CISCO1941-2.5G/K9

4.9 4
4 Review(s)
Model: CISCO1941-2.5G/K9 Cisco 1941 Router ISR G2
Detail: Cisco 1941 with 2.5G DRAM, 256MB Flash
Price: US$1,287.00
List Price: US$2,475.00
You save: US$1,188.00 (48% OFF)
Condition: Brand New Sealed
Availability: In stock
US$ 1,287.00 In stock Brand New Sealed
OR
Product Overview

Overview (CISCO1941-2.5G/K9)

The new platforms are architected to enable the next phase of branch-office evolution, providing rich media collaboration and virtualization to the branch while maximizing operational cost savings The Integrated Services Routers Generation 2 platforms are future-enabled with multi-core CPUs, Gigabit Ethernet switching with enhanced POE, and new energy monitoring and control capabilities while enhancing overall system performance. This CISCO1941-2.5G/K9 is the same as CISCO1941/K9, except the 2.5G installed DRAM.

Quick Specs

Figure 1 shows the front view of CISCO1941-2.5G/K9.

CISCO1941-2.5G/K9

Table 1 shows the Quick Specs of the CISCO1941-2.5G/K9.

Product Code

CISCO1941-2.5G/K9

Form Factor

Desktop - modular - 2U

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Network / Transport Protocol

IPSec, L2TPv3

Routing Protocol

OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing

Remote Management Protocol

SNMP, RMON

Compliant Standards

IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag

Features

Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support,

Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED)

Dimensions (W x D x H)

34.3 cm x 29.2 cm x 8.9 cm

DRAM Memory

2.5 GB

Flash Memory

256 MB (installed) / 8 GB (max)

Router Interfaces

1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Management : 1 x console - RJ-45
Management : 1 x console - mini-USB Type B
Serial : 1 x auxiliary - RJ-45
USB : 2 x 4 PIN USB Type A

Expansion Slot(s)

2 (total) / 2 (free) x HWIC
2 (total) / 1 (free) x CompactFlash Card
1 (total) / 1 (free) x Expansion Slot

Manufacturer Warranty

1 year warranty

Product Details

Figure 2 shows the ports and slots on the back panel of CISCO1941-2.5G/K9.

CISCO1941-2.5G/K9 Back Panel

Note:

On/Off switch

CF 0 LED

Input power connection

ISM or WLAN LED

AUX port

EN (Enable USB console) LED

GE 0/0

USB serial port—USB 5-pin mini USB Type-B

Kensington security slot

EN (Enable RJ-45 console) LED

CompactFlash 1

RJ-45 serial console port

CF 1 LED

GE 0/1

HWIC slot 1 (EHWIC, HWIC, or WIC)—double wide

USB ports—two USB 2.0 Type-A ports

CompactFlash 0

The Accessories

Table 2 shows some recommended accessories of CISCO1941-2.5G/K9.

Models

Description

ISM-SRE-300-K9

Internal Services Module (ISM) with Services Ready Engine

MEM-CF-256U1GB

256MB to 1GB Compact Flash Upgrade for Cisco 1900, 2900, 3900

MEM-CF-256U2GB

256MB to 2GB Compact Flash Upgrade for Cisco 1900, 2900, 3900

MEM-CF-256U512MB

256MB to 512MB CF Upgrade for Cisco 1900, 2900, 3900 ISR

MEM-CF-256U4GB

256MB to 4GB Compact Flash Upgrade for Cisco 1900, 2900, 3900

EHWIC-1GE-SFP-CU

Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU

EHWIC-4ESG

Four port 10/100/1000 Base-TX Gigabit Ethernet switch interface card for Cisco 1900 2900 3900 Routers

HWIC-2FE

HWIC two routed port Cisco Router High-Speed WAN Interface card

HWIC-1T

1-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card

HWIC-2T

2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card

VWIC3-1MFT-T1/E1

Cisco Voice/WAN Card VWIC3-1MFT-T1/E1

VWIC3-2MFT-T1/E1

Cisco Voice/WAN Card VWIC3-2MFT-T1/E1

VWIC3-1MFT-G703

Cisco Voice&WAN T1/E1 interface moudle VWIC3-1MFT-G703

VWIC3-2MFT-G703

Cisco Voice/WAN Card VWIC3-2MFT-G703

Compare to Similar Items

Table 3 shows the comparison between CISCO1941/K9 and CISCO1941-2.5G/K9.

Model

CISCO1941/K9

CISCO1941-2.5G/K9

Interface

2 GE

2 GE

EHWIC slot

2

2

SIM Slot

1

1

DRAM Memory

512 MB (installed) / 2 GB (max)

2.5 GB

Flash Memory

256 MB (installed) / 8 GB (max)

256 MB (installed) / 8 GB (max)

Rack Unit

2U

2U

Get More Information

Do you have any question about the CISCO1941-2.5G/K9?

Contact us now via Live Chat or cisco@router-switch.com.

Specification

Specification (CISCO1941-2.5G/K9)

Manufacturer Cisco Systems, Inc
Manufacturer Part Number CISCO1941-2.5G/K9
Product Type Router
Form Factor Desktop - modular - 2U
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol IPSec, L2TPv3
Routing Protocol OSPF, IS-IS, BGP, EIGRP, DVMRP, PIM-SM, IGMPv3, GRE, PIM-SSM, static IPv4 routing, static IPv6 routing
Remote Management Protocol SNMP, RMON
Features Firewall protection, VPN support, MPLS support, Syslog support, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED)
Compliant Standards IEEE 802.3ah, IEEE 802.1ah, IEEE 802.1ag
DRAM Memory 2.5 GB
Flash Memory 256 MB (installed) / 8 GB (max)
LED Status Lights Indicators Link activity, power
Connectivity Slots
Router Interfaces 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
Management : 1 x console - RJ-45
Management : 1 x console - mini-USB Type B
Serial : 1 x auxiliary - RJ-45
USB : 2 x 4 PIN USB Type A
Expansion Slot(s) 2 (total) / 2 (free) x HWIC
2 (total) / 1 (free) x CompactFlash Card
1 (total) / 1 (free) x Expansion Slot
Power Supply
Power Device Power supply - internal
Voltage Required AC 120/230 V ( 50/60 Hz )
Dimensions / Weight / Miscellaneous
Width 34.3 cm
Depth 29.2 cm
Height 8.9 cm
Weight 5.8 kg
Compliant Standards CISPR 22 Class A, CISPR 24, EN55024, EN55022 Class A, EN50082-1, CAN/CSA-E60065-00, ICES-003 Class A, CS-03, AS/NZS 3548, FCC, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60065, BSMI CNS 13438
