Model: AIR-CAP2602I-C-K9 Cisco Aironet 2600 Series Access Point
Detail: Cisco Aironet 2600 AP AIR-CAP2602I-C-K9 802.11n CAP w/CleanAir; 3x4:3SS; Mod; Int Ant; C Reg Domain; Control base
List Price: US$1,195.00
Price: $502.00
You save: US$693.00 (58% OFF)
Condition: Brand New Sealed
Availability: In stock
Shipping:
Express Shipping to Worldwide
2-6 Days, via DHL, FedEx, EMS, etc. ?
If you finish the payment today,
your order will arrive within the
estimated delivery time.
US$ 502.00 In stock Brand New Sealed
OR

AIR-CAP2602I-C-K9 SMARTnet Service Tool

Order Cisco SMARTnet Warranty? Fast Quote Now

Ask Our Experts

Live Chat | Email

  • +1-626-239-8066 (USA)
  • +852-3174-6166 (HK)
  • +852-3050-1066 (Fax)
Get Quotes up to
2x Faster
Project Inquiry
Overview

Overview (AIR-CAP2602I-C-K9)

Cisco Aironet 2600 Series Access Point:

3 x 4 MIMO technology with three spatial streams

standalone access point, IEEE 802.11 a/b/g/n

Dual-band, Internal antennas and E regulatory domain

Cross AP Noise Reduction, MIMO equalization

AIR-CAP2602I-C-K9 is 2600 series wireless access point in standalone mode, which offers a low-cost, entry-level solution with no requiring wireless controller. AIR-CAP2602I-C-K9 offers base-level wireless functionality with the high-performance, high-flexibility to support unique requirement for scale and mobility services. Standalone model and controller base access point can be interchangeable by upgrade or downgrade the system IOS to satisfy the needs by add services over time by adding a controller, which means, a controller is required to support voice, location services, guest access, and advanced security.

2600 series standalone model deliver the highest level of IEEE 802.11n performance which sustains up to 450-Mbps data rate, and 3*4 MIMO technology with three-spatial stream provides optimal coverage to ensure best possible end user experience on the wireless network.

Quick Specs

Figure 1 shows the appearance of AIR-CAP2602I-C-K9.

 AIR-CAP2602I-C-K9

Table 1 shows the Quick Specs.

Product Code

AIR-CAP2602I-C-K9

RAM

256 MB

Wireless Type

802.11G, 802.11n

Brand Name

Cisco

Item model number

AIR-CAP2602I-C-K9

Item Weight

2.5 pounds

Product Dimensions

8.7 x 8.7 x 2.1 inches

Item Dimensions L x W x H

8.7 x 8.7 x 2.13 inches

Flash Memory Size

32

Product Details

Figure 2 shows the front panel of AIR-CAP2602I-C-K9.

 AIR-CAP2602I-C-K9-Back

Note:

LED indicator

Get More Information

Do you have any question about the AIR-CAP2602I-C-K9 ?

Contact us now via Live Chat or sales@router-switch.com.

Specification

Specification (AIR-CAP2602I-C-K9)

AIR-CAP2602I-C-K9 Specification

Product Description

Cisco Aironet 2600 Series Access Points with Internal antennas



Devide Type

standalone Wireless  Access point



Regulatory domain

E regulatory domain



Software

Cisco Unified Wireless Network Software Release 7.2.110 or later.



Data rates supported

● 802.11a: up to 54 Mbps
● 802.11g: up to 54 Mbps

● 802.11n on 2.4 GHz: up to 450Mbps

Maximum number of nonoverlapping channels

5 GHz
● 802.11a:
◦ 20 MHz: 21
● 802.11n:
◦ 20 MHz: 21
◦ 40 MHz: 9

2.4 GHz
● 802.11b/g:
◦ 20 MHz: 3
● 802.11n:
◦ 20 MHz: 3

External antenna (antenna purchase separately)

● Certified for use with antenna gains up to 6 dBi (2.4 GHz and 5 GHz)

● Cisco offers the industry's broadest selection of 802.11n antennas delivering optimal coverage for a variety of deployment scenarios

Interfaces

● 10/100/1000BASE-T autosensing (RJ-45)

● Management console port (RJ-45)

System memory

● 256 MB DRAM

● 32 MB flash

Power consumption ( power supply pruchase separately)

15.4 Watts (standard 802.3af POE)



IEEE standards

● IEEE 802.11a/b/g, 802.11n, 802.11h, 802.11d



Security

● 802.11i, Wi-Fi Protected Access 2 (WPA2), WPA
● 802.1X

● Advanced Encryption Standards (AES), Temporal Key Integrity Protocol (TKIP)

Frequency band and 20-MHz operating channels

A (A regulatory domain):
●  2.412 to 2.462 GHz; 11 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.500 to 5.700 GHz; 8 channels
(excludes 5.600 to 5.640 GHz)
●  5.745 to 5.825 GHz; 5 channels
C (C regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.745 to 5.825 GHz; 5 channels
D (D regulatory domain):
●  2.412 to 2.462 GHz; 11 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.745 to 5.825 GHz; 5 channels
E (E regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.500 to 5.700 GHz; 8 channels
(excludes 5.600 to 5.640 GHz)
H (H regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.150 to 5.350 GHz; 8 channels
●  5.745 to 5.825 GHz; 5 channels
I (I regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.180 to 5.320 GHz; 8 channels
K (K regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.500 to 5.620 GHz; 7 channels
●  5.745 to 5.805 GHz; 4 channels

N (N regulatory domain):
●  2.412 to 2.462 GHz; 11 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.745 to 5.825 GHz; 5 channels
Q (Q regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.500 to 5.700 GHz; 11 channels
R (R regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.660 to 5,805 GHz; 7 channels
S (S regulatory domain):
●  2.412 to 2.472 GHz; 13 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.500 to 5.700 GHz;, 11 channels
●  5.745 to 5.825 GHz; 5 channels
T (T regulatory domain):
●  2.412 to 2.462 GHz; 11 channels
●  5.280 to 5.320 GHz; 3 channels
●  5.500 to 5.700 GHz; 8 channels
(excludes 5.600 to 5.640 GHz)
●  5.745 to 5.825 GHz; 5 channels
Z (Z regulatory domain):
●  2.412 to 2.462 GHz; 11 channels
●  5.180 to 5.320 GHz; 8 channels
●  5.500 to 5.700 GHz; 8 channels
(excludes 5.600 to 5.640 GHz)
●  5.745 to 5.825 GHz; 5 channels

Environmental

● Nonoperating (storage) temperature: -22 to 158°F (-30 to 70°C)
● Nonoperating (storage) Altitude Test: 25˚C, 15,000 ft.
● Operating temperature: -4 to 131°F (-20 to 55°C)

● Operating humidity: 10 to 90 % (noncondensing)
● Operating Altitude Test: 40˚C, 9843 ft.

Q&A

Faq (AIR-CAP2602I-C-K9)

AIR-CAP2602I-C-K9, is this module must work with Controller?

This AP is Controller-Based Access Point, so can’t work without controller. But on Cisco.com it has 2 versions of IOS, Autonomous AP IOS Software & Lightweight AP IOS Software. If you need, we can supply IOS to alter it.
