Enhanced high-speed WAN interface card (EHWIC) slots

RAM

512 MB (installed) / 2 GB (max)

Flash Memory

256 MB (installed) / 8 GB (max)

Dimensions

47 cm x 43.8 cm x 8.9 cm

Package Weight

17.2 Kg

Product Details

Figure 2 shows the front panel of the CISCO2921-V/K9.

cisco2921-v-k9-front

Note:

AC OK

Optional RPS adapter(blank panel shown)

On/Off switch

LEDs area

AC power connector

Figure 3 show the expansion slots and ports on the back panel.

cisco2921-v-k9-back slots

Note:

Compact flash 0 and 1 (0, right)

10/100/1000 Ethernet port (GE 0/1 and GE 0/2)

EHWIC 0,1,2 and 3 (0, far right)

10/100/1000 Ethernet port GE 0/0

USB serial port

Ground

RJ-45 serial console port

USB 0 and 1 (1, top)

AUX port

Service module slots

SFP

Modularity Features

Table 2 shows some recommended models for this router.

Models

Description

SM-ES3G-16-P

Enhanced EtherSwitch Service Module, L2/L3 switching, 16* 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology

SM-ES3G-24-P

Enhanced EtherSwitch Service Module, L2/L3 switching, 24 * 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology

HWIC-2T

2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card

EHWIC-1GE-SFP-CU

Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU

EHWIC-4ESG

Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card  for Cisco 1900 2900 3900 Routers

ISM-SRE-300-K9

Internal Services Module (ISM) with Services Ready Engine

MEM-CF-256U1GB

256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900

MEM-CF-256U2GB

256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900

MEM-CF-256U512MB

256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR

MEM-CF-256U4GB

256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900

MEMUSB-1024FT

1GB USB Flash Token

The Licenses

Table 3 shows the recommended license.

Licenses

Description

L-SL-29-SEC-K9=

Cisco 2900 License L-SL-29-SEC-K9 Security E-Delivery PAK for Cisco 2901-2951

L-SL-29-APP-K9

Cisco Application Experience License ISR 2900 Series - includes licenses for: AppX, DATA and WAASX

L-SL-29-SECNPE-K9

Cisco 2900 License L-SL-29-SECNPE-K9 SEC No Payload Encryption E PAK for Cisco 2901-2951

L-SL-29-UC-K9

Cisco 2900 License L-SL-29-UC-K9= Unified Communication E-Delivery PAK for Cisco 2901-2951

Compare to Similar Item

Table 4 shows the comparison between CISCO2921/K9 and CISCO2921-V/K9.

Model

CISCO2921/K9

CISCO2921-V/K9

Bundle

None

Voice

Interface

3GE

3GE

EHWIC slot

4

4

SIM Slot

1

1

SFP

1

1

Memory

512MB (installed) / 2 GB (max)

512MB (installed) / 2 GB (max)

Flash Memory

256MB (installed) / 8 GB (max)

256MB (installed) / 8 GB (max)

Rack Unit

2 U

2 U

Get More Information

Do you have any question about the CISCO2921-V/K9?

Contact us now via Live Chat or sales@router-switch.com.

Specification

Specification (CISCO2921-V/K9)

CISCO2921-V/K9 Specifications

Manufacturer

Cisco Systems, Inc

Manufacturer Part Number

CISCO2921-V/K9

Product Type

Router

Form Factor

External - modular - 2U

Dimensions (WxDxH)

47 cm x 43.8 cm x 8.9 cm

Weight

13.2 kg

DRAM Memory

512 MB (installed) / 2 GB (max)

Flash Memory

256 MB (installed) / 8 GB (max)

Routing Protocol

OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Network / Transport Protocol

IPSec

Remote Management Protocol

SNMP, RMON

Digital Ports Qty

32

Features

MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED)

Compliant Standards

IEEE 802.1Q, IEEE 802.3af, IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag

Power

AC 120/230 V ( 50/60 Hz )

Q&A

Faq (CISCO2921-V/K9)

I want CISCO2921-V/K9 upgrade to C2921-VSEC-SRE/K9, how?

Need module SM-SRE-700/k9& license SL-29-SEC-k9.
