Model: Huawei AR2200 Series Router AR2240-S
Detail: AR2240-S Integrated Chassis Components
Price: US$1,480.00
Condition: Brand New Sealed
Availability: In stock
US$ 1,480.00 In stock Brand New Sealed
OR

Ask Our Experts

Live Chat | Email

  • +1-626-239-8066 (USA)
  • +852-3174-6166 (HK)
  • +852-3050-1066 (Fax)
Get Quotes up to
2x Faster
Project Inquiry
Overview

Overview (AR2240-S)

Huawei AR2240-S-S, AR2240-S router Integrated Chassis Components. Router reduces equipment and deployment costs due to integrated routing, switching, 3G, voice, and security functions in a single device.

Quick Specs

Figure 1 shows the appearance of Huawei Router - AR2240-S.

 AR2240-S-appearance

Table 1 shows the Quick Specs.

Product Code

Huawei Router - AR2240-S

Memory

Configured with SRU40/SRU60/SRU80/SRU100: 2 GB

Configured with SRU200: 4 GB

Flash

16 MB

Service interfaces (standard configuration)

WAN interfaces:

Configured with SRU40/SRU60/SRU80/SRU100: 1 GE electrical interface and 2 GE combo interfaces

Configured with SRU200: 2 10 GE optical interfaces and 4 GE combo interfaces

LAN interfaces: none

Extended slots

4 SIC slots, 2 WSIC slots, and 2 XSIC slots

Power module type

Pluggable power module

Weight

8.85 kg (19.51 lb)

Dimensions (W x D x H)

442.0 mm x 470.0 mm x 88.1 mm

Product Details

Figure 2 shows the front panel of AR2240-S.

 AR2240-S-front-1

Note:

Ground point

ESD jack

Two WSIC slots

Two XSIC slots

Four SIC slots

Figure 3 shows the back panel of AR2240-S.

 AR2240-S-back

Note:

SRU slots

Built-in fan module

Two power module slots

The Modules, Cards

Table 2 shows the recommended elements for the AR2240-S.

Model

Description

AC power module

AR0MPSAP3500

350W AC Power Module

DC power module

AR0MPSDP3500

350W DC Power Module

WAN interface card

AR-1E3T3M-W

1-Port Channelized/Unchannelized E3/T3 WAN Interface Card

AR0MSDE11A00

1-Port Fractional Channelized E1/T1 WAN Interface Card

xDSL interface card

AR01SLV1XA

1-Port VDSL2 over POTS WAN Interface Module

AR0MSLA1XA01

1-Port ADSL2+ ANNEX A/M WAN Interface Module

Compare to Similar Items

Table 3 shows the comparison between AR2240-S and AR2220E.

Model

AR2240-S

AR2220E

WAN Speed with Services

1 Gbit/s (with SRU40)

2 Gbit/s (with SRU80)

1 Gbit/s (with SRU100E)

4.5 Gbit/s (with SRU200)

800 Mbit/s



Fixed WAN Ports

SRU40: 3 x GE (2 x Combo)

SRU80: 3 x GE (2 x Combo)

SRU100E: 4 x GE Combo+ 2 x GE SFP

SRU200: 4 x GE Combo+ 2 x 10 GE SFP+

2 x GE

Wireless Controller

Wireless Controller is integrated in software

Memory

2 GB/4 GB

1 GB

Get More Information

Do you have any question about the AR2240-S?

Contact us now via Live Chat or cisco@router-switch.com.

Specification

Specification (AR2240-S)

AR2240-S Specification

WAN Speed with Services***

1 Gbit/s (With SRU40)

2 Gbit/s (With SRU80)

1 Gbit/s (With SRU100E)

4.5 Gbit/s (With SRU200)

Firewall Performance (large packets)

5.5 Gbit/s (With SRU40)

9.5 Gbit/s (With SRU80)

10 Gbit/s (With SRU100E)

15 Gbit/s (With SRU200)

Number of recommended users

1,000

Fixed WAN Ports

SRU40: 3 x GE (2 x Combo)

SRU80: 3 x GE (2 x Combo)

SRU100E: 4 x GE Combo+ 2 x GE SFP

SRU200: 4 x GE Combo+ 2 x 10 GE SFP+

SIC Slots

4

WSIC Slots (default/max**)

2/4

XSIC Slots (default/max**)

2/4

EXSIC Slot (shared with XSIC slots)

1

DSP Slots

0/3

USB 2.0 Ports

1/2

Mini-USB Ports

1

Console Port

1

Memory

2 GB/4 GB

Flash
(default/max**)

2 GB/8 GB

Maximum Power

350W (Single Power Module)

700W (Dual Power Module)

Redundant Power Supply

Internal: AC, DC

AC Power

100V to 240V

Frequency

50 Hz/60 Hz

DC Power

-48V to -60V

Dimensions (height x width x depth)

88.1 mm x 442 mm x 470 mm

Weight

8.95 kg (without power module and interface card)

Ambient Temperature

0°C to 45°C

Relative Humidity

5% to 95% (non-condensing)
